55", 4K UHD 3840 x 2160, VA, 350 nit, 4000:1, 8 ms, 178/178, 3x HDMI 2.0, 2x USB, Tizen 7.0
Description
Specifications
| Display |
|---|
| Display diagonal |
55" |
| Display resolution |
3840 x 2160 pixels |
| Display brightness |
350 cd/m² |
| HD type |
4K Ultra HD |
| Response time |
8 ms |
| Contrast ratio (typical) |
4000:1 |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Pixel pitch |
0.0124 x 0.0124" (0.315 x 0.315 mm) |
| Active display area (W x H) |
47.6 x 26.8" (1209.6 x 680.4 mm) |
| Display diagonal (metric) |
54.6" (138.7 cm) |
| Dynamic contrast ratio marketing name |
Mega Contrast |
| Vertical scan range |
48 - 75 Hz |
| Touchscreen |
No |
| Panel type |
VA |
| Horizontal scan range |
30 - 81 kHz |
| Display technology |
LED |
| Colour saturation |
72% |
| Native refresh rate |
60 Hz |
| Haze rate |
2% |
| RGB colour space |
NTSC |
| Ports & interfaces |
|---|
| Ethernet LAN |
Yes |
| HDMI ports quantity |
3 |
| HDMI version |
2.0 |
| DVI port |
No |
| Remote (IR) input |
1 |
| USB port |
Yes |
| Ethernet LAN (RJ-45) ports |
1 |
| RS-232 interface |
Yes |
| Wi-Fi |
No |
| USB ports quantity |
2 |
| PC Audio out |
Yes |
| DisplayPorts quantity |
0 |
| HDMI input ports quantity |
3 |
| Audio |
|---|
| Sound modes |
Dolby Audio |
| Built-in speaker(s) |
No |
| Design |
|---|
| Product design |
Digital signage flat panel |
| Product colour |
Black |
| VESA mounting |
Yes |
| Panel mounting interface |
200 x 200 mm |
| Placement supported |
Indoor |
| Bezel width (top) |
0.453" (1.15 cm) |
| Bezel width (side) |
0.453" (1.15 cm) |
| Bezel width (bottom) |
0.453" (1.15 cm) |
| Mounting type |
Wall |
| Screen shape |
Flat |
| Performance |
|---|
| Purpose |
Commercial |
| Operating hours (hours/days) |
16/7 |
| HDCP |
Yes |
| HDCP version |
2.2 |
| Wi-Fi |
No |
| Power |
|---|
| Power consumption (typical) |
154 W |
| Power consumption (standby) |
0.5 W |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50/60 Hz |
| Energy efficiency scale |
A to G |
| Energy efficiency class (SDR) |
G |
| Energy consumption (SDR) per 1000 hours |
85 kWh |
| Computer system |
|---|
| Operating system installed |
Tizen 7.0 |
| Internal memory |
8 GB |
| Video formats supported |
HEVC/H.265 |
| Built-in processor |
Yes |
| Weight & dimensions |
|---|
| Display width |
48.7" (1237.9 mm) |
| Display depth |
1.12" (28.5 mm) |
| Display height |
27.9" (708.8 mm) |
| Display weight |
34.6 lbs (15.7 kg) |
| Packaging data |
|---|
| Package width |
55.2" (1403 mm) |
| Package depth |
5.83" (148 mm) |
| Package height |
32.9" (835 mm) |
| Package weight |
43.9 lbs (19.9 kg) |
| Remote control included |
Yes |
| Mounting kit |
Yes |
| Cables included |
AC, RS-232, USB |
| Batteries included |
Yes |
| Packaging content |
|---|
| Remote control included |
Yes |
| Mounting kit |
Yes |
| Cables included |
AC, RS-232, USB |
| Batteries included |
Yes |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Operating relative humidity (H-H) |
10 - 80% |
| Storage temperature (T-T) |
-20 - 45 °C |
| Storage relative humidity (H-H) |
5 - 95% |
| Network |
|---|
| Ethernet LAN |
Yes |
| Wi-Fi |
No |
| Thin Client |
|---|
| Operating system installed |
Tizen 7.0 |
| Internal memory |
8 GB |
| Video formats supported |
HEVC/H.265 |
| Technical details |
|---|
| Panel type |
VA |
| Processor |
Quantum Lite 4K Processor |
| Sustainability compliance |
Yes |
| Sustainability certificates |
ENERGY STAR, EPEAT |
| Compliance certificates |
TÜV mark |
| Other features |
|---|
| Wi-Fi |
No |
| Sound modes |
Dolby Audio |
| PC Audio out |
Yes |
| Panel type |
VA |
| On/off switch |
Yes |
| Display technology |
LED |
| Bezel width (top) |
0.453" (1.15 cm) |
| Bezel width (side) |
0.453" (1.15 cm) |
| Bezel width (bottom) |
0.453" (1.15 cm) |
| Energy efficiency scale |
A to G |
