Tripp Lite ECO750UPS, Standby (Offline), 0.75 kVA, 450 W, Sine, 110 V, 120 V
Description
Tripp Lite ECO750UPS. UPS topology: Standby (Offline), Output power capacity: 0.75 kVA, Output power: 450 W. AC outlet types: NEMA 5–15R, Power plug: NEMA 5-15P, AC outlets quantity: 12 AC outlet(s). Typical backup time at full load: 2 min, Typical backup time at half load: 8.6 min. Form factor: Compact, Product color: Black, Housing material: Acrylonitrile butadiene styrene (ABS). Compliance certificates: RoHS
Specifications
| Power |
|---|
| Output power capacity |
0.75 kVA |
| Output power |
450 W |
| Input operation voltage (min) |
110 V |
| Input operation voltage (max) |
120 V |
| Output operation voltage (min) |
110 V |
| Output operation voltage (max) |
120 V |
| Surge energy rating |
316 J |
| Maximum current |
10 A |
| Output frequency |
50/60 Hz |
| ECO mode |
Yes |
| Ports & interfaces |
|---|
| Cable length |
59.1" (1.5 m) |
| AC outlets quantity |
12 AC outlet(s) |
| AC outlet types |
NEMA 5–15R |
| Power plug |
NEMA 5-15P |
| USB port |
Yes |
| USB 2.0 ports quantity |
1 |
| Modem (RJ-11) ports |
1 |
| Ethernet LAN (RJ-45) ports |
2 |
| Performance |
|---|
| UPS topology |
Standby (Offline) |
| Number of input phases |
1 |
| Response time |
6 ms |
| EMI/RFI noise filtering |
Yes |
| Surge protection |
Yes |
| Surge protection features |
Digital Subscriber Line (DSL), Network, Telephone |
| Waveform |
Sine |
| LED indicators |
Yes |
| Audible alarm(s) |
Yes |
| Features |
|---|
| UPS topology |
Standby (Offline) |
| Output power capacity |
0.75 kVA |
| Country of origin |
China |
| Number of input phases |
1 |
| Response time |
6 ms |
| Output power |
450 W |
| Input operation voltage (min) |
110 V |
| Input operation voltage (max) |
120 V |
| Output operation voltage (min) |
110 V |
| Output operation voltage (max) |
120 V |
| Surge energy rating |
316 J |
| Maximum current |
10 A |
| EMI/RFI noise filtering |
Yes |
| Surge protection |
Yes |
| Surge protection features |
Digital Subscriber Line (DSL), Network, Telephone |
| Waveform |
Sine |
| Output frequency |
50/60 Hz |
| Audible alarm(s) |
Yes |
| ECO mode |
Yes |
| Battery |
|---|
| Typical backup time at half load |
8.6 min |
| Typical backup time at full load |
2 min |
| Cold start |
Yes |
| Design |
|---|
| Form factor |
Compact |
| Country of origin |
China |
| Product colour |
Black |
| Cable length |
59.1" (1.5 m) |
| LED indicators |
Yes |
| Housing material |
Acrylonitrile butadiene styrene (ABS) |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-15 - 50 °C |
| Operating relative humidity (H-H) |
0 - 95% |
| Technical details |
|---|
| Output frequency |
50/60 Hz |
| Sustainability certificates |
ENERGY STAR |
| Compliance certificates |
RoHS |
| Certificates |
|---|
| Compliance certificates |
RoHS |
| Packaging content |
|---|
| Cables included |
USB cable |
| Manual |
Yes |
| Sustainability |
|---|
| Sustainability certificates |
ENERGY STAR |
| Weight & dimensions |
|---|
| Width |
5.12" (130 mm) |
| Depth |
12.2" (309.9 mm) |
| Height |
3.35" (85.1 mm) |
| Weight |
6.81 lbs (3.09 kg) |
| Package width |
5.98" (151.9 mm) |
| Package depth |
14.9" (379 mm) |
| Package height |
7.83" (198.9 mm) |
| Package weight |
8.33 lbs (3.78 kg) |
| Packaging data |
|---|
| Cables included |
USB cable |
| Manual |
Yes |
| Package width |
5.98" (151.9 mm) |
| Package depth |
14.9" (379 mm) |
| Package height |
7.83" (198.9 mm) |
| Package weight |
8.33 lbs (3.78 kg) |
| Logistics data |
|---|
| Country of origin |
China |
| Products per master (outer) case |
6 pc(s) |
| Master (outer) case width |
15.6" (395 mm) |
| Master (outer) case length |
18.7" (475 mm) |
| Master (outer) case height |
16.9" (428 mm) |
| Master (outer) case gross weight |
47.2 lbs (21.4 kg) |
| Master (outer) case GTIN (EAN/UPC) |
10037332211115 |
