Wi-Fi 6 (11ax), 2.4 GHz, 5 GHz, 1200 Mbps, 2400 Mbps, 23 dBm, 205 x 205 x 33 mm, 570 g

Key Features

• Wi-Fi 6 Technology: Dual concurrent 802.11ax architecture with backward compatibility for legacy Wi-Fi devices.
• High-Performance Speeds: Delivers 2,400 Mbps (5GHz) and 1,148 Mbps (2.4GHz) throughput.
• Advanced Security: Integrated WPA3 and WPA2-AES authentication protection.
• Professional-Grade Antenna: 5 dBi integrated 4x4 antenna system.
• Versatile Connectivity: 2.5GE PoE+ port for power and high-speed networking.
• Cloud Management: Free local and remote management via EnGenius Cloud.
• Flexible Deployment: Multiple operating modes with AP, STA, and Mesh support.

Description

EnGenius Cloud Managed Wi-Fi 6 4X4 Access Point ECW212L is a cost-effective model designed for small businesses. It support dual-concurrent 802.11ax architecture, delivering speeds up to 1,148 Mbps on the 2.4GHz and 2,400 Mbps on the 5 GHz band, providing high-performance connectivity. With seamless integration into the EnGenius Cloud platform, it offers easy management and robust security through WPA3, making it an ideal solution for businesses seeking enterprise-grade performance at an affordable price.

Specifications

Performance
Ethernet LAN data rates	10,100,1000,2500 Mbit/s
Spread spectrum method	OFDM, OFDMA
2.4 GHz	Yes
5 GHz	Yes
Frequency band	2.4 - 5.85 GHz
Wi-Fi Multimedia (WMM)/(WME)	Yes
Number of users	128 user(s)
VLAN support	Yes
Networking standards	IEEE 802.11a, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u
MIMO type	Multi User MIMO
MIMO	Yes
Wi-Fi roaming	Yes
Band steering	Yes
Remote Authentication Dial-In User Service (RADIUS)	Yes
Features
6 GHz	No
Ethernet LAN data rates	10,100,1000,2500 Mbit/s
Spread spectrum method	OFDM, OFDMA
2.4 GHz	Yes
5 GHz	Yes
Frequency band	2.4 - 5.85 GHz
Wi-Fi Multimedia (WMM)/(WME)	Yes
Number of users	128 user(s)
VLAN support	Yes
Networking standards	IEEE 802.11a, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u
Bluetooth	No
Fast roaming	Yes
MIMO type	Multi User MIMO
MIMO	Yes
Wi-Fi roaming	Yes
Band steering	Yes
Maximum data transfer rate (2.4 GHz)	1200 Mbit/s
Maximum data transfer rate (5 GHz)	2400 Mbit/s
Virtual LAN features	Tagged VLAN
Spatial streams	4 x 4
Maximum Tx power (2.4 GHz)	23 dBmW
Maximum Tx power (5 GHz)	23 dBmW
Security
Security algorithms	WPA2-PSK, WPA3-PSK
Remote Authentication Dial-In User Service (RADIUS)	Yes
Protocols
DHCP client	Yes
Ports & interfaces
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Power
Power consumption (max)	17 W
Input current	2 A
Power over Ethernet (PoE)	Yes
DC voltage range	12 V
Design
Placement	Ceiling, Wall
LED indicators	PoE, Power
Product colour	White
Antenna
Antenna type	Internal
Antennas quantity	8
Antenna gain level (max)	5 dBi
Antenna direction type	Omni-directional
Antenna features	Integrated antenna
Technical details
Harmonized System (HS) code	85176990
Compliance certificates	CE, Federal Communications Commission (FCC), Industry Canada (IC), UKCA
Certificates
Compliance certificates	CE, Federal Communications Commission (FCC), Industry Canada (IC), UKCA
Software
Fast roaming	Yes
Weight & dimensions
Width	8.07" (205 mm)
Depth	8.07" (205 mm)
Height	1.3" (33 mm)
Weight	20.1 oz (570 g)
Package width	9.72" (247 mm)
Package depth	9.72" (247 mm)
Package height	3.43" (87 mm)
Package weight	30.7 oz (870 g)
Packaging data
Mounting kit	Yes
Package width	9.72" (247 mm)
Package depth	9.72" (247 mm)
Package height	3.43" (87 mm)
Package weight	30.7 oz (870 g)
Packaging content
Mounting kit	Yes
Operational conditions
Operating relative humidity (H-H)	0 - 90%
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-40 - 80 °C
Storage relative humidity (H-H)	0 - 90%
Logistics data
Master (outer) case width	18.1" (460 mm)
Master (outer) case length	20.5" (520 mm)
Master (outer) case height	10.6" (270 mm)
Master (outer) case gross weight	22.3 lbs (10.1 kg)
Products per master (outer) case	10 pc(s)
Harmonized System (HS) code	85176990
