4K, 86", 600 cd/m², 8ms, ADS, 20RMS
Description
Philips Signage 5000 SeriesGo beyond the ordinary. Captivate audiences and elevate their experience with the Philips Signage 5000. Powered by Android 14 for smooth integrations, this versatile 24/7 display steps up to deliver exceptional performance in any setting.
24/7 – working for your content around the clock.With 500 cd/m2 brightness for better visibility under bright lights or even in sunlight, the Philips Signage 5000 Series is designed to be used 24/7, making it a great selection for travel and transportation hubs, retail centres, food and beverage locations, and more.
Install in portrait or landscape orientations.Extend your display into the future with our modular approach. Bringing opportunities for longer product lifetime with easily detached and replaced components, plus a firm focus on sustainability, with reduced WEEE disposal.
Android 14 professional System on Chip.Powered by Android 14, your Philips Signage 5050 display is designed on a professional platform with trusted connectivity and security built in. Optimised for native Android apps, it enables you to install web apps and software directly onto the display, eliminating the need for an external media player.
Integrated HTML5 Chromium-based browser.Connect and control your content via the cloud with our integrated HTML5, Chromium-based browser. Design your content online and connect a single display, or your entire network, either landscape or portrait. Simply connect to the Internet via an RJ45 cable.
Philips Wave ready for remote device management.Unlock the power, versatility and intelligence inside your Philips Signage 5000 displays remotely with Wave. This evolutionary cloud platform puts you fully in control, with simplified installation and setup, monitoring and controlling displays, upgrading firmware, managing playlists and setting power schedules, saving you time, energy and environmental impact.
Specifications
| Display |
|---|
| Display diagonal |
86" |
| Display resolution |
3840 x 2160 pixels |
| Display brightness |
600 cd/m² |
| HD type |
Full HD |
| Response time |
8 ms |
| Contrast ratio (typical) |
1200:1 |
| Contrast ratio (dynamic) |
500000:1 |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Pixel pitch |
0.0112 x 0.0112" (0.285 x 0.285 mm) |
| Display diagonal (metric) |
49.5" (125.7 cm) |
| Display number of colours |
1.07 billion colors |
| Panel type |
VA |
| Native aspect ratio |
16:9 |
| Display technology |
LCD |
| Haze rate |
25% |
| Ports & interfaces |
|---|
| Ethernet LAN |
Yes |
| HDMI ports quantity |
2 |
| HDMI version |
2.0 |
| USB connector type |
Micro-USB B, USB Type-C |
| Remote (IR) output |
1 |
| Remote (IR) input |
1 |
| USB port |
Yes |
| Ethernet LAN (RJ-45) ports |
1 |
| RS-232 interface |
Yes |
| Wi-Fi |
Yes |
| USB version |
2.0/3.2 Gen 2 (3.1 Gen 2) |
| USB ports quantity |
1 |
| RS-232C |
Yes |
| DisplayPorts quantity |
1 |
| DisplayPort version |
1.4 |
| Number of antenna connectors |
1 |
| Audio |
|---|
| Number of built-in speakers |
2 |
| RMS rated power |
20 W |
| Built-in speaker(s) |
Yes |
| Design |
|---|
| Product colour |
Black |
| VESA mounting |
Yes |
| Panel mounting interface |
100 x 100,200 x 200 mm |
| Bezel width (top) |
0.587" (1.49 cm) |
| Bezel width (side) |
0.587" (1.49 cm) |
| Bezel width (bottom) |
0.587" (1.49 cm) |
| Performance |
|---|
| On Screen Display (OSD) languages |
Arabic, Simplified Chinese, Traditional Chinese, Danish, German, Dutch, English, Spanish, Finnish, French, Italian, Japanese, Norwegian, Polish, Portuguese, Russian, Swedish, Turkish |
| On Screen Display (OSD) |
Yes |
| Number of OSD languages |
18 |
| Mean time between failures (MTBF) |
50000 h |
| Wi-Fi |
Yes |
| Power |
|---|
| AC input voltage |
100 - 240 V |
| AC input frequency |
50/60 Hz |
| Energy efficiency class (SDR) |
F |
| Computer system |
|---|
| Processor model |
A53 |
| Operating system installed |
Android |
| Computer system |
Yes |
| Computer system type |
System on Chip (SoC) |
| Internal memory |
4 GB |
| Processor cores |
8 |
| Internal storage capacity |
32 GB |
| Video formats supported |
AVI, H.263, H.264, H.265, MP4, MPEG, MPEG4, VP8, WEBM |
| Audio formats supported |
AAC, HEAAC / MPEG |
| Image formats supported |
BMP, JPEG, PNG |
| Processor manufacturer |
ARM |
| Built-in processor |
Yes |
| On-board graphics card model |
Mali-G52 MC3 |
| Operating system version |
14 |
| Weight & dimensions |
|---|
| Display width |
75.9" (1929 mm) |
| Display height |
43.3" (1100 mm) |
| Display weight |
106.5 lbs (48.3 kg) |
| Packaging content |
|---|
| Cables included |
AC, IR sensor, RS-232 |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Storage temperature (T-T) |
-20 - 60 °C |
| Storage relative humidity (H-H) |
5 - 95% |
| Network |
|---|
| Ethernet LAN |
Yes |
| Wi-Fi |
Yes |
| Thin Client |
|---|
| Processor model |
A53 |
| Operating system installed |
Android |
| Internal memory |
4 GB |
| Internal storage capacity |
32 GB |
| Video formats supported |
AVI, H.263, H.264, H.265, MP4, MPEG, MPEG4, VP8, WEBM |
| Audio formats supported |
AAC, HEAAC / MPEG |
| Image formats supported |
BMP, JPEG, PNG |
| Packaging data |
|---|
| Cables included |
AC, IR sensor, RS-232 |
| Technical details |
|---|
| USB connector type |
Micro-USB B, USB Type-C |
| Panel type |
VA |
| DisplayPort version |
1.4 |
| Compliance certificates |
CB, CE, RoHS |
| Other features |
|---|
| USB connector type |
Micro-USB B, USB Type-C |
| Wi-Fi |
Yes |
| Panel type |
VA |
| Mean time between failures (MTBF) |
50000 h |
| DisplayPort version |
1.4 |
| Display technology |
LCD |
| Bezel width (top) |
0.587" (1.49 cm) |
| Bezel width (side) |
0.587" (1.49 cm) |
| Bezel width (bottom) |
0.587" (1.49 cm) |
