55", 4K UHD (3840 x 2160), IPS, 500 nit, 8 ms, IP5X, SoC, Wi-Fi, PIP, PBP, Pro:Idiom, Beacon, Control Manager, SuperSign CMS, webOS 6.0
Key Features
- Resolution : 3,840 x 2,160 (UHD)
- Brightness (Typ.) : 500 nit
- EPEAT (US Only)
- Bezel Width : 12.4 mm (T/B), 11.4 mm (R/L)
- Interface : HDMI(3) / DP / USB 2.0 / RS232C / RJ45 / Audio / IR
Description
Specifications
| Display |
|---|
| LED backlight |
Yes |
| Display diagonal |
55" |
| Display resolution |
3840 x 2160 pixels |
| Display brightness |
500 cd/m² |
| HD type |
4K Ultra HD |
| Response time |
8 ms |
| Contrast ratio (typical) |
1100:1 |
| Contrast ratio (dynamic) |
1000000:1 |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Display number of colours |
1.07 billion colors |
| Panel life |
50000 h |
| Touchscreen |
No |
| Panel type |
IPS |
| Native aspect ratio |
16:9 |
| LED backlighting type |
Direct-LED |
| Display technology |
LCD |
| Colour gamut |
95% |
| Colour depth |
10 bit |
| Native refresh rate |
60 Hz |
| Haze rate |
28% |
| Ports & interfaces |
|---|
| Ethernet LAN |
Yes |
| HDMI ports quantity |
4 |
| DVI port |
No |
| USB connector type |
USB Type-A |
| Remote (IR) input |
1 |
| USB port |
Yes |
| Ethernet LAN (RJ-45) ports |
1 |
| Wi-Fi |
Yes |
| USB version |
2.0 |
| USB ports quantity |
1 |
| RS-232C |
Yes |
| DisplayPorts quantity |
1 |
| HDMI input ports quantity |
3 |
| HDMI output ports quantity |
1 |
| Audio |
|---|
| Built-in speaker(s) |
Yes |
| Design |
|---|
| Product design |
Digital signage flat panel |
| Product colour |
Black |
| VESA mounting |
Yes |
| Panel mounting interface |
300 x 300 mm |
| Placement supported |
Indoor |
| Orientation |
Horizontal/Vertical |
| Bezel width (top) |
0.488" (1.24 cm) |
| Bezel width (side) |
0.449" (1.14 cm) |
| Bezel width (bottom) |
0.488" (1.24 cm) |
| Performance |
|---|
| Purpose |
Universal |
| Operating hours (hours/days) |
24/7 |
| International Protection (IP) code |
IP5X |
| Picture-in-Picture |
Yes |
| On Screen Display (OSD) |
Yes |
| HDCP |
Yes |
| Automatic brightness control |
Yes |
| Plug and Play |
Yes |
| HDCP version |
1.4/2.2/2.3 |
| Panel life |
50000 h |
| Wi-Fi |
Yes |
| Power |
|---|
| Power consumption (typical) |
130 W |
| Power consumption (standby) |
0.5 W |
| AC input voltage |
100-240 V |
| AC input frequency |
50-60 Hz |
| Power consumption (max) |
180 W |
| Computer system |
|---|
| Operating system installed |
WebOS |
| Computer system |
Yes |
| Computer system type |
System on Chip (SoC) |
| Internal memory |
16 GB |
| Operating system version |
6.0 |
| Weight & dimensions |
|---|
| Display width |
48.7" (1237 mm) |
| Display depth |
2.27" (57.7 mm) |
| Display height |
28" (710 mm) |
| Display weight |
31.3 lbs (14.2 kg) |
| Packaging data |
|---|
| Package width |
53.5" (1360 mm) |
| Package depth |
6.38" (162 mm) |
| Package height |
31.9" (810 mm) |
| Package weight |
41.7 lbs (18.9 kg) |
| Remote control included |
Yes |
| Cables included |
AC, Phone |
| Batteries included |
Yes |
| Packaging content |
|---|
| Remote control included |
Yes |
| Cables included |
AC, Phone |
| Batteries included |
Yes |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Operating relative humidity (H-H) |
10 - 80% |
| Network |
|---|
| Ethernet LAN |
Yes |
| Wi-Fi |
Yes |
| Thin Client |
|---|
| Operating system installed |
WebOS |
| Internal memory |
16 GB |
| Technical details |
|---|
| USB connector type |
USB Type-A |
| Panel type |
IPS |
| LED backlighting type |
Direct-LED |
| Real Time Clock (RTC) |
Yes |
| Other features |
|---|
| USB connector type |
USB Type-A |
| Wi-Fi |
Yes |
| Power consumption (PowerSave) |
91 W |
| Power consumption (max) |
180 W |
| Panel type |
IPS |
| Display technology |
LCD |
| Bezel width (top) |
0.488" (1.24 cm) |
| Bezel width (side) |
0.449" (1.14 cm) |
| Bezel width (bottom) |
0.488" (1.24 cm) |
| Audio output |
1 |
| Plug and Play |
Yes |
