65" 4K 3840 x 2160, ADS / Direct-LED, 16:9, 8ms, 1200:1, HDMI, USB, DisplayPort, 170W, 110-240V, 50/60Hz
Key Features
- High image quality and high legibility suitable for various scenes
- Superb Reliability & Easy Installation
- Various external linkage suitable for conference room and signage applications
Description
The Panasonic Connect TH-SQE2 Series 4K Professional Display is designed for 24-hour continuous operation and crystal-clear viewing clarity. The display provides a brightness of 500cd/m² with an anti-glare panel, and minimum haze treatment of 25%, reducing the reflection of ambient light and vastly improving visibility in all environments. For ultimate flexibility and a clean look without set-top-boxes or cables, the TH-SQE2 Series is also equipped with a slot for the Intel® SDM specification supporting applications, such as digital signage and broadcasts, using a built-in PC, terminal board, or wireless presentation system.
Specifications
| Display |
| LED backlight |
Yes |
| Display diagonal |
65" |
| Display resolution |
3840 x 2160 pixels |
| Display brightness |
500 cd/m² |
| HD type |
4K Ultra HD |
| Response time |
8 ms |
| Contrast ratio (typical) |
1200:1 |
| Contrast ratio (dynamic) |
50000:1 |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Active display area (W x H) |
56.2 x 31.6" (1428.4 x 803.5 mm) |
| Display diagonal (metric) |
64.5" (163.9 cm) |
| Display number of colours |
1.07 billion colors |
| Panel life |
50000 h |
| Touchscreen |
No |
| Panel type |
ADS |
| Native aspect ratio |
16:9 |
| LED backlighting type |
Direct-LED |
| Display technology |
LCD |
| Anti-glare screen |
Yes |
| Haze rate |
25% |
| Ports & interfaces |
| Ethernet LAN |
Yes |
| HDMI ports quantity |
5 |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| DVI port |
No |
| USB connector type |
USB Type-A, USB Type-C |
| Remote (IR) input |
1 |
| USB port |
Yes |
| Audio (L/R) out |
1 |
| Ethernet LAN (RJ-45) ports |
1 |
| RS-232 interface |
Yes |
| Wi-Fi standards |
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Wi-Fi |
Yes |
| USB version |
2.0/3.2 Gen 1 (3.1 Gen 1) |
| USB ports quantity |
3 |
| RS-232C |
Yes |
| DisplayPorts quantity |
1 |
| Compatible memory cards |
MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Card reader integrated |
Yes |
| HDMI input ports quantity |
4 |
| HDMI output ports quantity |
1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
1 |
| USB Type-C DisplayPort Alternate Mode |
Yes |
| Audio |
| Number of built-in speakers |
2 |
| RMS rated power |
20 W |
| Built-in speaker(s) |
Yes |
| Bluetooth audio |
Yes |
| Design |
| Product design |
Digital signage flat panel |
| Product colour |
Black |
| VESA mounting |
Yes |
| Panel mounting interface |
600 x 400 mm |
| Placement supported |
Indoor |
| Orientation |
Horizontal/Vertical |
| Anti-glare screen |
Yes |
| Screen shape |
Flat |
| Performance |
| Purpose |
Universal |
| HDCP |
Yes |
| HDCP version |
2.2 |
| Panel life |
50000 h |
| Wi-Fi |
Yes |
| Power |
| Power consumption (typical) |
170 W |
| Power consumption (standby) |
0.5 W |
| AC input voltage |
110 - 240 V |
| AC input frequency |
50 - 60 Hz |
| Energy efficiency scale |
A to G |
| Energy efficiency class (SDR) |
G |
| Weight & dimensions |
| Display width |
57.3" (1456 mm) |
| Display depth |
3.78" (96 mm) |
| Display height |
33.6" (853 mm) |
| Display weight |
54.9 lbs (24.9 kg) |
| Packaging data |
| Package width |
63.3" (1607 mm) |
| Package depth |
6.97" (177 mm) |
| Package height |
38.6" (980 mm) |
| Package weight |
79.4 lbs (36 kg) |
| Remote control included |
Yes |
| Cables included |
AC |
| Packaging content |
| Remote control included |
Yes |
| Cables included |
AC |
| Technical details |
| USB connector type |
USB Type-A, USB Type-C |
| Panel type |
ADS |
| LED backlighting type |
Direct-LED |
| HDCP 2.2 |
Yes |
| Other features |
| USB connector type |
USB Type-A, USB Type-C |
| Wi-Fi standards |
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Wi-Fi |
Yes |
| Panel type |
ADS |
| Display technology |
LCD |
| Compatible memory cards |
MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Card reader integrated |
Yes |
| Bluetooth version |
5.1 |
| Bluetooth |
Yes |
| Energy efficiency scale |
A to G |
