Stay productive wherever you are working. Simply connect the scanner to a portable powerbank and work anywhere without any limitations to performance.
Key Features
- Scan up to 30ppm
- 60ipm, 2-sided colour scan
- Large 7.1cm touchscreen
- 20 sheet Automatic Document Feeder (ADF)
- Power directly via USB Type-C
- Create up to 20 one-touch scan activity shortcuts
Description
Powerful yet compact and portable, scanning from any location just got easier with the ADS-1800W. Compatible with external powerbanks, effortlessly scan your documents when and where it is most convenient for you. Together with wireless connectivity, you can easily connect and scan using your mobile phone or tablet and enjoy seamless workflows with powerful PDF editing and document management software. Create up to 25 preset scan to destinations No PC connection required Mobile App support OCR and PDF editing software included Compatible with Barcode Utility Optional paper output tray available Supports Brother Mobile Connect app *See datasheet for detailed technical information
Specifications
| Scanning |
|---|
| Maximum scan size |
8.5 x 14" (215.9 x 355.6 mm) |
| Optical scanning resolution |
600 x 600 DPI |
| Enhanced scan resolution |
1200 x 1200 DPI |
| Colour scanning |
Yes |
| Duplex scanning |
Yes |
| Greyscale levels |
256 |
| ADF scan speed (b/w, A4) |
30 ppm |
| Design |
|---|
| Built-in display |
Yes |
| Product colour |
White |
| Display |
LCD |
| Display diagonal |
2.8" |
| Touchscreen |
Yes |
| Scanner type |
ADF scanner |
| Colour display |
Yes |
| Control type |
Buttons, Touch |
| Performance |
|---|
| Sensor type |
Dual CIS |
| Scan to |
FTP, PC, SMB |
| Scan drivers |
SANE, TWAIN, WIA |
| Scanning noise level |
62 dB |
| Paper handling |
|---|
| Maximum ISO A-series paper size |
A4 |
| Scanning media types supported |
Business Card, Plain paper, Plastic Card, Recycled paper, Thick paper, Thin paper |
| ISO A-series sizes (A0...A9) |
A4 |
| Card thickness (max) |
0.0488" (1.24 mm) |
| Paper tray media weight |
51.8 - 128 g/m² |
| Ports & interfaces |
|---|
| USB connector type |
USB Type-C |
| USB port |
Yes |
| Network |
|---|
| Wi-Fi |
Yes |
| Wi-Fi standards |
802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Security algorithms |
64-bit WEP, 128-bit WEP, EAP-TLS, EAP-TTLS, SMTP-AUTH, SNMPv3, SSH, SSL/TLS, WPA-AES, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-TKIP, WPA3-PSK, WPA3-SAE |
| IPv6 support |
Yes |
| Power |
|---|
| Power supply type |
AC/USB |
| Power consumption (typical) |
10 W |
| Power consumption (standby) |
2 W |
| Power consumption (off) |
0.1 W |
| Weight & dimensions |
|---|
| Width |
11.3" (288 mm) |
| Depth |
3.98" (101 mm) |
| Height |
3.35" (85 mm) |
| Weight |
3.13 lbs (1.42 kg) |
| Package width |
11.3" (288 mm) |
| Package depth |
8.31" (211 mm) |
| Package height |
8.07" (205 mm) |
| Package weight |
5.31 lbs (2.41 kg) |
| Packaging data |
|---|
| Package width |
11.3" (288 mm) |
| Package depth |
8.31" (211 mm) |
| Package height |
8.07" (205 mm) |
| Package weight |
5.31 lbs (2.41 kg) |
| Packaging content |
|---|
| Cables included |
USB |
| System requirements |
|---|
| Windows operating systems supported |
Windows 10, Windows 11 |
| Mac operating systems supported |
Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura |
| Operational conditions |
|---|
| Operating temperature (T-T) |
5 - 35 °C |
| Other features |
|---|
| Wi-Fi |
Yes |
| Wi-Fi standards |
802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Security algorithms |
64-bit WEP, 128-bit WEP, EAP-TLS, EAP-TTLS, SMTP-AUTH, SNMPv3, SSH, SSL/TLS, WPA-AES, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-TKIP, WPA3-PSK, WPA3-SAE |
| Scanner type |
ADF scanner |
