43" 4K 3840 x 2160, LED Direct, 8 ms, 1200:1, 60 Hz
Description
Create pixel-perfect imagery at a cost-conscious price point with the new fully commercial NEC ME Series large format displays. By focusing on bringing high-powered, integrated and easy-to-use media playback to the customer all while maintaining the proven reliability and quality of previous product, the ME series gives customers a reliable mainstream display to fit all of their digital signage needs. The flexible system-on-chip platform not only allows for highend media playback via USB or internal storage but since these products are powered by Android 13, they also allow the ability to install separate APK’s if a third-party application needs to be installed. On top of this, the updated OSD design includes new and legacy functionality within a brand new aesthetically appealing and stylistic approach.
Specifications
| Display |
|---|
| LED backlight |
Yes |
| Display diagonal |
43" |
| Display resolution |
3840 x 2160 pixels |
| Display brightness |
400 cd/m² |
| HD type |
4K Ultra HD |
| Response time |
8 ms |
| Contrast ratio (typical) |
1200:1 |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Pixel pitch |
0.00984 x 0.00984" (0.25 x 0.25 mm) |
| Active display area (W x H) |
37.1 x 20.8" (941.2 x 529.4 mm) |
| Display number of colours |
1.07 billion colors |
| Vertical scan range |
23 - 76 Hz |
| Touchscreen |
No |
| Panel type |
ADS |
| Native aspect ratio |
16:9 |
| LED backlighting type |
Direct-LED |
| Horizontal scan range |
30 - 135 kHz |
| Adjustable colour temperature |
Yes |
| Colour temperature |
10000 K |
| High Dynamic Range (HDR) technology |
High Dynamic Range 10 (HDR10), Hybrid Log-Gamma (HLG) |
| High Dynamic Range (HDR) supported |
Yes |
| Native refresh rate |
60 Hz |
| Ports & interfaces |
|---|
| Ethernet LAN |
Yes |
| HDMI ports quantity |
3 |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| HDMI version |
2.0 |
| DVI port |
No |
| USB connector type |
USB Type-A, USB Type-C |
| USB port |
Yes |
| Ethernet LAN (RJ-45) ports |
1 |
| Wi-Fi |
No |
| USB ports quantity |
4 |
| RS-232C |
Yes |
| DisplayPorts quantity |
0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
1 |
| USB Type-C DisplayPort Alternate Mode |
Yes |
| Audio |
|---|
| Built-in speaker(s) |
Yes |
| Design |
|---|
| Product design |
Digital signage flat panel |
| Product colour |
Black |
| VESA mounting |
Yes |
| Panel mounting interface |
200 x 200 mm |
| Placement supported |
Indoor |
| Orientation |
Horizontal/Vertical |
| Screen shape |
Flat |
| Performance |
|---|
| Purpose |
Commercial |
| HDCP |
Yes |
| Wi-Fi |
No |
| Power |
|---|
| Power consumption (typical) |
90 W |
| Power consumption (standby) |
0.5 W |
| Power consumption (max) |
175 W |
| Energy efficiency class (SDR) |
G |
| Energy efficiency class (HDR) |
G |
| Energy consumption (SDR) per 1000 hours |
93 kWh |
| Computer system |
|---|
| Operating system installed |
Android |
| Computer system |
Yes |
| Operating system version |
13 |
| Weight & dimensions |
|---|
| Display width |
38" (964.6 mm) |
| Display depth |
2.44" (62 mm) |
| Display height |
21.8" (552.5 mm) |
| Display weight |
20.7 lbs (9.4 kg) |
| Packaging data |
|---|
| Package width |
41.6" (1056 mm) |
| Package depth |
6.14" (156 mm) |
| Package height |
24.9" (632 mm) |
| Package weight |
31.3 lbs (14.2 kg) |
| Operational conditions |
|---|
| Operating relative humidity (H-H) |
20 - 80% |
| Storage temperature (T-T) |
-20 - 60 °C |
| Storage relative humidity (H-H) |
10 - 80% |
| Network |
|---|
| Ethernet LAN |
Yes |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Wi-Fi |
No |
| Thin Client |
|---|
| Operating system installed |
Android |
| Technical details |
|---|
| USB connector type |
USB Type-A, USB Type-C |
| Power supply type |
Internal |
| Panel type |
ADS |
| LED backlighting type |
Direct-LED |
| Viewing angle (Horizontal/Vertical) |
178 |
| Other features |
|---|
| USB connector type |
USB Type-A, USB Type-C |
| Power supply type |
Internal |
| Wi-Fi |
No |
| USB 2.0 ports quantity |
1 |
| Power consumption (max) |
175 W |
| Panel type |
ADS |
| Headphone outputs |
1 |
| Headphone connectivity |
3.5 mm |
