UAP-AC-PRO - Indoor/Outdoor, 2.4GHz/5GHz, 802.11 a/b/g/n/ac, 2x 10/100/1000, 1x USB 2.0, 802.3af PoE, 802.3at PoE+
Description
Scalable Enterprise Wi-Fi ManagementUniFi® is the revolutionary Wi-Fi system that combines enterprise performance, unlimited scalability, and a central management controller. UniFi 802.11AC Dual‑Radio Access Points (APs) have a refined industrial design and can be easily installed using the included mounting hardware.
Easily accessible through any standard web browser, the UniFi Controller software is a powerful software engine ideal for high-density client deployments requiring low latency and high uptime performance.
Use the UniFi Controller software to quickly configure and administer an enterprise Wi-Fi network – no special training required. RF map and performance features, real-time status, automatic UAP device detection, and advanced security options are all seamlessly integrated.
Save money and save timeUnlike traditional enterprise Wi-Fi systems that use a hardware controller, UniFi comes bundled with a non-dedicated software controller that can be deployed on an on-site PC, Mac, or Linux machine; in a private cloud; or using a public cloud service.
Powerful HardwareThe UniFi 802.11AC Dual-Radio APs feature the latest in Wi-Fi 802.11AC MIMO technology.
Intuitive UniFi Controller SoftwareConfigure and manage your APs with the easy-to-learn user interface.
ExpandableUnlimited scalability: build wireless networks as big or small as needed. Start with one (or upgrade to a three‑pack) and expand to thousands while maintaining a single unified management system.
UAP-AC-PRODeploy the UniFi AC Pro AP indoors or outdoors, in wireless networks requiring maximum performance.
Sporting a weatherproof design, the UniFi AC Pro AP features simultaneous, dual-band, 3x3 MIMO technology and convenient 802.3af PoE/802.3at PoE+ compatibility. It is available in single- and five‑packs.
Specifications
| Performance |
|---|
| Maximum data transfer rate |
1300 Mbit/s |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Wi-Fi data rate (max) |
1300 Mbit/s |
| 2.4 GHz |
Yes |
| 5 GHz |
Yes |
| Reset button |
Yes |
| Networking standards |
IEEE 802.11ac, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11v |
| Maximum indoor range |
4803.1" (122 m) |
| Certification |
CE, FCC, IC |
| Features |
|---|
| Maximum data transfer rate |
1300 Mbit/s |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Wi-Fi data rate (max) |
1300 Mbit/s |
| 2.4 GHz |
Yes |
| 5 GHz |
Yes |
| Networking standards |
IEEE 802.11ac, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11v |
| Maximum indoor range |
4803.1" (122 m) |
| Security |
|---|
| Security algorithms |
AES, TKIP, WEP, WPA, WPA2 |
| Ports & interfaces |
|---|
| USB 2.0 ports quantity |
1 |
| Ethernet LAN (RJ-45) ports |
2 |
| Power |
|---|
| Power consumption (max) |
9 W |
| Input current |
0.5 A |
| Power over Ethernet (PoE) |
Yes |
| AC input voltage |
48 V |
| Design |
|---|
| Internal |
No |
| Reset button |
Yes |
| Product colour |
White |
| Certification |
CE, FCC, IC |
| Antenna |
|---|
| Antennas quantity |
3 |
| Antenna gain level (max) |
3 dBi |
| Technical details |
|---|
| Harmonized System (HS) code |
85176990 |
| Certificates |
|---|
| Certification |
CE, FCC, IC |
| Weight & dimensions |
|---|
| Width |
7.74" (196.7 mm) |
| Depth |
7.74" (196.7 mm) |
| Height |
1.38" (35 mm) |
| Weight |
12.3 oz (350 g) |
| Packaging data |
|---|
| PoE adapter included |
Yes |
| Mounting kit |
Yes |
| Packaging content |
|---|
| PoE adapter included |
Yes |
| Mounting kit |
Yes |
| Quantity per pack |
1 pc(s) |
| Operational conditions |
|---|
| Operating relative humidity (H-H) |
5 - 95% |
| Operating temperature (T-T) |
-10 - 70 °C |
| Logistics data |
|---|
| Quantity per pack |
1 pc(s) |
| Harmonized System (HS) code |
85176990 |
