StarTech 10GbE Multi-Gigabit Open SFP+ Fiber Media Converter, Standalone 10 Gigabit Ethernet RJ-45 to 10GBASE-T SFP, Single-Mode / Multi-Mode, 9K Jumbo Frames
Key Features
- FIBER ETHERNET MEDIA CONVERTER: Extends & converts 10Gbps/1Gbps fiber to RJ45 copper; Supports multimode & singlemode fiber connections & a wide variety of fiber protocols depending on SFP+ module used
- Enable Zero-Touch Network Deployment: Plug-and-play design removes drivers and software, allowing non-technical users to install quickly while IT teams reduce setup time; Open SFP+ slot supports flexible copper-to-fiber or fiber-to-copper conversion
- RELIABLE & DURABLE DESIGN: Compact, stand-alone design, no rack necessary; External steel housing with ESD Surge Protection; Contact and Air Discharge Protection; MTBF rating exceeds 38,400 hrs
- TECH SPECS: 10 Gbps; 1 Gbps; 10GBASE-T; 1000BASE-T; Unmanaged; LFP; SMF & MMF; Full Duplex; RJ45; Mountable; Power adapter incl.; Open SFP/SFP+
- THE IT PRO'S CHOICE:: Designed for reliability in edge and on-prem deployments, our media converters are lab-tested and field-proven for seamless integration and maximum uptime; Backed by free lifetime multi-lingual technical assistance
Description
Fiber to Copper Media Converter | 10GBASE/1000BASE | 10Gbps/1Gbps Unmanaged | Single Mode & Multimode
This Ethernet fiber media converter offers an easy, cost-effective way to extend your network over fiber, using the SFP+ of your choice. It converts a copper RJ45 Ethernet connection to 10Gbps or 1Gbps fiber, to extend your network over longer distances or connect workstations to switches.
Cost-Effective Extensions and Flexible PerformanceThe RJ45 to fiber media converter provides a cost-efficient way to connect an Ethernet network to remote devices over a fiber backbone. It features an open SFP+ slot that supports the MSA-compliant 10 Gigabit SFP+ or 1 Gigabit SFP that best suits your fiber connection setup (single mode/multimode) and distance requirements.
A Versatile Way to Connect Different NetworksThe 10Gb/1Gb fiber media converter supports auto-negotiation while providing versatile connectivity to existing networks and devices, maximizing the usage and performance of legacy equipment.
Network Compatibility:
• 10GBASE-ER
• 10GBASE-LR
• 10GBASE-LW
• 10GBASE-EW
• 10GBASE-R
• 10GBASE-SR
• 10GBASE-SW
• 10GBASE-T
• 1000BASE-T
• 1000BASE-SX
• 1000BASE-LX
Fast and Easy InstallationThe unmanaged fiber media converter has a standalone compact design with simple plug-and-play setup to ensure fast and easy installation.
StarTech.com Fiber Media ConvertersOvercome the distance limitations of traditional network cables with StarTech.com fiber media converters. Our converters connect different types of network cabling and help you extend networks between buildings and over longer distances. Whether you need to extend a network connection 550 m or 40 km, we can help you.
Specifications
| Network |
|---|
| Maximum data transfer rate |
10000 Mbit/s |
| Auto-negotiation |
Yes |
| Jumbo frames |
9000 |
| Fiber ethernet cabling technology |
10GBASE-LR, 10GBASE-SR |
| Networking standards |
IEEE 802.1Q, IEEE 802.3ae, IEEE 802.3an |
| Jumbo frames support |
Yes |
| Ethernet LAN data rates |
10,100,1000,1200,2500,5000,10000 Mbit/s |
| Ethernet interface type |
10 Gigabit Ethernet |
| Auto MDI/MDI-X |
Yes |
| Fiber optic connector |
SFP+ |
| Performance |
|---|
| Fiber mode structure |
Multi-mode, Single-mode |
| Auto-negotiation |
Yes |
| Jumbo frames support |
Yes |
| Features |
|---|
| Internal |
No |
| LED indicators |
Link, Power |
| Housing material |
Aluminum |
| Product colour |
Black |
| Ports & interfaces |
|---|
| Connectivity technology |
Wired |
| Ethernet LAN (RJ-45) ports |
1 |
| Fiber ports quantity |
1 |
| Fiber optic connector |
SFP+ |
| Power |
|---|
| Input current |
250 A |
| Output voltage |
5 V |
| Output current |
2 A |
| Power plug type |
Type M |
| External power adapter |
Yes |
| Power over Ethernet (PoE) |
No |
| Weight & dimensions |
|---|
| Width |
3.15" (80 mm) |
| Depth |
4.8" (122 mm) |
| Height |
1.18" (30 mm) |
| Weight |
9.67 oz (274 g) |
| Package width |
5.67" (144 mm) |
| Package depth |
8.15" (207 mm) |
| Package height |
1.5" (38 mm) |
| Package weight |
12.3 oz (350 g) |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 70 °C |
| Storage temperature (T-T) |
-40 - 120 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Packaging content |
|---|
| AC adapter included |
Yes |
| Manual |
Yes |
| Packaging data |
|---|
| Package width |
5.67" (144 mm) |
| Package depth |
8.15" (207 mm) |
| Package height |
1.5" (38 mm) |
| Package weight |
12.3 oz (350 g) |
| Design |
|---|
| Internal |
No |
| LED indicators |
Link, Power |
| Housing material |
Aluminum |
| Product colour |
Black |
| Certification |
CE, FCC, UL, PSE |
| Certificates |
|---|
| Certification |
CE, FCC, UL, PSE |
| Compliance certificates |
RoHS |
| Technical details |
|---|
| Harmonized System (HS) code |
85176990 |
| Compliance certificates |
RoHS |
| Logistics data |
|---|
| Master (outer) case width |
12.6" (320 mm) |
| Master (outer) case length |
21.7" (550 mm) |
| Master (outer) case height |
12.6" (320 mm) |
| Products per master (outer) case |
20 pc(s) |
| Harmonized System (HS) code |
85176990 |
