86", 4K UHD (3840 x 2160), TFT LCD, DLED, 1.07B, 500 nits, 1200:1, 8 ms, 2x 10 W, HDMI 2.1, RS-232, VGA, SPDIF, RJ45, USB-A, USB-C, 3.5 mm, OS-Free
Key Features
- OPTIMIZED FOR VIDEOCONFERENCING: Clear 4K visuals and reliable performance for smooth, professional meetings
- FAST STARTUP: Boots in seconds so meetings start on time, every time
- SIMPLE CONNECTIVITY: One USB-C cable plus HDMI for quick, easy laptop connections
- SEAMLESS AV INTEGRATION: Certified for Q-SYS, compatible with Crestron, Extron, and AMX
- FLEXIBLE INSTALLATION: Supports portrait or landscape mounting to fit any space
Description
The ViewSonic® CDE86G3 is a 86” commercial display designed to make meetings, trainings, and videoconferences fast, simple, and professional. Its 4K UHD resolution ensures crisp visuals for presentations and video calls, while 24/7 commercial-grade reliability keeps it running smoothly in huddle rooms, conference rooms, and executive offices. Booting in as fast as 8 seconds, the CDE86G3 gets your meetings started on time without delays. A single USB-C cable plus HDMI lets you easily connect laptops, share content, and power devices, making setup quick and effortless. Q-SYS certified and compatible with Crestron, Extron, and AMX, it integrates seamlessly into existing AV systems. With no operating system to manage, this OS-free display reduces security risks and IT complexity, giving your team a safer, low-maintenance solution. The versatile 86" size fits perfectly in a variety of meeting spaces while delivering big-screen impact.
Specifications
| Display |
|---|
| LED backlight |
Yes |
| Display diagonal |
86" |
| Display resolution |
3840 x 2160 pixels |
| Display brightness |
500 cd/m² |
| HD type |
4K Ultra HD |
| Response time |
8 ms |
| Contrast ratio (typical) |
1200:1 |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Display diagonal (metric) |
85.8" (218 cm) |
| Display number of colours |
1.07 billion colors |
| Panel life |
50000 h |
| Touchscreen |
No |
| Supported video modes |
480i, 480p, 720p, 1080i, 1080p, 2160p |
| Panel type |
VA |
| Native aspect ratio |
16:9 |
| LED backlighting type |
Direct-LED |
| Display technology |
LCD |
| Anti-glare screen |
Yes |
| Colour depth |
8 bit |
| Surface hardness |
3H |
| Native refresh rate |
60 Hz |
| Haze rate |
25% |
| Ports & interfaces |
|---|
| Ethernet LAN |
Yes |
| HDMI ports quantity |
3 |
| HDMI version |
2.1 |
| DVI port |
No |
| VGA (D-Sub) input ports |
1 |
| USB connector type |
USB Type-A, USB Type-C |
| USB port |
Yes |
| Ethernet LAN (RJ-45) ports |
1 |
| RS-232 interface |
Yes |
| USB version |
2.0 |
| USB ports quantity |
3 |
| PC Audio out |
Yes |
| PC Audio in |
Yes |
| DisplayPort version |
1.2 |
| HDMI input ports quantity |
3 |
| USB Type-C DisplayPort Alternate Mode |
Yes |
| Audio Return Channel (ARC) |
Yes |
| Consumer Electronics Control (CEC) |
Yes |
| Audio |
|---|
| Number of built-in speakers |
2 |
| RMS rated power |
20 W |
| Built-in speaker(s) |
Yes |
| Design |
|---|
| Product design |
Digital signage flat panel |
| Product colour |
Black |
| VESA mounting |
Yes |
| Panel mounting interface |
600 x 400 mm |
| Placement supported |
Indoor |
| Orientation |
Horizontal/Vertical |
| Bezel width (top) |
0.626" (1.59 cm) |
| Bezel width (side) |
0.626" (1.59 cm) |
| Bezel width (bottom) |
0.626" (1.59 cm) |
| Anti-glare screen |
Yes |
| Screen shape |
Flat |
| Performance |
|---|
| Purpose |
Commercial |
| Operating hours (hours/days) |
24/7 |
| HDCP |
Yes |
| HDCP version |
2.2 |
| Panel life |
50000 h |
| Power |
|---|
| Power consumption (typical) |
119.6 W |
| Power consumption (standby) |
0.5 W |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50/60 Hz |
| Power consumption (max) |
179.2 W |
| Computer system |
|---|
| Processor model |
MTK3683 |
| Processor manufacturer |
MediaTek |
| Built-in processor |
Yes |
| Weight & dimensions |
|---|
| Display width |
76.1" (1933.8 mm) |
| Display depth |
3.14" (79.7 mm) |
| Display height |
43.5" (1103.8 mm) |
| Display weight |
87.1 lbs (39.5 kg) |
| Packaging data |
|---|
| Package width |
82.5" (2095 mm) |
| Package depth |
7.28" (185 mm) |
| Package height |
48" (1220 mm) |
| Package weight |
118.6 lbs (53.8 kg) |
| Remote control included |
Yes |
| Mounting kit |
Yes |
| Cables included |
AC, HDMI |
| Batteries included |
Yes |
| Packaging content |
|---|
| Remote control included |
Yes |
| Mounting kit |
Yes |
| Cables included |
AC, HDMI |
| Batteries included |
Yes |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Operating altitude |
0 - 118110.2" (0 - 3000 m) |
| Network |
|---|
| Ethernet LAN |
Yes |
| Thin Client |
|---|
| Processor model |
MTK3683 |
| Technical details |
|---|
| USB connector type |
USB Type-A, USB Type-C |
| Screws included |
Yes |
| Panel type |
VA |
| LED backlighting type |
Direct-LED |
| DisplayPort version |
1.2 |
| Sustainability certificates |
ENERGY STAR, Mexico Energy |
| Warranty period |
3 year(s) |
| Compliance certificates |
Federal Communications Commission (FCC), cTUVus, RoHS |
| Other features |
|---|
| USB connector type |
USB Type-A, USB Type-C |
| Screws included |
Yes |
| Power consumption (max) |
179.2 W |
| PC Audio out |
Yes |
| Panel type |
VA |
| Operating altitude |
0 - 118110.2" (0 - 3000 m) |
| Headphone connectivity |
3.5 mm |
| DisplayPort version |
1.2 |
| Display technology |
LCD |
| Bezel width (top) |
0.626" (1.59 cm) |
| Bezel width (side) |
0.626" (1.59 cm) |
| Bezel width (bottom) |
0.626" (1.59 cm) |
