Epson WorkForce DS-70000, 11.7 x 100" (297.2 x 2540 mm), 600 x 600 DPI, 16 bit, 8 bit, 70 ppm, 70 ppm
Key Features
- Capture large, 2-sided documents in a single scan — scan documents as large as 11.7" x 100" down to 2.7" x 4.7" through the ADF or 11.7" x 17" on the scanner bed
- Remarkable results — 4 line CCD sensor (RGB and black) provides crisp, sharp text
- Ultra-fast speeds — one-pass duplex at speeds of 70 ppm /140 ipm
- Work smarter and more efficiently — built-in 200-sheet Automatic Document Feeder, plus auto duplex scanning
- Ultrasonic double-feed detector — automatically stops the scanning process if two pages feed together; just separate the pages and continue
- Convenient, network scanning capabilities — use the optional networking module and included Document Capture Pro software to scan to any PC on the local network
- Scan directly to popular cloud services — scan to SharePoint®, Evernote®, Google Docs and more
- Scan to a searchable PDF — save scanned documents as PDF files
- Do more with powerful productivity software — includes Epson® Scan, Document Capture Pro (Windows® only)
- One-touch scanning — create up to 30 user-programmable jobs
Description
Epson WorkForce DS-70000. Maximum scan size: 11.7 x 100" (297.2 x 2540 mm), Optical scanning resolution: 600 x 600 DPI, Input color depth: 16 bit. Scanner type: Flatbed & ADF scanner, Product color: White. Sensor type: CCD, Daily duty cycle (max): 8000 pages, Scan file formats: PDF. Standard input capacity: 200 sheets. Maximum ISO A-series paper size: A4, ISO A-series sizes (A0...A9): A4, A5, ISO B-series sizes (B0...B9): B5
Specifications
| Scanning |
|---|
| Maximum scan size |
11.7 x 100" (297.2 x 2540 mm) |
| Optical scanning resolution |
600 x 600 DPI |
| Colour scanning |
Yes |
| Duplex scanning |
Yes |
| Input colour depth |
16 bit |
| Output colour depth |
8 bit |
| ADF scan speed (b/w, A4) |
70 ppm |
| ADF scan speed (colour, A4) |
70 ppm |
| Duplex ADF scan speed (b/w, A4) |
140 ipm |
| Duplex ADF scan speed (colour, A4) |
140 ipm |
| Design |
|---|
| Built-in display |
No |
| Product colour |
White |
| Scanner type |
Flatbed & ADF scanner |
| Performance |
|---|
| Sensor type |
CCD |
| Scan file formats |
PDF |
| Daily duty cycle (max) |
8000 pages |
| Input capacity |
|---|
| Standard input capacity |
200 sheets |
| Paper handling |
|---|
| Maximum ISO A-series paper size |
A4 |
| Maximum scan area (ADF) |
11.7 x 17" (297.2 x 431.8 mm) |
| Minimum scan area (ADF) |
2.7 x 4.7" (68.6 x 119.4 mm) |
| Auto Document Feeder (ADF) media weight |
35 - 128 g/m² |
| Letter |
Yes |
| Legal |
Yes |
| ISO B-series sizes (B0...B9) |
B5 |
| ISO A-series sizes (A0...A9) |
A4, A5 |
| Ports & interfaces |
|---|
| Standard interfaces |
USB 2.0 |
| Optional connectivity |
Ethernet |
| USB port |
Yes |
| USB version |
2.0 |
| Network |
|---|
| Ethernet LAN |
Yes |
| Power |
|---|
| Power supply type |
AC |
| Power consumption (typical) |
79 W |
| Power consumption (standby) |
12.5 W |
| Input voltage |
220-240 V |
| AC input frequency |
50 - 60 Hz |
| Weight & dimensions |
|---|
| Width |
25.2" (640 mm) |
| Depth |
18.5" (470 mm) |
| Height |
11.3" (287 mm) |
| Weight |
59.3 lbs (26.9 kg) |
| Sustainability |
|---|
| Sustainability certificates |
ENERGY STAR |
| System requirements |
|---|
| Windows operating systems supported |
Windows 7 Home Basic, Windows 7 Home Premium, Windows 7 Professional, Windows 7 Starter, Windows 7 Ultimate, Windows 8, Windows 8 Enterprise, Windows 8 Pro, Windows Vista Business, Windows Vista Enterprise, Windows Vista Home Basic, Windows Vista Home Premium, Windows Vista Ultimate, Windows XP Home, Windows XP Professional, Windows XP Professional x64 |
| USB required |
Yes |
| Mac operating systems supported |
Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion |
| Mac compatibility |
Yes |
| Operational conditions |
|---|
| Operating temperature (T-T) |
5 - 35 °C |
| Operating relative humidity (H-H) |
10 - 80% |
| Storage relative humidity (H-H) |
10 - 85% |
| Other features |
|---|
| Ethernet LAN |
Yes |
| Scanner type |
Flatbed & ADF scanner |
| Technical details |
|---|
| Sustainability certificates |
ENERGY STAR |
