65" ADS DLED, 4K, 16:9, 450 cd/m², 1200:1, 8 ms, 178/178, 20W, RJ45, HDMI, RS-232, SPDIF, USB, 100-240 VAC, 24/7, VESA, 25.4 kg
Key Features
- Multiple Ways To Connect And Share Content
- AV Control System Interoperability
- Centralized Control Device Management
- Reliable 24/7 Operation Rating
- Superb And Stunning Picture Quality
- Powerful Secured Embedded Platform
Description
Streamline your presentations, enhance collaboration, and succeed with the ViewSonic CDE6530 digital display. Whether your employees are in office or working remotely, they will enjoy fast and easy ways to communicate thanks to ViewBoard Cast™ screen sharing software and the myViewBoard® Display app that allows up to four participants to connect and share content. For maximum visibility even in rooms with high ambient light, these displays offer stunning 4K Ultra HD resolution, high brightness and a 25% high haze anti-glare screen. What’s more, these all-in-one displays simplify installation and maintenance thanks to a powerful secured embedded platform that delivers smooth content playback without the need for a PC or media player.
Multiple Ways to Connect and ShareConnect wirelessly through your network or directly to the display. Use the ViewBoard Cast™ screen sharing software along with the web-based myViewBoard® Display app to allow up to four participants (on-site and remote) to connect and share their content regardless of what OS platform they are using (Windows, MacOS, Chrome OS, Android, iOS). In addition, AirPlay, Miracast and the optional ViewBoard Cast button all offer wireless and software-less casting options.
AV Control System InteroperabilityThese displays are Crestron Connected® as well as Extron and AMX certified for seamless integration. Network admins are always in control with the ability to send control signals such as on/off, switch inputs, push firmware and security updates, and get status from the display.
Centralized Device Control ManagerFor IT admins, it’s tough managing the hundreds of devices and displays that live on the network. Now with myViewBoard Manager, an easy-to-use web-based application, IT can securely set up, manage and maintain all of the displays from a centralized dashboard.
Reliable 24/7 Operation RatingFeaturing a long lifespan, this professional-grade commercial display is designed for reliable use 24 hours a day, 7 days a week. Ideal in virtually any commercial application and environment, this commercial display delivers peace of mind with its robust and durable design.
Superb and Stunning Picture QualityWith 4K resolution, high brightness and 25% high haze anti-glare glass treatment, these displays deliver bright, clear and sharp images in any indoor environment.
Powerful Secured Embedded PlatformThis display can execute several tasks at once while providing smooth content playback without the need for a PC or media player. The embedded SoC provides PC-like performance and power to run apps, while hardened custom Android OS firmware protects the display from viruses and security breaches by preventing unknown sources to be installed on the system.
Flexible InstallationWith landscape or portrait mode options, a uniform bezel width, HDMI in and HDMI out for up to 9-screen tiling (ex 1x2, 2x2, 3x2, 4x2, 3x3, 1x9, etc.) without an external HDMI matrix, this display delivers versatile video wall configuration out-of-the-box.
Advanced Multi-Source CapabilityPicture in Picture (PiP) and Picture by Picture (PBP) options allow up to two independent sources to run at the same time.
Integrated Content Management SystemEnjoy a cloud-based 30-day trial service subscription from ViewSonic's content management software, powered by Revel Digital platform. This allows you to instantly transfer multimedia from any HTML5 browser-based device to the display no matter where you are. Works with optional ViewSonic Signage Manager CMS (SW-216) for local content push with perpetual license.
