55”, 3,840 x 2,160 (4K UHD), 500 nits (Typ.), ADS, 60 Hz, DCI 80%, 178 × 178, 10 W × 2

Key Features

• Resolution : 3,840 × 2,160 (UHD)
• Brightness : 500 nit (Typ.)
• 24Hr Usage Scene (24 Hours / 7 Days)
• Even Bezel
• High-Performance with webOS 6.1

Description

LG webOS UHD Signage for 24/7 Operation

Superb Picture Quality with Ultra HD Resolution
The UL5Q-M series, with UHD resolution, enhances the realism of colors and details in the content. Its wide viewing angle offers clear visuals, while its 500-nit brightness vividly showcases the content.

High-Performance with LG webOS 6.1
LG webOS 6.1 is available on the UL5Q-M series for smooth execution of multiple tasks. The LG webOS smart signage platform enhances user convenience with an intuitive GUI*.

Even Bezel Design
The UL5Q-M series features even bezels, enhancing the aesthetic appeal of various spaces. These uniform bezels not only facilitate easy installation but also transform standard displays into elegant focal points.

Adaptive Viewing Experience
Experience the flexibility with the UL5Q-M series’ up/down tilt capability. Whether mounted high or low, the display can be adjusted to eye level, offering viewer engagement regardless of installation height. This versatility not only enhances spatial efficiency but also provides visual comfort, delivering clear information from various viewing angles.

Engineered for 24/7 Operation
Built for environments that never sleep, the UL5Q-M series features panel technology that enables 24/7 operation.

* The UL5Q-M series includes the same standard warranty period as other signage models and offers an optional extended warranty, providing coverage for up to 5 years in total. If the extended warranty is purchased, coverage ends when either 50,000 hours of usage is reached or the 5-year period expires, whichever comes first.

Built-In Brightness Sensor
The UL5Q-M series’ front-mounted brightness sensor automatically adjusts brightness to match various lighting conditions, optimizing viewing quality and energy efficiency without manual intervention. This adaptive feature offers consistent display performance while also supporting power optimization, delivering a visual experience that dynamically responds to environmental changes.

Advanced Security Architecture
The UL5Q-M series incorporates LG’s Enhanced Kernel Protection (EKP) technology, safeguarding critical data from unauthorized access and potential security threats. This commitment to information security is validated by the ISO/IEC 15408 Common Criteria EAL2 certification, providing businesses with the confidence that their sensitive content and operations remain protected in today’s challenging security landscape.

Remote Monitoring and Control
This web-based monitoring solution is user-friendly and allows the user to be at ease. It enables the user to have full access anytime, anywhere from their mobile phone & PC in a network-accessible environment, with access to both current and past data. It allows the user to monitor the unit, make adjustments, and control the unit remotely in real time.

EPEAT Registered
The Electronic Product Environmental Assessment Tool (EPEAT) is a method for several layers of customers to evaluate the effect of a product on the environment. UL5Q-M series is an EPEAT Bronze-certified* display which means that it meets all the required criteria in the Computers and Displays category.

LG ConnectedCare
Maintenance is easy and fast with the optional LG ConnectedCare* service, a cloud service solution provided by LG. It remotely manages the status of displays in client workplaces for fault diagnosis and remote-control services, supporting the stable operation of clients’ businesses.

* The availability of the ‘LG ConnectedCare’ service differs by region, and it needs to be purchased separately. So please contact the LG sales representative in your region for more details.

Specifications

Display
Display diagonal	55"
Display resolution	3840 x 2160 pixels
Display brightness	500 cd/m²
HD type	4K Ultra HD
Response time	8 ms
Contrast ratio (typical)	1200:1
Contrast ratio (dynamic)	1000000:1
Viewing angle, horizontal	178°
Viewing angle, vertical	178°
Display number of colours	1.07 billion colors
Touchscreen	No
Panel type	ADS
Native aspect ratio	16:9
Display technology	LED
Colour saturation	80%
Rated lifetime	50000 h
Native refresh rate	60 Hz
Haze rate	1%
Ports & interfaces
Ethernet LAN	Yes
HDMI ports quantity	3
HDMI version	2.2/1.4
DVI port	No
USB connector type	USB Type-A
USB port	Yes
Ethernet LAN (RJ-45) ports	1
Wi-Fi	Yes
USB version	2.0
USB ports quantity	2
RS-232C	Yes
PC Audio out	Yes
Audio
Number of built-in speakers	2
RMS rated power	20 W
Built-in speaker(s)	Yes
Design
Product design	Digital signage flat panel
Product colour	Black
VESA mounting	Yes
Panel mounting interface	300 x 300 mm
Placement supported	Indoor
Orientation	Horizontal/Vertical
Bezel width (top)	0.425" (1.08 cm)
Bezel width (side)	0.425" (1.08 cm)
Bezel width (bottom)	0.425" (1.08 cm)
Bezel colour	Black
Performance
Purpose	Commercial
Operating hours (hours/days)	24/7
On Screen Display (OSD) languages	Arabic, Simplified Chinese, Traditional Chinese, Czech, Danish, German, Dutch, English, Spanish, Finnish, French, Greek, Italian, Japanese, Korean, Norwegian, Polish, Portuguese, Russian, Swedish, Turkish
Web browser	Yes
webRTC support	Yes
Wi-Fi	Yes
Power
Power consumption (typical)	124 W
Power consumption (standby)	0.5 W
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power consumption (off)	0.5 W
Energy efficiency class (SDR)	G
Energy efficiency class (HDR)	Not available
Energy consumption (SDR) per 1000 hours	126 kWh
Computer system
Operating system installed	WebOS
Internal memory	8 GB
Operating system version	6.1
Weight & dimensions
Display width	48.6" (1234.2 mm)
Display depth	23.2" (589 mm)
Display height	27.8" (706.7 mm)
Display weight	26.5 lbs (12 kg)
Packaging data
Package width	54.3" (1380 mm)
Package depth	32.5" (825 mm)
Package height	4.65" (118 mm)
Package weight	34 lbs (15.4 kg)
Remote control included	Yes
Cables included	Power
Packaging content
Remote control included	Yes
Cables included	Power
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80%
Network
Ethernet LAN	Yes
Wi-Fi	Yes
Thin Client
Operating system installed	WebOS
Internal memory	8 GB
Sensors
Gyroscope	Yes
Temperature sensor	Yes
Technical details
USB connector type	USB Type-A
Power supply type	Internal
Panel type	ADS
Compliance certificates	CB, CE, Electromagnetic Compatibility (EMC), Federal Communications Commission (FCC)
Other features
USB connector type	USB Type-A
Power supply type	Internal
Wi-Fi	Yes
PC Audio out	Yes
Panel type	ADS
Display technology	LED
Bezel width (top)	0.425" (1.08 cm)
Bezel width (side)	0.425" (1.08 cm)
Bezel width (bottom)	0.425" (1.08 cm)
