75", 4K 3840 x 2160 (UHD), 8ms (G to G), ADS, 60Hz, BT709 95%, 500nit, 16:9, 178º x 178º, 1200:1, 1.07 B, 50000H, 24/7, 16GB eMMC, SoC, 3x HDMI, RJ-45, HDCP 2.2/1.4, 2x USB 2.0 Type-A, RS232C, 10W x 2, Wi-Fi/BT, 0 °C to 40 °C, 100 - 240V, 50/60Hz, 160W, Black

Key Features

• Resolution : 3,840 × 2,160 (UHD)
• Brightness : 500 nits (Typ.)
• Bezel Width : 12.9 mm (Even)
• webOS Smart Platform
• LG Shield

Description

Large UHD Signage Display with LG webOS Platform and Advanced Security

Superb Picture Quality with Ultra HD Resolution
With the resolution of UHD, it makes the colors and details of the content vivid and realistic. In addition, the wide viewing angle provides clear content.

Convenient webOS Platform
The UH5Q is equipped with a high-performance SoC that allows for multiple tasks to be performed without a separate media player. The webOS platform provides app development tools with an intuitive UI that enhances user convenience, and includes webOS partner apps to create an SI-friendly environment.

Durability that Provides Reliability
Optimized for business environments, the UH5Q is protected against salt, dust, iron powder and humidity thanks to conformal partial coating on power board, allowing for stable operation. Also, its customer-centric features, such as IP5x and Shock Monitoring*, provide both reliability and satisfaction.

Comprehensive Security
webOS Signage goes beyond security measures at the operating system (OS) level. LG Shield employs a five-tiered defense system, encompassing server, application, operating system, system, and hardware. Each layer operates independently, providing comprehensive protection against various threats. Also, the webOS platform supports ETSI EN 303 645.

SuperSign Solutions
SuperSign is an integrated and intuitive content management solution for creative and organized digital signage content in your space, connecting customers to a range of services with convenient user experiences. There are a variety of versions such as SuperSign Cloud, so discover and enjoy the version that best fits you.

Specifications

Display
LED backlight	Yes
Display diagonal	75"
Display resolution	3840 x 2160 pixels
Display brightness	500 cd/m²
HD type	4K Ultra HD
Response time	8 ms
Contrast ratio (typical)	1200:1
Contrast ratio (dynamic)	1000000:1
Viewing angle, horizontal	178°
Viewing angle, vertical	178°
Display number of colours	1.07 billion colors
Panel life	50000 h
Touchscreen	No
Supported video modes	2160p
Supported graphics resolutions	3840 x 2160
Panel type	ADS
Native aspect ratio	16:9
LED backlighting type	Edge-LED
Colour gamut	95%
Native refresh rate	60 Hz
Haze rate	25%
Ports & interfaces
Ethernet LAN	Yes
HDMI ports quantity	3
DVI port	No
USB connector type	USB Type-A
USB port	Yes
Ethernet LAN (RJ-45) ports	1
Wi-Fi	Yes
USB version	2.0
USB ports quantity	2
RS-232C	Yes
DisplayPorts quantity	1
Consumer Electronics Control (CEC)	Yes
Audio
Number of built-in speakers	2
RMS rated power	20 W
Built-in speaker(s)	Yes
Design
Product design	Digital signage flat panel
Product colour	Black
VESA mounting	Yes
Panel mounting interface	600 x 400 mm
Placement supported	Indoor
Orientation	Horizontal/Vertical
Bezel width (top)	0.508" (1.29 cm)
Bezel width (side)	0.508" (1.29 cm)
Bezel width (bottom)	0.508" (1.29 cm)
Mounting type	Wall
Screen shape	Flat
Performance
Purpose	Commercial
Operating hours (hours/days)	24/7
International Protection (IP) code	IP5X
Picture-in-Picture	Yes
On Screen Display (OSD) languages	Multi
On Screen Display (OSD)	Yes
HDCP	Yes
Automatic brightness control	Yes
Plug and Play	Yes
HDCP version	1.4/2.2
Security algorithms	SNMP
Digital Rights Management (DRM) type	Pro:Idiom
webRTC support	Yes
Panel life	50000 h
Wi-Fi	Yes
Power
Power consumption (typical)	160 W
Power consumption (standby)	0.5 W
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power consumption (off)	0.5 W
Power consumption (max)	247 W
Heat generation (typical)	546 BTU/h
Heat generation (max)	843 BTU/h
Computer system
Operating system installed	WebOS
Computer system	Yes
Computer system type	System on Chip (SoC)
Internal memory	16 GB
Operating system version	8.0
Weight & dimensions
Display width	66.1" (1679.5 mm)
Display depth	1.17" (29.7 mm)
Display height	37.7" (958.7 mm)
Display weight	78.7 lbs (35.7 kg)
Packaging data
Package width	71.7" (1820 mm)
Package depth	7.87" (200 mm)
Package height	43.9" (1115 mm)
Package weight	97 lbs (44 kg)
Remote control included	Yes
Quick start guide	Yes
Cables included	Power
Packaging content
Remote control included	Yes
Quick start guide	Yes
Cables included	Power
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80%
Network
Ethernet LAN	Yes
Wi-Fi	Yes
Security algorithms	SNMP
Wake-on-LAN	Yes
Thin Client
Operating system installed	WebOS
Internal memory	16 GB
Brand-specific features
LG technologies (AV/TV)	Control Manager, Gapless Playback, ISM Method, SI Server Setting, Local Contents Scheduling, Booting Logo Image, Auto Set ID, Group Manager, No Signal Image, Setting Data Cloning, Status Mailing, Smart Energy Saving
Sensors
Gyroscope	Yes
Temperature sensor	Yes
Technical details
USB connector type	USB Type-A
Panel type	ADS
LED backlighting type	Edge-LED
Compliance certificates	CB, Electromagnetic Compatibility (EMC), Federal Communications Commission (FCC), CE, KC
Other features
USB connector type	USB Type-A
Wi-Fi	Yes
Quick start guide	Yes
Power consumption (PowerSave)	112 W
Power consumption (max)	247 W
Panel type	ADS
Bluetooth	Yes
Bezel width (top)	0.508" (1.29 cm)
Bezel width (side)	0.508" (1.29 cm)
Bezel width (bottom)	0.508" (1.29 cm)
Plug and Play	Yes
