22SM3G-B, 21.5", IPS, 1920 x 1080 (FHD), 250 cd/m², USB Plug & Play, Built-in Wi-Fi
Key Features
- Brightness(Typ.) : 250 cd/m²
- Bezel : 16.3mm
- Depth : 53.8mm
- Interface : HDMI(2) / USB 2.0 / RS232C / RJ45 / IR / Audio
- USB Plug & Play, Built-in Wi-Fi
Description
22" Signage with More Utility for Commercial Space22SM3G delivers information and performs guide with more effective ways in various commercial space, which provides more convenient solution thanks to its upgraded webOS platform.
High Performance SoC with webOSBuilt-in Quad Core SoC can execute several tasks at once while providing smooth content playback without the need for a media player. Also, LG webOS smart signage platform enhances user convenience with intuitive GUI and simple app development tools.
Various Sensor ApplicationsLG webOS smart signage platform easily supports connections with external sensors such as GPIO, NFC/RFID, temperature sensors, etc, via USB plug-in. The overall cost for maintenance is reduced as there's no need to purchase additional software or media players.
A Wide Range of InterfacesThrough its diverse interfaces, users can connect the display with various sources for optimal use. Also, the failover function supports users preparing backup sources in case an unexpected error occurs.
USB Plug & Play22SM3G supports USB Plug & Play feature, so users can easily set content playback using a USB.
Remote Monitoring and ControlThrough the Control Manager, the embedded web monitoring solution, you can control and monitor the status of multiple 22SM3G displays in different locations in real-time. It is available on internet-connected devices, allowing you to flexibly and rapidly respond to emergency situations anywhere.
Real-time Care Service with LG Signage365CareThe maintenance gets easier and faster with the optional service Signage365Care*, a cloud service solution provided by LG service. It remotely manages status of displays in client workplaces for fault diagnosis and remote-control services, ensuring stable operation of the client’s business.
Specifications
| Display |
|---|
| Display diagonal |
21.5" |
| Display resolution |
1920 x 1080 pixels |
| Display brightness |
250 cd/m² |
| HD type |
Full HD |
| Contrast ratio (typical) |
1000:1 |
| Contrast ratio (dynamic) |
400000:1 |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Display diagonal (metric) |
22" (55.9 cm) |
| Touchscreen |
No |
| Native aspect ratio |
16:9 |
| Display technology |
IPS |
| Ports & interfaces |
|---|
| Ethernet LAN |
Yes |
| HDMI ports quantity |
2 |
| DVI port |
No |
| USB port |
Yes |
| Audio (L/R) in |
1 |
| Ethernet LAN (RJ-45) ports |
1 |
| RS-232 interface |
Yes |
| Wi-Fi |
Yes |
| USB version |
2.0 |
| USB ports quantity |
1 |
| RS-232C |
Yes |
| DisplayPorts quantity |
0 |
| Audio |
|---|
| Number of built-in speakers |
2 |
| RMS rated power |
2 W |
| Built-in speaker(s) |
Yes |
| Design |
|---|
| Product design |
Digital signage flat panel |
| Product colour |
Black |
| VESA mounting |
Yes |
| Panel mounting interface |
100 x 100 mm |
| Orientation |
Horizontal |
| Certification |
CB, NRTL, EMC, FCC Class "A", CE, ErP |
| Performance |
|---|
| Purpose |
Universal |
| Operating hours (hours/days) |
16/7 |
| Wi-Fi |
Yes |
| Power |
|---|
| Power consumption (typical) |
33 W |
| Power consumption (standby) |
30 W |
| Heat dissipation |
7.89 BTU/h |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50 - 60 Hz |
| Power consumption (sleep) |
1 W |
| Power consumption (off) |
0.5 W |
| Computer system |
|---|
| Computer system |
No |
| Internal memory |
4 GB |
| Processor cores |
4 |
| Built-in processor |
Yes |
| Weight & dimensions |
|---|
| Width |
20.1" (510.3 mm) |
| Depth |
2.12" (53.8 mm) |
| Height |
11.9" (302.1 mm) |
| Weight |
7.36 lbs (3.34 kg) |
| Packaging data |
|---|
| Package width |
22.2" (565 mm) |
| Package depth |
4.06" (103 mm) |
| Package height |
14.1" (357 mm) |
| Package weight |
7.72 lbs (3.5 kg) |
| Remote control included |
Yes |
| Mounting kit |
Yes |
| Cables included |
AC |
| Batteries included |
Yes |
| Packaging content |
|---|
| Remote control included |
Yes |
| Mounting kit |
Yes |
| Cables included |
AC |
| Batteries included |
Yes |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Operating relative humidity (H-H) |
10 - 80% |
| Storage temperature (T-T) |
-20 - 60 °C |
| Storage relative humidity (H-H) |
5 - 85% |
| Certificates |
|---|
| Certification |
CB, NRTL, EMC, FCC Class "A", CE, ErP |
| Network |
|---|
| Ethernet LAN |
Yes |
| Wi-Fi |
Yes |
| Thin Client |
|---|
| Internal memory |
4 GB |
| Logistics data |
|---|
| Harmonized System (HS) code |
85285210 |
| Features |
|---|
| Harmonized System (HS) code |
85285210 |
| Other features |
|---|
| Wi-Fi |
Yes |
| Display technology |
IPS |