Specifications
| Display |
|---|
| Display diagonal |
65" |
| Display resolution |
3840 x 2160 pixels |
| Display brightness |
450 cd/m² |
| HD type |
4K Ultra HD |
| Response time |
8 ms |
| Contrast ratio (typical) |
1200:1 |
| Contrast ratio (dynamic) |
5000:1 |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Display number of colours |
1.07 billion colors |
| Panel life |
40000 h |
| Touchscreen |
No |
| Panel type |
ADS |
| Native aspect ratio |
16:9 |
| LED backlighting type |
Direct-LED |
| Display technology |
LCD |
| Anti-glare screen |
Yes |
| Surface hardness |
3H |
| Native refresh rate |
60 Hz |
| Haze rate |
25% |
| Ports & interfaces |
|---|
| Ethernet LAN |
Yes |
| HDMI ports quantity |
3 |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| HDMI version |
2.1 |
| DVI port |
No |
| USB connector type |
Mini-USB A, USB Type-C |
| USB port |
Yes |
| Ethernet LAN (RJ-45) ports |
1 |
| RS-232 interface |
Yes |
| Wi-Fi |
Yes |
| USB version |
2.0/3.2 Gen 1 (3.1 Gen 1) |
| USB ports quantity |
3 |
| DisplayPorts quantity |
0 |
| OPS module slot |
Yes |
| HDMI input ports quantity |
2 |
| HDMI output ports quantity |
1 |
| Audio |
|---|
| Number of built-in speakers |
2 |
| RMS rated power |
20 W |
| Built-in speaker(s) |
Yes |
| Design |
|---|
| Product design |
Digital signage flat panel |
| Product colour |
Black |
| VESA mounting |
Yes |
| Panel mounting interface |
600 x 400 mm |
| Placement supported |
Indoor |
| Orientation |
Horizontal/Vertical |
| Bezel width (top) |
0.591" (1.5 cm) |
| Bezel width (side) |
0.591" (1.5 cm) |
| Bezel width (bottom) |
0.591" (1.5 cm) |
| Certification |
cTUus, FCC, Energy Star 8.0, RoHS, Mexico NOM, Mexico Energy |
| Anti-glare screen |
Yes |
| Mounting type |
Wall |
| Screen shape |
Flat |
| Performance |
|---|
| Purpose |
Universal |
| Operating hours (hours/days) |
24/7 |
| HDCP |
Yes |
| HDCP version |
2.2 |
| Panel life |
40000 h |
| Wi-Fi |
Yes |
| Power |
|---|
| Power consumption (typical) |
165 W |
| Power consumption (standby) |
0.5 W |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50 - 60 Hz |
| Power consumption (max) |
335 W |
| Computer system |
|---|
| Processor frequency |
1.5 GHz |
| Operating system installed |
Android 11 |
| Computer system |
Yes |
| Computer system type |
System on Chip (SoC) |
| Internal memory |
4 GB |
| Processor cores |
4 |
| Internal storage capacity |
32 GB |
| Built-in processor |
Yes |
| On-board graphics card model |
ARM Mali-G52 |
| Weight & dimensions |
|---|
| Weight |
56 lbs (25.4 kg) |
| Display width |
57.6" (1463.3 mm) |
| Display depth |
3.21" (81.6 mm) |
| Display height |
33" (838.3 mm) |
| Display weight |
56 lbs (25.4 kg) |
| Packaging data |
|---|
| Package width |
64.1" (1628 mm) |
| Package depth |
8.19" (208 mm) |
| Package height |
37.1" (942 mm) |
| Package weight |
73.2 lbs (33.2 kg) |
| Remote control included |
Yes |
| Quick start guide |
Yes |
| Mounting kit |
Yes |
| Cables included |
AC, HDMI, RS-232, USB Type-C |
| Batteries included |
Yes |
| Packaging content |
|---|
| Remote control included |
Yes |
| Quick start guide |
Yes |
| Mounting kit |
Yes |
| Cables included |
AC, HDMI, RS-232, USB Type-C |
| Batteries included |
Yes |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Certificates |
|---|
| Certification |
cTUus, FCC, Energy Star 8.0, RoHS, Mexico NOM, Mexico Energy |
| Network |
|---|
| Ethernet LAN |
Yes |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Wi-Fi |
Yes |
| Thin Client |
|---|
| Processor frequency |
1.5 GHz |
| Operating system installed |
Android 11 |
| Internal memory |
4 GB |
| Internal storage capacity |
32 GB |
| Logistics data |
|---|
| Products per master (outer) case |
5 pc(s) |
| Pallet gross width |
66.1" (168 cm) |
| Pallet gross length |
44.9" (114 cm) |
| Pallet gross height |
42.2" (107.1 cm) |
| Harmonized System (HS) code |
8528521000 |
| Features |
|---|
| Harmonized System (HS) code |
8528521000 |
| Technical details |
|---|
| USB connector type |
Mini-USB A, USB Type-C |
| Panel type |
ADS |
| LED backlighting type |
Direct-LED |
| OPS slot |
1 |
| Other features |
|---|
| USB connector type |
Mini-USB A, USB Type-C |
| Wi-Fi |
Yes |
| Quick start guide |
Yes |
| Power consumption (max) |
335 W |
| Panel type |
ADS |
| Display technology |
LCD |
| Bezel width (top) |
0.591" (1.5 cm) |
| Bezel width (side) |
0.591" (1.5 cm) |
| Bezel width (bottom) |
0.591" (1.5 cm) |
| OPS module slot |
Yes |
