LCD 43", 4K UHD 3840 x 2160, 500 cd/m², 8 ms, 994 x 582 x 73 mm, 21 kg
Key Features
- Best readability – high brightness panel ensures content is readable even in well-lit environments and anti-glare coating avoids distracting reflections
- Pen-On-Paper user experience – Zero bonded glass and latest infrared touch technology enable highly accurate and responsive writing and drawing with up to 20 touch points
- Out-of-the-box collaboration – the integrated Android PC features a powerful home screen launcher offering fast and flexible access to a range of pre-installed applications
- Highly customizable – a variety of settings allow the display to be optimised to meet the needs of different applications, from small meeting and huddle rooms to touch signage and wayfinding
- Safe & Secure – latest Android 14 SoC provides a secure operating system which, together with extra security features, meets the highest IT security standards
Description
Multi-purpose for interactive engagementsFor best-in-class touch performance and value, the Sharp LM series commands feature-rich professional capabilities for small meeting spaces and interactive signage applications. An integrated System on Chip (SoC) with Android 14 CTS-compliant Operating System offers the most up to date features and security for seamless out-of-the-box collaboration.
Boosting creativity in group collaboration, the Sharp LM series features intuitive Pen-on-Paper writing, a built-in whiteboard, annotation overlay mode and Windows Ink support. Using the on-board EShare app, content can be wirelessly shared from any personal device to the display without the need for apps or dongles. A single USB-C cable transmits data, video/audio output and power delivery between notebook and display for the simplest and seamless BYOD workflows.
With its 4-sided uniform slim bezel design, the Sharp LM series supports installations in both landscape and portrait as well as tilted desk. Dedicated features including hide side bars, application lock and a built-in web browser make the Sharp LM series the perfect display for budget-driven interactive signage applications.
Specifications
| Display |
|---|
| LED backlight |
Yes |
| Display diagonal |
43" |
| Display resolution |
3840 x 2160 pixels |
| Display brightness |
500 cd/m² |
| HD type |
4K Ultra HD |
| Response time |
8 ms |
| Contrast ratio (typical) |
4000:1 |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Display diagonal (metric) |
42.5" (108 cm) |
| Display number of colours |
1.07 billion colors |
| Vertical scan range |
24 - 70 Hz |
| Touchscreen |
Yes |
| Panel type |
VA |
| Number of simultaneous touchpoints |
20 |
| Native aspect ratio |
16:9 |
| LED backlighting type |
Direct-LED |
| Horizontal scan range |
31.5 - 135 kHz |
| Display technology |
LED |
| Touchscreen technology |
Infrared |
| Native refresh rate |
60 Hz |
| Haze rate |
25% |
| Multi-touch |
Yes |
| Ports & interfaces |
|---|
| HDMI ports quantity |
4 |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| DVI port |
No |
| USB connector type |
USB Type-A, USB Type-B, USB Type-C |
| USB port |
Yes |
| Ethernet LAN (RJ-45) ports |
1 |
| RS-232 interface |
Yes |
| Wi-Fi standards |
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| Wi-Fi |
Yes |
| USB ports quantity |
7 |
| OPS module slot |
Yes |
| HDMI input ports quantity |
3 |
| HDMI output ports quantity |
1 |
| USB 2.0 Type-B ports quantity |
1 |
| Audio Return Channel (ARC) |
Yes |
| Audio |
|---|
| Number of built-in speakers |
2 |
| RMS rated power |
20 W |
| Built-in speaker(s) |
Yes |
| Design |
|---|
| Product design |
Interactive flat panel |
| Product colour |
Black |
| VESA mounting |
Yes |
| Panel mounting interface |
400 x 400 mm |
| Placement supported |
Indoor |
| Orientation |
Horizontal/Vertical |
| Bezel width (top) |
0.591" (1.5 cm) |
| Bezel width (side) |
0.591" (1.5 cm) |
| Bezel width (bottom) |
0.591" (1.5 cm) |
| Certification |
ISO 9241-307, Class 1 |
| Screen shape |
Flat |
| Performance |
|---|
| Purpose |
Universal |
| Operating hours (hours/days) |
18/7 |
| HDCP |
Yes |
| HDCP version |
2.3 |
| Wi-Fi |
Yes |
| Power |
|---|
| Power consumption (typical) |
1110 W |
| Power consumption (standby) |
0.5 W |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50/60 Hz |
| Computer system |
|---|
| Processor family |
ARM Cortex |
| Processor model |
Cortex-A53 |
| Operating system installed |
Android 14 |
| Internal memory |
4 GB |
| Processor cores |
8 |
| Internal storage capacity |
32 GB |
| Processor manufacturer |
ARM |
| Built-in processor |
Yes |
| Processor architecture |
ARM Cortex-A53+Cortex-A73 |
| Operating system version |
14 |
| Weight & dimensions |
|---|
| Display width |
39.1" (994 mm) |
| Display depth |
2.87" (73 mm) |
| Display height |
22.9" (582 mm) |
| Display weight |
46.3 lbs (21 kg) |
| Packaging data |
|---|
| Package width |
44.9" (1140 mm) |
| Package depth |
7.28" (185 mm) |
| Package height |
29.1" (740 mm) |
| Package weight |
63.9 lbs (29 kg) |
| Package volume |
29000 cm³ |
| Remote control included |
Yes |
| Cables included |
AC, HDMI |
| Batteries included |
Yes |
| Packaging content |
|---|
| Remote control included |
Yes |
| Stand included |
No |
| Cables included |
AC, HDMI |
| Batteries included |
Yes |
| Operational conditions |
|---|
| Operating temperature (T-T) |
5 - 35 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Storage temperature (T-T) |
-20 - 60 °C |
| Storage relative humidity (H-H) |
10 - 80% |
| Certificates |
|---|
| Certification |
ISO 9241-307, Class 1 |
| Network |
|---|
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Wi-Fi standards |
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| Wi-Fi |
Yes |
| Thin Client |
|---|
| Processor family |
ARM Cortex |
| Processor model |
Cortex-A53 |
| Operating system installed |
Android 14 |
| Internal memory |
4 GB |
| Internal storage capacity |
32 GB |
| Features |
|---|
| Base material |
Metal |
| Suitable for indoor use |
Yes |
| Wall mountable |
Yes |
| Technical details |
|---|
| USB connector type |
USB Type-A, USB Type-B, USB Type-C |
| Stand included |
No |
| Panel type |
VA |
| Number of simultaneous touchpoints |
20 |
| LED backlighting type |
Direct-LED |
| Sustainability certificates |
ENERGY STAR |
| Warranty period |
3 year(s) |
| Compliance certificates |
CE, Electromagnetic Compatibility (EMC), RoHS, UKCA |
| Other features |
|---|
| USB connector type |
USB Type-A, USB Type-B, USB Type-C |
| Wi-Fi standards |
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| Wi-Fi |
Yes |
| Stand included |
No |
| Panel type |
VA |
| Number of simultaneous touchpoints |
20 |
| Display technology |
LED |
| Bluetooth version |
5.3 |
| Bluetooth |
Yes |
| Bezel width (top) |
0.591" (1.5 cm) |
| Bezel width (side) |
0.591" (1.5 cm) |
| Bezel width (bottom) |
0.591" (1.5 cm) |
| OPS module slot |
Yes |
