Fusion Pro 2.5G PoE Gateway with SSD Tray, 3.69", LCM, Touchscreen, 4 GB DDR4, 54V/4.16A, 225 W PoE+, Black, 226 × 135 × 31.5 mm
Key Features
- One Platform for Networking & Surveillance: Centrally manage Omada APs, switches, cameras, and an NVR.
- Simplified Setup: App-guided onboarding via Bluetooth and one-tap bulk device adoption.
- License‑Free Cloud Management: Advanced networking & AI-powered surveillance with DPI, QoS, and Smart Search*.
- Enterprise‑Grade Performance: 9× 2.5G ports (8× PoE+, 180W total budget), Quad-core CPU, 2.3 Gbps IPS/IDS throughput†.
- Flexible Storage Options: 1× NVMe SSD tray for 2TB video storage or an external NVR expansion for up to 24× cameras.
- Quick Troubleshooting via Touchscreen: Speed test, fault alerts, traffic insight, and more.
- Advanced Software Capabilities: Full-featured VPNs, full mesh SD-WAN, auto QoS, content filtering.
- Professional Video Monitoring: Smart Search, case management, third-party camera support, and cloud drive & NAS archive.
Description
Unified Control for Networking & Surveillance in One PlatformCombining a gateway, controller, and video management system in a single device, Omada Fusion Pro 2.5G PoE delivers a unified networking and surveillance solution. Centrally manage APs, switches, cameras, and an NVR through one intuitive interface. Instantly detect, diagnose, and resolve issues without switching between systems.
Simplified Setup for Faster Deployment, Boosting EfficiencyEasily set up the Fusion Pro 2.5G PoE via Bluetooth using the Omada app. Automatically discover and batch adopt all other Omada and VIGI devices at once, saving time and simplifying IT deployment.
License‑Free Cloud Management, Lower Ongoing CostsEnjoy premium networking and AI-powered security features, including DPI, IDS/IPS, Smart Search*, and more, all included with no additional subscription fees.
Enterprise‑Grade Performance, Built for Demanding Environments
Quick Troubleshooting via Touchscreen,
Reducing On-Site VisitsWith an innovative 3.69-inch touchscreen, enjoy quick troubleshooting—all at your fingertips. Reduce on‑site visits and save time with direct, on‑device monitoring.
Secure Remote Network Access, One Click AwayWith Omada LightLink VPN, securely access your network from anywhere with one click. Powered by Smart Split Tunneling, only essential traffic goes through the VPN, reducing unnecessary VPN load and preserving a smooth user experience.
Advanced Networking Capabilities for Secure and Intelligent Management
Simple Multi-Site Connectivity with Full-Mesh SD-WANConnect up to 20 sites with direct inter‑site links—simpler to deploy, smoother for multi‑site networking.
App‑Based Access ControlEasily manage access by app and category. Control access intuitively with simple, clearly defined policies.
One-Click Auto QoSEnsure critical traffic always gets priority, with one-click presets or full customization.
Content Filtering & Ad BlockingBlocks unwanted sites and intrusive ads for a safer, cleaner experience.
Professional Features for High-Efficiency Video Monitoring
Uninterrupted Surveillance with Easier Maintenance
Flexible Mounting for Diverse Business Environments
DesktopNo Additional Installation Needed
Wall‑MountableMagnetic-Mount Plate Needed
Rack‑MountableRack-Mount Kit Needed
Designed for Forward-Thinking BusinessesSpecifications
| Design |
|---|
| LED indicators |
Link, PoE |
| Mounting type |
Rack/Desktop/Wall |
| Product colour |
Black |
| Enclosure material |
Polycarbonate (PC) |
| Number of fans |
1 fan(s) |
| Performance |
|---|
| Internal memory type |
DDR4 |
| Internal memory |
4000 MB |
| Display type |
LCM |
| Control display unit |
Yes |
| Number of SSDs supported |
1 |
| Mounting type |
Rack/Desktop/Wall |
| Product colour |
Black |
| Enclosure material |
Polycarbonate (PC) |
| Protocols |
|---|
| DHCP server |
Yes |
| Network |
|---|
| NAT functionality |
Port Forwarding / Virtual Server / DMZ / ALG / UPnP / One-to-One NAT / Disable NAT |
| Dynamic DNS (DDNS) |
Yes |
| Ethernet LAN data rates |
2500 Mbit/s |
| IPSec VPN throughput |
1.332 Gbit/s |
| Bluetooth |
Yes |
| Mobile network generation |
Not supported |
| SSL VPN throughput |
0.371 Gbit/s |
| Security |
|---|
| NAT functionality |
Port Forwarding / Virtual Server / DMZ / ALG / UPnP / One-to-One NAT / Disable NAT |
| Security algorithms |
SNMP, SNMPv2, SNMPv3, SSID, PPSK |
| Firewall security |
Yes |
| Access Control List (ACL) |
Yes |
| ARP attack prevention |
Yes |
| Ports & interfaces |
|---|
| WAN connection |
Ethernet (RJ-45) |
| Ethernet LAN (RJ-45) ports |
9 |
| DC-in jack |
Yes |
| Management features |
|---|
| Reset button |
Yes |
| Quality of Service (QoS) support |
Yes |
| Performance management |
Cloud Access • On-Premises Management • Omada App • Omada Guard App |
| Power |
|---|
| Power over Ethernet (PoE) |
Yes |
| Input voltage |
100 - 240 V |
| Input frequency |
50/60 Hz |
| Input current |
4.16 A |
| DC input voltage |
54 V |
| Power consumption (max) |
225 W |
| Power over Ethernet (PoE) type supported |
PoE+ |
| Weight & dimensions |
|---|
| Weight |
29.2 oz (828 g) |
| Width |
5.31" (135 mm) |
| Height |
1.24" (31.5 mm) |
| Depth |
8.9" (226 mm) |
| Technical details |
|---|
| Performance management |
Cloud Access • On-Premises Management • Omada App • Omada Guard App |
| Indication |
|---|
| LED indicators |
Link, PoE |
| Memory |
|---|
| Internal memory type |
DDR4 |
| Internal memory |
4000 MB |
| Display |
|---|
| Touchscreen |
Yes |
| Display type |
LCM |
| Display diagonal |
3.69" |
| Control display unit |
Yes |
