24", IPS, 1920 x 1080, 16.78M, 250 cd/m², 1000:1, 5 ms
Key Features
- In-demand display size – the popular 23.8” display with Full HD resolution is the perfect size for busy office workspaces.
- Future-proof flexibility – wide connectivity provides high-level flexibility with DP, HDMI, USB Type C, USB A and audio output.
- Clutter-free workspace – Powerful 65W USB Type-C connectivity manages video, audio, power and USB via a single cable
- Easy multi-screen set-up – Daisy-chain multiple display configurations through DisplayPort-out, no additional cables needed
- Maximum attention to health and well-being – the outstanding ergonomic height adjustment from 0 to 150 mm; eye pleasing built-in Low Blue Light and Flicker-Free technology; plus integrated ambient light sensor all combines to tailor the perfect individual setup to boost productivity.
Description
Re-imagine your desktop computing experienceWith the MultiSync EA Series, Sharp has developed monitor solutions that push the boundaries of what you’ve come to know as business-class screen performance. The EA Series deliver a completely redesigned chassis with a host of enhanced features, advanced technologies, future-proof connectivity and environmentally friendly benefits. All models utilise IPS LCD panels, which boast the best possible colour accuracy and minimal viewing angle shift.
Every model features LED backlights, enabling a thin and light design. Other green features include ECO Mode™, a carbon footprint meter and an ambient light sensor, which automatically adjusts the brightness to the optimal setting depending on ambient lighting, screen content or both.
Specifications
| Display |
|---|
| Display brightness (typical) |
250 cd/m² |
| Display diagonal |
24" |
| Response time |
5 ms |
| Display resolution |
1920 x 1080 pixels |
| Display technology |
LCD |
| Screen shape |
Flat |
| Display number of colours |
16.78 million colors |
| Native aspect ratio |
16:9 |
| Maximum refresh rate |
60 Hz |
| sRGB coverage (typical) |
101.6% |
| Adobe RGB coverage |
75.3% |
| Contrast ratio (typical) |
1000:1 |
| Contrast ratio (dynamic) |
5000:1 |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Pixel pitch |
0.0108 x 0.0108" (0.275 x 0.275 mm) |
| Horizontal scan range |
31.5 - 83 kHz |
| Vertical scan range |
50 - 75 Hz |
| HD type |
Full HD |
| Backlight type |
W-LED |
| NTSC coverage (typical) |
72% |
| Touchscreen |
No |
| Panel type |
IPS |
| LED backlight |
Yes |
| Response time measurement type |
GTG (Gray to Gray) |
| Performance |
|---|
| Low Blue Light technology |
Yes |
| Flicker-free technology |
Yes |
| Multimedia |
|---|
| Built-in speaker(s) |
Yes |
| Number of speakers |
2 |
| RMS rated power |
2 W |
| Design |
|---|
| Market positioning |
Consumer |
| Product colour |
Black |
| Front bezel colour |
Black |
| Ports & interfaces |
|---|
| Built-in USB hub |
Yes |
| USB hub version |
3.2 Gen 1 (3.1 Gen 1) |
| Number of upstream ports |
1 |
| VGA (D-Sub) ports quantity |
1 |
| DVI-D ports quantity |
1 |
| HDMI ports quantity |
1 |
| DisplayPorts quantity |
1 |
| Headphone out |
No |
| HDMI |
Yes |
| Number of downstream ports |
3 |
| Ergonomics |
|---|
| Wall mountable |
Yes |
| Cable lock slot |
Yes |
| VESA mounting |
Yes |
| Panel mounting interface |
100 x 100 mm |
| LED indicators |
Power |
| Swivelling |
Yes |
| Swivel angle range |
-170 - 170° |
| Tilt angle range |
-5 - 35° |
| Height adjustment |
Yes |
| Pivot angle |
0 - 90° |
| Pivot |
Yes |
| Plug and Play |
Yes |
| Cable lock slot type |
Kensington |
| Tilt adjustment |
Yes |
| Power |
|---|
| AC input voltage |
100 - 240 V |
| Power consumption (standby) |
0.3 W |
| Power consumption (typical) |
21 W |
| Energy efficiency scale |
A to G |
| Energy efficiency class (SDR) |
D |
| Energy efficiency class (HDR) |
Not available |
| Energy consumption (SDR) per 1000 hours |
13 kWh |
| Operational conditions |
|---|
| Operating temperature (T-T) |
5 - 35 °C |
| Storage temperature (T-T) |
-10 - 60 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Storage relative humidity (H-H) |
10 - 85% |
| Weight & dimensions |
|---|
| Width (with stand) |
21.2" (537.7 mm) |
| Depth (with stand) |
9.84" (250 mm) |
| Height (with stand) |
19.2" (486.6 mm) |
| Bezel width (side) |
0.0315" (0.8 mm) |
| Bezel width (top) |
0.0315" (0.8 mm) |
| Bezel width (bottom) |
0.622" (1.58 cm) |
| Width (without stand) |
21.2" (537.7 mm) |
| Weight (with stand) |
15.4 lbs (7 kg) |
| Sustainability |
|---|
| Sustainability certificates |
ENERGY STAR, TCO |
| Technical details |
|---|
| Sustainability certificates |
ENERGY STAR, TCO |
| Warranty period |
3 year(s) |
| Compliance certificates |
RoHS, WEEE |
| Weight (with stand) |
15.4 lbs (7 kg) |
| Touchscreen |
No |
| Other features |
|---|
| Warranty period |
3 year(s) |
| Compliance certificates |
RoHS, WEEE |
| Width (without stand) |
21.2" (537.7 mm) |
| HDMI |
Yes |
| Energy efficiency scale |
A to G |
| Touchscreen |
No |
| Front bezel colour |
Black |
