0.65" 4K UHD, 3840x2160, 5500 ANSI, F=2.3-3.0, f=17.63-27.9mm, 30"-300"
Key Features
- True 4K HDR delivers exceptional image clarity and detail
- Clear visuals with 5,500 ANSI Lumens and high native contrast ratio provided by a 0.65” DMD chip
- Supports 21:9 aspect ratio, ideal for Microsoft Teams Rooms
- Installation flexibility: 1.7x zoom, V lens shift, H/V keystone correction, and 360° projection
- Centralized LAN control for efficient management
- 3rd generation laser phosphor technology with up to 30,000-hour lifespan
Description
Introducing the LS901-4K from ViewSonic’s Luminous Superior Series, tailored for expansive venue displays. Featuring 5,500 ANSI lumens of brightness and high native contrast provided by a 0.65” DMD chip through DLP technology, it delivers stunning 4K UHD visuals on screens larger than 100 inches. Perfect for museums and educational institutions, the LS901-4K’s ultra-high resolution with HDR/HLG support ensures every detail is vivid and clear, enhancing viewer engagement. With 21:9 aspect ratio support, the LS901-4K is also an ideal choice for Microsoft Teams Rooms. Its 1.7x optical zoom allows for a flexible setup to suit various installation needs, and the vertical lens shift and H/V keystone adjustment make the process a breeze. Additionally, portrait mode and 360° projection capabilities cater to more advanced requirements. Comprehensive LAN control ensures seamless integration into corporate networks. Employing advanced 3rd generation laser phosphor technology, the LS901-4K boasts a remarkable 30,000-hour lifespan, reducing maintenance costs for both business and educational institutions.
Specifications
| Projector |
|---|
| Projector brightness |
5500 ANSI lumens |
| Projector native resolution |
UHD 4K (3840x2160) |
| Screen size compatibility |
30 - 300" |
| Native aspect ratio |
16:9 |
| Projection distance |
31.5 - 533.5" (0.8 - 13.6 m) |
| Contrast ratio (typical) |
3000000:1 |
| Number of colours |
1.07 billion colors |
| Vertical scan range |
23 - 240 Hz |
| Horizontal scan range |
15 - 255 kHz |
| Keystone correction, vertical |
-30 - 30° |
| Keystone correction, horizontal |
-30 - 30° |
| Light source |
|---|
| Service life of light source |
20000 h |
| Service life of light source (economic mode) |
30000 h |
| Lens system |
|---|
| Zoom capability |
Yes |
| Focal length range |
17.63 - 27.9 mm |
| Aperture range (F-F) |
2.3 - 3 |
| Vertical lens shift range |
-21 - 0% |
| Offset |
154% |
| Video |
|---|
| Full HD |
Yes |
| Ports & interfaces |
|---|
| HDMI ports quantity |
2 |
| USB 2.0 ports quantity |
2 |
| Audio (L/R) out |
1 |
| Serial interface type |
RS-232 |
| AC (power) in |
Yes |
| Network |
|---|
| Ethernet LAN |
Yes |
| Ethernet LAN (RJ-45) ports |
1 |
| Features |
|---|
| Noise level |
31 dB |
| Noise level (economic mode) |
25 dB |
| Multimedia |
|---|
| Built-in speaker(s) |
Yes |
| Number of built-in speakers |
2 |
| RMS rated power |
30 W |
| Design |
|---|
| Market positioning |
Education |
| Product colour |
White |
| Product type |
Standard throw projector |
| LED indicators |
Yes |
| Display |
|---|
| Built-in display |
No |
| Power |
|---|
| Power source |
AC |
| Power consumption (typical) |
245 W |
| Power consumption (standby) |
0.5 W |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50 - 60 Hz |
| Supplier features |
|---|
| Harmonized System (HS) code |
8528620000 |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Weight & dimensions |
|---|
| Width |
13.3" (337 mm) |
| Depth |
11" (280 mm) |
| Height |
5.2" (132 mm) |
| Weight |
10.7 lbs (4.85 kg) |
| Package width |
19.5" (496 mm) |
| Package depth |
7.68" (195 mm) |
| Package height |
15.2" (387 mm) |
| Package weight |
15 lbs (6.8 kg) |
| Packaging content |
|---|
| Remote control included |
Yes |
| Manual |
Yes |
| Logistics data |
|---|
| Pallet gross width |
48" (122 cm) |
| Pallet gross length |
40.2" (102 cm) |
| Pallet gross height |
81.1" (2.06 m) |
| Products per master (outer) case |
1 pc(s) |
| Harmonized System (HS) code |
8528620000 |
