Wi-Fi 7, 1x RJ-45, IP66, OFDMA, QoS, MLO, PoE+
Key Features
- Directional and Omnidirectional Antennas: Freely switch between modes via software for optimal signal control
- Plug & Play Auto-Sensing Antennas: Automatically detects antenna changes and switches between internal and external antennas as needed
- 4-Stream Dual-Band Wi-Fi 7: Up to 5.0 Gbps
- 1× 2.5G PoE Port: Flexible PoE deployment reduces costs by delivering power and data over a single Ethernet cable
- Outdoor-Ready Durability: Features an IP66-rated weatherproof enclosure and 6kV lightning protection
- Quick and Easy Setup: Features wall/pole mounting with Omada SDN for one-click setup
- Advanced Features: Centralized management, mesh, and seamless roaming
Description
Versatile Antennas DeploymentAdapt to any environment effortlessly by selecting the antenna type that suits your needs. Whether you require long-distance connectivity or need to cover multiple endpoints, easily switch between external omni, internal directional, or custom antenna configurations with just a few clicks in the software.
Auto-Sensing Plug & Play—No Expertise NeededAutomatically detects the attachment and removal of antennas (included) in auto mode and seamlessly switches between the internal and external antennas with zero configuration.
Outdoor-Ready IP66 Weatherproof DesignThe EAP725-Outdoor features an IP66 weatherproof rating, ensuring reliable protection against heavy rain, dust, and harsh weather conditions.
Seamless Connectivity with Mesh and RoamingEnsures customers enjoy uninterrupted streaming when moving around by switching clients automatically to the access points with the optimal signal.
Works with Omada SDN for One-Click SetupOmada SDN allows users to quickly set up the EAP725-Outdoor through automatic device identification and one‑click adoption.
Empowering Businesses with Reliable Omada SDN SolutionsOmada’s Software-Defined Networking (SDN) solution seamlessly integrates access points (APs), managed switches, and gateways, enabling 100% centralized cloud management for a highly scalable network.
Specifications
| Performance |
|---|
| Maximum data transfer rate |
5000 Mbit/s |
| Ethernet LAN data rates |
10,100,1000,2500 Mbit/s |
| 2.4 GHz |
Yes |
| 5 GHz |
Yes |
| Wireless isolation |
Yes |
| Wi-Fi Multimedia (WMM)/(WME) |
Yes |
| Syslog |
Yes |
| Web-based management |
Yes |
| VLAN support |
Yes |
| Reset button |
Yes |
| Rate limiting |
Yes |
| Quality of Service (QoS) support |
Yes |
| Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11be, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11v, IEEE 802.1x, IEEE 802.3at |
| Band steering |
Yes |
| Features |
|---|
| 6 GHz |
No |
| Maximum data transfer rate |
5000 Mbit/s |
| Ethernet LAN data rates |
10,100,1000,2500 Mbit/s |
| 2.4 GHz |
Yes |
| 5 GHz |
Yes |
| Wireless isolation |
Yes |
| Wi-Fi Multimedia (WMM)/(WME) |
Yes |
| VLAN support |
Yes |
| Rate limiting |
Yes |
| Quality of Service (QoS) support |
Yes |
| Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11be, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11v, IEEE 802.1x, IEEE 802.3at |
| Cabling technology |
10/100/1000/2500Base-T |
| Bluetooth |
Yes |
| Bluetooth version |
5.2 |
| Band steering |
Yes |
| Maximum data transfer rate (2.4 GHz) |
688 Mbit/s |
| Maximum data transfer rate (5 GHz) |
4324 Mbit/s |
| Virtual LAN features |
Management VLAN |
| Bluetooth Low Energy (BLE) |
Yes |
| BeamForming |
Yes |
| Security |
|---|
| Security algorithms |
OWE, SNMP, SNMPv2, SNMPv3, SSH, WPA-Enterprise, WPA-Personal, WPA2-Enterprise, WPA2-Personal, WPA3-Enterprise, WPA3-Personal |
| Number of SSID supported |
16 |
| MAC address filtering |
Yes |
| Service Set Identifier (SSID) features |
Multiple SSIDs |
| Schedule access |
Yes |
| Management features |
|---|
| Syslog |
Yes |
| Web-based management |
Yes |
| Cloud-managed |
Yes |
| Ports & interfaces |
|---|
| USB 2.0 ports quantity |
0 |
| Ethernet LAN (RJ-45) ports |
1 |
| Cabling technology |
10/100/1000/2500Base-T |
| Power |
|---|
| Power consumption (max) |
18.4 W |
| Power over Ethernet (PoE) |
Yes |
| Power over Ethernet (PoE) type supported |
PoE+ |
| Design |
|---|
| Reset button |
Yes |
| Placement |
Pole, Wall |
| LED indicators |
Status |
| International Protection (IP) code |
IP66 |
| Product colour |
White |
| Antenna |
|---|
| Antenna type |
Internal & external |
| Antennas quantity |
8 |
| Antenna gain level (max) |
13.2 dBi |
| Technical details |
|---|
| Compliance certificates |
BSMI, CE, Federal Communications Commission (FCC), Industry Canada (IC), JRF, NCC, RoHS, VCCI |
| Certificates |
|---|
| Compliance certificates |
BSMI, CE, Federal Communications Commission (FCC), Industry Canada (IC), JRF, NCC, RoHS, VCCI |
| Weight & dimensions |
|---|
| Width |
8.19" (208 mm) |
| Depth |
6.3" (160 mm) |
| Height |
2.17" (55 mm) |
| Weight |
2.93 lbs (1.33 kg) |
| Packaging data |
|---|
| Mounting kit |
Yes |
| Packaging content |
|---|
| Mounting kit |
Yes |
| Quantity per pack |
1 pc(s) |
| Operational conditions |
|---|
| Operating relative humidity (H-H) |
10 - 90% |
| Operating temperature (T-T) |
-30 - 70 °C |
| Storage temperature (T-T) |
-40 - 70 °C |
| Storage relative humidity (H-H) |
5 - 90% |
| Logistics data |
|---|
| Quantity per pack |
1 pc(s) |
