55" OMN-S Series FHD Window Signage Display OM55N-S
Key Features
- Present bright content on a dual-display
- Modernize space with flexible design
- Maximize operational efficiency
Description
Present bright content on a dual-displayDual-display, double the impact. Engineered to enhance multiple environments, maintaining picture integrity on the window-facing side even in direct sunlight, while delivering information concisely in-store for comprehensive customer engagement.
Modernize space with flexible designChoose the position of your display with multiple installation options, complementing any environment with a flexible, smart design.
Maximize operational efficiencyA double-sided display allows content on both sides, all powered by just one electric power cord and one LAN cable for minimal clutter and maximized energy efficiency.
Streamline content managementThe OMN-DS series’ embedded MagicINFO Player S7, backed by the powerful TIZEN operating system, boosts the display’s overall performance, allowing for easy content management and ensuring seamless content transition and playback.
Durable PerformanceWith IP5X-validated dust protection and embedded, proprietary functionality that mitigates overheating, the OMN-DS series continuously provides robust durability.
Clean Cable ConfigurationConnectivity cover keeps connections clean and organized. Embedded Wi-Fi also allows for updates without the need for any additional messy cables.
Specifications
| Display |
|---|
| Display diagonal |
55" |
| Display resolution |
1920 x 1080 pixels |
| Display brightness |
3000 cd/m² |
| HD type |
Full HD |
| Response time |
6 ms |
| Contrast ratio (typical) |
6000:1 |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Pixel pitch |
0.0248 x 0.0248" (0.63 x 0.63 mm) |
| Dynamic contrast ratio marketing name |
Mega Contrast |
| Vertical scan range |
24 - 75 Hz |
| Touchscreen |
No |
| Panel type |
VA |
| Horizontal scan range |
15 - 135 kHz |
| Display technology |
LCD |
| Colour gamut |
72% |
| RGB colour space |
NTSC |
| Pixel frequency (max) |
594 MHz |
| Ports & interfaces |
|---|
| Ethernet LAN |
Yes |
| HDMI ports quantity |
2 |
| HDMI version |
2.0 |
| DVI port |
No |
| Remote (IR) input |
1 |
| USB port |
Yes |
| Ethernet LAN (RJ-45) ports |
1 |
| RS-232 interface |
Yes |
| Wi-Fi |
Yes |
| USB ports quantity |
2 |
| Infrared data port |
Yes |
| DisplayPorts quantity |
0 |
| Design |
|---|
| Product design |
Digital signage flat panel |
| Product colour |
Black |
| Placement supported |
Indoor/outdoor |
| Orientation |
Vertical |
| Bezel width (top) |
0.898" (2.28 cm) |
| Bezel width (side) |
0.898" (2.28 cm) |
| Bezel width (bottom) |
0.898" (2.28 cm) |
| Certification |
Class A
60950-1 |
| Screen shape |
Flat |
| Performance |
|---|
| Purpose |
Universal |
| HDCP |
Yes |
| HDCP version |
2.2 |
| Wi-Fi |
Yes |
| Power |
|---|
| Power consumption (typical) |
500 W |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50 - 60 Hz |
| Power consumption (sleep) |
0.5 W |
| Computer system |
|---|
| Operating system installed |
Tizen 5.0 |
| Computer system |
Yes |
| Computer system type |
System on Chip (SoC) |
| Built-in processor |
Yes |
| Weight & dimensions |
|---|
| Display width |
28.6" (726.8 mm) |
| Display depth |
2.74" (69.5 mm) |
| Display height |
51.1" (1299 mm) |
| Display weight |
92.6 lbs (42 kg) |
| Packaging data |
|---|
| Package width |
37" (940 mm) |
| Package depth |
14.4" (367 mm) |
| Package height |
57.7" (1466 mm) |
| Package volume |
52000 cm³ |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Operating relative humidity (H-H) |
10 - 80% |
| Certificates |
|---|
| Certification |
Class A
60950-1 |
| Thin Client |
|---|
| Operating system installed |
Tizen 5.0 |
| Technical details |
|---|
| RS-232 input ports |
1 |
| Panel type |
VA |
| Other features |
|---|
| Wi-Fi |
Yes |
| RS-232 input ports |
1 |
| Panel type |
VA |
| Flash memory |
8000 MB |
| Display technology |
LCD |
| Bezel width (top) |
0.898" (2.28 cm) |
| Bezel width (side) |
0.898" (2.28 cm) |
| Bezel width (bottom) |
0.898" (2.28 cm) |
