| Internal I/O |
|---|
| Number of M.2 (M) slots |
3 |
| USB 3.2 Gen 2 (3.1 Gen 2) connectors |
0 |
| Front panel connector |
Yes |
| 12V power connector |
Yes |
| Supported storage drive interfaces |
M.2, SATA III |
| USB 2.0 connectors |
2 |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors |
2 |
| TPM connector |
Yes |
| S/PDIF out connector |
Yes |
| Number of SATA III connectors |
4 |
| Number of chassis fan connectors |
3 |
| Front panel audio connector |
Yes |
| CPU fan connector |
Yes |
| ATX Power connector (24-pin) |
Yes |
| RGB LED pin header |
Yes |
| Performance |
|---|
| Component for |
PC |
| Motherboard chipset family |
Intel |
| Motherboard chipset |
Intel B760 |
| Motherboard form factor |
micro ATX |
| Audio output channels |
7.1 channels |
| Supported storage drive types |
HDD & SSD |
| Supported processor sockets |
LGA 1700 |
| RAID levels |
0, 1, 5, 10 |
| Number of HDDs supported |
4 |
| Windows operating systems supported |
Windows 10 x64, Windows 11 |
| Processor |
|---|
| Processor manufacturer |
Intel |
| Compatible processor series |
Intel Core i3 12th Gen, Intel Core i3 13th Gen, Intel Core i3 14th Gen, Intel Core i5 12th Gen, Intel Core i5 13th Gen, Intel Core i5 14th Gen, Intel Core i7 12th Gen, Intel Core i7 13th Gen, Intel Core i7 14th Gen, Intel Core i9 12th Gen, Intel Core i9 13th Gen, Intel Core i9 14th Gen, Intel® Celeron®, Intel® Pentium® Gold |
| Processor socket |
LGA 1700 |
| Supported processor sockets |
LGA 1700 |
| Memory |
|---|
| Supported memory types |
DDR5-SDRAM |
| Memory slots type |
DIMM |
| Number of memory slots |
4 |
| Memory channels |
Dual-channel |
| Supported memory clock speeds |
7200,7000,6800,6600,6400,6200,6000,5800,5600,5400,5200,5000,4800 MHz |
| Maximum internal memory |
192 GB |
| Unbuffered memory |
Yes |
| Supported memory clock speed (max) |
7200 MHz |
| ECC сompatibility |
Non-ECC |
| Storage controllers |
|---|
| Supported storage drive interfaces |
M.2, SATA III |
| Supported storage drive types |
HDD & SSD |
| RAID levels |
0, 1, 5, 10 |
| Number of HDDs supported |
4 |
| Number of storage drives supported |
7 |
| RAID support |
Yes |
| Graphics |
|---|
| Parallel processing technology support |
Not supported |
| Rear panel I/O ports |
|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
0 |
| USB 2.0 ports quantity |
4 |
| Ethernet LAN (RJ-45) ports |
1 |
| WiFi-AP antenna jack |
1 |
| VGA (D-Sub) ports quantity |
0 |
| HDMI ports quantity |
1 |
| DVI-D ports quantity |
0 |
| DisplayPorts quantity |
1 |
| Network |
|---|
| Ethernet LAN |
Yes |
| Wi-Fi |
Yes |
| Wi-Fi standards |
Wi-Fi 6 (802.11ax), 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Ethernet interface type |
Gigabit Ethernet |
| Bluetooth |
Yes |
| Bluetooth version |
5.3 |
| Top Wi-Fi standard |
Wi-Fi 6 (802.11ax) |
| Features |
|---|
| Component for |
PC |
| Motherboard chipset family |
Intel |
| Motherboard chipset |
Intel B760 |
| Motherboard form factor |
micro ATX |
| Audio output channels |
7.1 channels |
| Supported processor sockets |
LGA 1700 |
| Windows operating systems supported |
Windows 10 x64, Windows 11 |
| Product colour |
White, Black |
| Expansion slots |
|---|
| Number of M.2 (M) slots |
3 |
| PCI Express x1 (Gen 4.x) slots |
2 |
| PCI Express x16 (Gen 4.x) slots |
1 |
| PCI Express x16 (Gen 5.x) slots |
1 |
| 1st M.2 largest key size |
2280 |
| 1st M.2 highest PCI Express generation |
4.0 |
| 2nd M.2 largest key size |
2280 |
| 2nd M.2 highest PCI Express generation |
4.0 |
| 3rd M.2 largest key size |
2280 |
| 3rd M.2 highest PCI Express generation |
3.0 |
| BIOS |
|---|
| BIOS type |
UEFI AMI |
| BIOS memory size |
128 Mbit |
| Weight & dimensions |
|---|
| Width |
9.61" (244 mm) |
| Depth |
9.61" (244 mm) |
| Packaging content |
|---|
| Cables included |
SATA |
| Screws included |
Yes |
| Antenna included |
Yes |
| Other features |
|---|
| PCI Express x1 (Gen 4.x) slots |
2 |
