86", 3840 × 2160 (UHD), 16:9, 500 nits, HDMI, RJ45, RS232C, USB, Wi-Fi, Internal Memory 16GB, webOS 8.0, IP5X
Key Features
- Resolution : 3,840 × 2,160 (UHD)
- Brightness : 500 nits (Typ.)
- Bezel Width : 13.4 mm (Even)
- webOS Smart Platform
- LG Shield
Description
Superb Picture Quality with Ultra HD ResolutionWith the resolution of UHD, it makes the colors and details of the content vivid and realistic. In addition, the wide viewing angle provides clear content.
Convenient webOS PlatformThe UH5Q is equipped with a high-performance SoC that allows for multiple tasks to be performed without a separate media player. The webOS platform provides app development tools with an intuitive UI that enhances user convenience, and includes webOS partner apps to create an SI-friendly environment.
Durability that Provides ReliabilityOptimized for business environments, the UH5Q is protected against salt, dust, iron powder and humidity thanks to conformal partial coating on power board, allowing for stable operation. Also, its customer-centric features, such as IP5x and Shock Monitoring*, provide both reliability and satisfaction.
Comprehensive SecuritywebOS Signage goes beyond security measures at the operating system (OS) level. LG Shield employs a five-tiered defense system, encompassing server, application, operating system, system, and hardware. Each layer operates independently, providing comprehensive protection against various threats. Also, the webOS platform supports ETSI EN 303 645.
SuperSign SolutionsSuperSign is an integrated and intuitive content management solution for creative and organized digital signage content in your space, connecting customers to a range of services with convenient user experiences. There are a variety of versions such as SuperSign Cloud, so discover and enjoy the version that best fits you.
Specifications
| Display |
|---|
| LED backlight |
Yes |
| Display diagonal |
86" |
| Display resolution |
3840 x 2160 pixels |
| Display brightness |
700 cd/m² |
| HD type |
4K Ultra HD |
| Response time |
8 ms |
| Contrast ratio (typical) |
1200:1 |
| Contrast ratio (dynamic) |
1000000:1 |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Display number of colours |
1.07 billion colors |
| Touchscreen |
No |
| Panel type |
ADS |
| Native aspect ratio |
16:9 |
| LED backlighting type |
Edge-LED |
| Rated lifetime |
50000 h |
| Native refresh rate |
60 Hz |
| Haze rate |
25% |
| Ports & interfaces |
|---|
| Ethernet LAN |
Yes |
| HDMI ports quantity |
3 |
| HDMI version |
2.2/1.4 |
| USB connector type |
Mini-USB A |
| Remote (IR) input |
1 |
| USB port |
Yes |
| Ethernet LAN (RJ-45) ports |
1 |
| Wi-Fi |
Yes |
| USB version |
2.0 |
| USB ports quantity |
2 |
| RS-232C |
Yes |
| DisplayPorts quantity |
1 |
| HDMI input ports quantity |
3 |
| Audio |
|---|
| Number of built-in speakers |
2 |
| RMS rated power |
20 W |
| Built-in speaker(s) |
Yes |
| Design |
|---|
| Product design |
Digital signage flat panel |
| Product colour |
Black |
| VESA mounting |
Yes |
| Panel mounting interface |
600 x 400 mm |
| Placement supported |
Indoor/outdoor |
| Orientation |
Horizontal/Vertical |
| Screen shape |
Flat |
| Performance |
|---|
| Purpose |
Commercial |
| Operating hours (hours/days) |
24/7 |
| International Protection (IP) code |
IP5X |
| On Screen Display (OSD) languages |
English, French, German, Spanish, Italian, Korean, Simplified Chinese, Traditional Chinese, Portuguese, Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Dutch, Czech, Greek, Turkish, Arabic |
| On Screen Display (OSD) |
Yes |
| HDCP |
Yes |
| webRTC support |
Yes |
| Screen sharing |
Yes |
| Wi-Fi |
Yes |
| Power |
|---|
| Power consumption (typical) |
205 W |
| AC input voltage |
100-240 V |
| AC input frequency |
50/60 Hz |
| Power consumption (off) |
0.5 W |
| Power consumption (max) |
297 W |
| Heat generation (typical) |
699 BTU/h |
| Heat generation (max) |
1013 BTU/h |
| Computer system |
|---|
| Operating system installed |
WebOS |
| Internal memory |
16 GB |
| Operating system version |
8.0 |
| Weight & dimensions |
|---|
| Display width |
75.9" (1928.8 mm) |
| Display depth |
1.17" (29.7 mm) |
| Display height |
43.3" (1099.8 mm) |
| Display weight |
116.8 lbs (53 kg) |
| Packaging data |
|---|
| Package width |
82.7" (2100 mm) |
| Package depth |
9.96" (253 mm) |
| Package height |
49.2" (1250 mm) |
| Package weight |
147 lbs (66.7 kg) |
| Remote control included |
Yes |
| Cables included |
Power |
| Packaging content |
|---|
| Remote control included |
Yes |
| Cables included |
Power |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Operating relative humidity (H-H) |
10 - 80% |
| Network |
|---|
| Ethernet LAN |
Yes |
| Wi-Fi |
Yes |
| Thin Client |
|---|
| Operating system installed |
WebOS |
| Internal memory |
16 GB |
| Sensors |
|---|
| Gyroscope |
Yes |
| Temperature sensor |
Yes |
| Features |
|---|
| Wall mountable |
Yes |
| Technical details |
|---|
| USB connector type |
Mini-USB A |
| Panel type |
ADS |
| LED backlighting type |
Edge-LED |
| Other features |
|---|
| USB connector type |
Mini-USB A |
| Wi-Fi |
Yes |
| Power consumption (max) |
297 W |
| Panel type |
ADS |
