49 Inch UHD Digital Signage, 500 nits, webOS Smart Platform with LG Shield
Key Features
- Resolution : 3,840 × 2,160 (UHD)
- Brightness : 500 nits (Typ.)
- Bezel Width : 11.4 mm (Even Bezel)
- webOS Smart Platform
- LG Shield
Description
UHD Signage Display with LG webOS Platform and Advanced SecuritySuperb Picture Quality with Ultra HD ResolutionWith the resolution of UHD, it makes the colors and details of the content vivid and realistic. In addition, the wide viewing angle provides clear content.
Even & Slim Bezel DesignThe UH5Q series features perfectly balanced horizontal and vertical slim bezels, creating a visually harmonious display solution. Its specialized design simplifies installation in retail environments while delivering a truly immersive viewing experience.
Convenient webOS PlatformThe UH5Q is equipped with a high-performance SoC that allows for multiple tasks to be performed without a separate media player. The webOS platform provides app development tools with an intuitive UI that enhances user convenience, and includes webOS partner apps to create an SI-friendly environment.
Design for Space UtilizationDesigned with thin bezels and simple cable management, the UH5Q saves space. With specialized hidden power inlets, it can be installed close to the wall, leaving only about 13.5 mm of space with the slim bracket.
Durability that Provides ReliabilityOptimized for business environments, the UH5Q is protected against salt, dust, iron powder and humidity thanks to conformal partial coating on power board, allowing for stable operation. Also, its customer-centric features, such as IP5x and Shock Monitoring, provide both reliability and satisfaction.
Comprehensive SecuritywebOS Signage goes beyond security measures at the operating system (OS) level. LG Shield employs a five-tiered defense system, encompassing server, application, operating system, system, and hardware. Each layer operates independently, providing comprehensive protection against various threats. Also webOS platform support ETSI EN 303 645.
SuperSign SolutionsSuperSign is an integrated and intuitive content management solution for creative and organized digital signage content in your space, connecting customers to a range of services with convenient user experiences. There are a variety of versions such as SuperSign Cloud, so discover and enjoy the version that best fits you.
Specifications
| Display |
|---|
| LED backlight |
Yes |
| Display diagonal |
49" |
| Display resolution |
3840 x 2160 pixels |
| Display brightness |
500 cd/m² |
| HD type |
4K Ultra HD |
| Contrast ratio (typical) |
1100:1 |
| Contrast ratio (dynamic) |
1000000:1 |
| Display number of colours |
1.07 billion colors |
| Touchscreen |
No |
| Panel type |
IPS |
| Native aspect ratio |
16:9 |
| LED backlighting type |
Edge-LED |
| Display technology |
LCD |
| Rated lifetime |
50000 h |
| Native refresh rate |
60 Hz |
| Ports & interfaces |
|---|
| Ethernet LAN |
Yes |
| HDMI ports quantity |
3 |
| DVI port |
No |
| USB port |
Yes |
| Ethernet LAN (RJ-45) ports |
1 |
| Wi-Fi |
Yes |
| USB version |
2.0 |
| USB ports quantity |
2 |
| RS-232C |
Yes |
| DisplayPorts quantity |
1 |
| Audio |
|---|
| Number of built-in speakers |
2 |
| RMS rated power |
20 W |
| Built-in speaker(s) |
Yes |
| Design |
|---|
| Product design |
Digital signage flat panel |
| Product colour |
Black |
| VESA mounting |
Yes |
| Panel mounting interface |
300 x 300 mm |
| Placement supported |
Indoor |
| Bezel width (top) |
0.449" (1.14 cm) |
| Bezel width (side) |
0.449" (1.14 cm) |
| Bezel width (bottom) |
0.449" (1.14 cm) |
| Performance |
|---|
| Purpose |
Universal |
| On Screen Display (OSD) languages |
Arabic, Simplified Chinese, Traditional Chinese, Czech, Danish, German, Dutch, English, Spanish, Finnish, French, Greek, Italian, Japanese, Korean, Norwegian, Polish, Portuguese, Russian, Swedish, Turkish |
| On Screen Display (OSD) |
Yes |
| HDCP version |
1.4/2.2 |
| Wi-Fi |
Yes |
| Power |
|---|
| Power consumption (typical) |
83 W |
| Power consumption (standby) |
0.5 W |
| Heat dissipation |
283 BTU/h |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50/60 Hz |
| Power consumption (off) |
0.5 W |
| Power consumption (max) |
134 W |
| Energy efficiency class (SDR) |
G |
| Energy efficiency class (HDR) |
Not available |
| Energy consumption (SDR) per 1000 hours |
86.5 kWh |
| Computer system |
|---|
| Operating system installed |
WebOS |
| Internal memory |
16 GB |
| Operating system version |
8.0 |
| Weight & dimensions |
|---|
| Width (with stand) |
47.8" (1215 mm) |
| Height (with stand) |
29.2" (742 mm) |
| Depth (with stand) |
5.59" (142 mm) |
| Weight (with stand) |
31.3 lbs (14.2 kg) |
| Display width |
43.5" (1104.3 mm) |
| Display depth |
1.17" (29.7 mm) |
| Display height |
25" (635.5 mm) |
| Display weight |
25.1 lbs (11.4 kg) |
| Packaging data |
|---|
| Package weight |
31.3 lbs (14.2 kg) |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Operating relative humidity (H-H) |
10 - 80% |
| Network |
|---|
| Ethernet LAN |
Yes |
| Wi-Fi |
Yes |
| Thin Client |
|---|
| Operating system installed |
WebOS |
| Internal memory |
16 GB |
| Features |
|---|
| Heat dissipation (max) |
457 BTU/h |
| Technical details |
|---|
| Power supply type |
Internal |
| Panel type |
IPS |
| LED backlighting type |
Edge-LED |
| Weight (with stand) |
31.3 lbs (14.2 kg) |
| Sustainability certificates |
ENERGY STAR, ErP |
| Compliance certificates |
CE, Federal Communications Commission (FCC), KC |
| Other features |
|---|
| Power supply type |
Internal |
| Wi-Fi |
Yes |
| Width (with stand) |
47.8" (1215 mm) |
| Power consumption (max) |
134 W |
| Panel type |
IPS |
| Internal memory type |
eMMC |
| Height (with stand) |
29.2" (742 mm) |
| Display technology |
LCD |
| Depth (with stand) |
5.59" (142 mm) |
| Bezel width (top) |
0.449" (1.14 cm) |
| Bezel width (side) |
0.449" (1.14 cm) |
| Bezel width (bottom) |
0.449" (1.14 cm) |
| Weight (with stand) |
31.3 lbs (14.2 kg) |
