VRLA, 12 V, 9 Ah, 90 VAC - 142 VAC, 57 - 63 Hz, NEMA 5-15P/NEMA 5-15R, 1500 J, 99 x 279 x 356 mm, 11.34 kg

Key Features

• Capacity: 1500 VA / 900 W
• Topology: Line Interactive
• Waveform: Simulated Sine Wave
• Output: 120 VAC ± 5%
• Runtime (half/full): 12 minutes / 3 minutes
• Outlets: 12 (6 surge, 6 surge + battery backup)
• Communication: USB, Serial
• Data line protection: Ethernet, Coaxial

Description

A mini-tower UPS with line interactive topology, the CyberPower Intelligent LCD CP1500AVRLCDTAA provides battery backup (using simulated sine wave output) and surge protection for desktop computers, workstations, networking devices, and VoIP phone systems. The CP1500AVRLCDTAA uses Automatic Voltage Regulation (AVR) to correct minor power fluctuations without switching to battery power, which extends battery life. AVR is essential in areas where power fluctuations occur frequently. The CP1500AVRLCDTAA comes with a three-year warranty (including coverage of batteries), a $500,000 Connected Equipment Guarantee, and complies with the U.S. Trade Agreement Act (TAA).

Battery Backup
Supplies power long enough for equipment to properly shut down when utility power fails. Helps prevent loss of data and minimizes the component stress caused by a hard shutdown.

Surge Protection
Diverts excess voltage away from sensitive electronic equipment during an AC power surge or power spike to prevent damage.

Automatic Voltage Regulation (AVR)
AVR increases the AC power and maintains a safe voltage level without switching to battery mode and conserving battery life.

Multifunction LCD
Displays immediate, detailed information on the UPS battery and power conditions, alerting users to potential problems before they can affect critical equipment and cause downtime.

Data Line Protection
Prevents power surges that travel through coaxial and Ethernet lines from causing damage to electronics.

Line Interactive Topology
Exists when a line interactive UPS has an autotransformer that regulates low voltages (e.g., brownouts) and over voltages (e.g., spikes) without having to switch to battery.

Simulated Sine Wave Output
Provides a manufactured waveform output to supply cost-effective battery backup power for equipment that does not require sine wave output.

ENERGY STAR
This model is an ENERGY STAR® certified Uninterruptible Power Supply (UPS) system. ENERGY STAR is the trusted, government-backed symbol for energy-efficient products and practices that help save money and protect the environment.

GreenPower UPS™ Bypass Design
A patented design that allows utility power to bypass the UPS transformer, when AC power is stable, which reduces energy consumption, noise, and heat buildup.

Ultra Quiet Design
Minimizes noise during operation for a quieter work environment.

PowerPanel® Personal Software
Provides a user-friendly dashboard interface for controlling and monitoring the UPS. Free software download available.

Specifications

Power
Output power capacity	1.5 kVA
Output power	900 W
Input operation voltage (min)	90 V
Input operation voltage (max)	142 V
Output operation voltage (min)	120 V
Output operation voltage (max)	120 V
Surge energy rating	1500 J
Output frequency	60 Hz
Input frequency	57/63 Hz
Ports & interfaces
Cable length	78.7" (2 m)
AC outlets quantity	12 AC outlet(s)
AC outlet types	NEMA 5-15R
Power plug	NEMA 5-15P
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN (RJ-45) ports	2
Performance
UPS topology	Line-Interactive
Audible alarm modes	Alarm when on battery, Fault, Low battery alarm, Overload alarm
Response time	4 ms
EMI/RFI noise filtering	Yes
Surge protection features	Coax
Waveform	Sine
Power protection features	Overload
LED indicators	Fault, Power
Audible alarm(s)	Yes
Features
UPS topology	Line-Interactive
Output power capacity	1.5 kVA
Audible alarm modes	Alarm when on battery, Fault, Low battery alarm, Overload alarm
Response time	4 ms
Output power	900 W
Input operation voltage (min)	90 V
Input operation voltage (max)	142 V
Output operation voltage (min)	120 V
Output operation voltage (max)	120 V
Surge energy rating	1500 J
EMI/RFI noise filtering	Yes
Surge protection features	Coax
Waveform	Sine
Power protection features	Overload
Output frequency	60 Hz
Audible alarm(s)	Yes
Input frequency	57/63 Hz
Battery
Number of batteries supported	2
Battery recharge time	8 h
Typical backup time at half load	12 min
Typical backup time at full load	3 min
Hot-swap battery	Yes
Design
Form factor	Mini Tower
Product colour	Black
Cable length	78.7" (2 m)
LED indicators	Fault, Power
Display type	LCD
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-15 - 45 °C
Operating relative humidity (H-H)	0 - 90%
Storage relative humidity (H-H)	0 - 95%
Operating altitude	0 - 120000" (0 - 3048 m)
Non-operating altitude	0 - 599960.6" (0 - 15239 m)
Technical details
Output frequency	60 Hz
Weight & dimensions
Width	3.9" (99 mm)
Depth	14" (356 mm)
Height	11" (279 mm)
Weight	24.9 lbs (11.3 kg)
Package width	7.9" (200.7 mm)
Package depth	17.5" (444.5 mm)
Package height	14.7" (374.6 mm)
Package weight	24.9 lbs (11.3 kg)
Packaging data
Cables included	USB cable
Package width	7.9" (200.7 mm)
Package depth	17.5" (444.5 mm)
Package height	14.7" (374.6 mm)
Package weight	24.9 lbs (11.3 kg)
Packaging content
Cables included	USB cable
