32", VA, 1920 x 1080, 450 cd/m², 4000:1, 16.7 (8bit), 178°/178°
Key Features
- Modern and slim design – robust yet elegant allowing for an unobtrusive integration into any application and environment.
- Secure remote management – control your devices remotely and securely using NEC NaviSet Administrator 2; proactively manage maintenance requirements saving time and resources
- Unhindered readability – no reflections from windows or other light sources means no disruption to the visibility of signage content or meeting room presentation
- Mission-critical 24/7 ready operation – the meticulous selection of industrial-grade components and careful design focused on demanding usage scenarios accompany an impressive and continuous viewer experience.
- Future Ready Connectivity – featuring multiple industry standard digital and analogue signal inputs for flexible integration into AV infrastructures.
Description
Intuitive professional content deliveryFor economical signage in 24/7 commercial environments, the 32” Sharp MultiSync® M322 delivers all the professional performance and features you need, whilst minimising the cost of ownership. With a 450 cd/m2 brightness output and anti-glare panel, the viewer enjoys excellent visual quality unhindered by reflections, with a slim, aesthetic design for unobtrusive integration.
Featuring multiple industry standard digital and analogue signal inputs, the M322 is future-proof for flexible integration. It also features full external control support through both RS-232 or LAN connectivity enabling operators to achieve time and cost savings when managing an estate of displays.
The full metal chassis, high end componentry and integrated schedule function affords peace of mind for extended runtimes, ideal for retail and transportation applications.
Specifications
| Display |
|---|
| LED backlight |
Yes |
| Display diagonal |
32" |
| Display resolution |
1920 x 1080 pixels |
| Display brightness |
550 cd/m² |
| HD type |
Full HD |
| Response time |
8 ms |
| Contrast ratio (typical) |
4000:1 |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Display diagonal (metric) |
31.5" (80 cm) |
| Display number of colours |
16.7 million colors |
| Vertical scan range |
23 - 86 Hz |
| Touchscreen |
No |
| Panel type |
VA |
| Native aspect ratio |
16:9 |
| LED backlighting type |
Direct-LED |
| Horizontal scan range |
26 - 91.1 kHz |
| Display technology |
LCD |
| Haze rate |
28% |
| Ports & interfaces |
|---|
| Ethernet LAN |
Yes |
| HDMI ports quantity |
2 |
| Ethernet LAN data rates |
100 Mbit/s |
| DVI port |
No |
| VGA (D-Sub) input ports |
1 |
| USB connector type |
USB Type-A |
| USB port |
Yes |
| Audio (L/R) out |
1 |
| RS-232 interface |
Yes |
| Wi-Fi |
No |
| USB ports quantity |
4 |
| DisplayPorts quantity |
2 |
| DisplayPorts out |
1 |
| DisplayPorts in |
1 |
| HDMI input ports quantity |
2 |
| Audio |
|---|
| Number of built-in speakers |
2 |
| RMS rated power |
10 W |
| Built-in speaker(s) |
Yes |
| Design |
|---|
| Product design |
Digital signage flat panel |
| Product colour |
Black |
| VESA mounting |
Yes |
| Placement supported |
Indoor |
| Bezel width (top) |
0.465" (1.18 cm) |
| Bezel width (side) |
0.469" (1.19 cm) |
| Bezel width (bottom) |
0.677" (1.72 cm) |
| Screen shape |
Flat |
| Performance |
|---|
| Purpose |
Universal |
| Wi-Fi |
No |
| Power |
|---|
| Power consumption (typical) |
40 W |
| Power consumption (standby) |
0.5 W |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50/60 Hz |
| Input voltage |
100 - 240 V |
| Energy efficiency class (SDR) |
G |
| Energy consumption (SDR) per 1000 hours |
41 kWh |
| Weight & dimensions |
|---|
| Display width |
28.6" (726.5 mm) |
| Display depth |
2.62" (66.5 mm) |
| Display height |
16.7" (425.4 mm) |
| Display weight |
13.9 lbs (6.3 kg) |
| Packaging data |
|---|
| Package width |
34.3" (870 mm) |
| Package depth |
6.3" (160 mm) |
| Package height |
20.7" (527 mm) |
| Package weight |
21.6 lbs (9.8 kg) |
| Remote control included |
Yes |
| Cables included |
AC |
| Packaging content |
|---|
| Remote control included |
Yes |
| Cables included |
AC |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Storage temperature (T-T) |
-20 - 60 °C |
| Storage relative humidity (H-H) |
10 - 80% |
| Network |
|---|
| Ethernet LAN |
Yes |
| Ethernet LAN data rates |
100 Mbit/s |
| Wi-Fi |
No |
| Technical details |
|---|
| USB connector type |
USB Type-A |
| Panel type |
VA |
| LED backlighting type |
Direct-LED |
| DisplayPorts out |
1 |
| DisplayPorts in |
1 |
| Other features |
|---|
| USB connector type |
USB Type-A |
| Wi-Fi |
No |
| Panel type |
VA |
| DisplayPorts out |
1 |
| DisplayPorts in |
1 |
| Display technology |
LCD |
| Bezel width (top) |
0.465" (1.18 cm) |
| Bezel width (side) |
0.469" (1.19 cm) |
| Bezel width (bottom) |
0.677" (1.72 cm) |
