| Ports & interfaces |
|---|
| Internal |
Yes |
| Connectivity technology |
Wired |
| Host interface |
PCI Express |
| Interface |
Ethernet |
| Ethernet LAN (RJ-45) ports |
4 |
| PCI version |
2.1 |
| PCI Card form factor |
Full-height (low-profile) |
| Bandwidth |
|---|
| Maximum data transfer rate |
1000 Mbit/s |
| Full duplex |
Yes |
| Network |
|---|
| Chipset |
Intel® I350 |
| Maximum data transfer rate |
1000 Mbit/s |
| Ethernet LAN |
Yes |
| iSCSI support |
Yes |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Cabling technology |
10/100/1000BaseT(X) |
| Networking standards |
IEEE 802.1as, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Supported network protocols |
TCP, UDP, IP |
| Maximum operating distance |
3937" (100 m) |
| LAN controller |
Intel® I350 |
| Full duplex |
Yes |
| Design |
|---|
| Internal |
Yes |
| Chipset |
Intel® I350 |
| PCI Card form factor |
Full-height (low-profile) |
| Component for |
Server |
| Product family |
Intel Gigabit server adapter |
| Product series |
Intel® I350 |
| Product codename |
Powerville |
| Power |
|---|
| Power consumption (typical) |
5 W |
| System requirements |
|---|
| Compatible operating systems |
https://www.intel.com/content/www/us/en/support/articles/000025890/network-and-i-o/ethernet-products.html |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 55 °C |
| Storage temperature (T-T) |
-40 - 70 °C |
| Storage relative humidity (H-H) |
35 - 90% |
| Weight & dimensions |
|---|
| Width |
2.71" (68.9 mm) |
| Depth |
5.33" (135.4 mm) |
| Protocols |
|---|
| Supported network protocols |
TCP, UDP, IP |
| Performance |
|---|
| Ethernet adapter ARK ID |
84805 |
| Storage-over-ethernet |
Yes |
| Speed & slot width |
5.0 GT/s, x4 Lane |
| PCI-SIG* SR-IOV Capable |
Yes |
| On-chip QoS and Traffic Management |
Yes |
| iWARP/RDMA |
No |
| Intelligent Offloads |
Yes |
| Intel Virtual Machine Device Queues (VMDq) |
Yes |
| Intel Flexible Port Partitioning |
Yes |
| Intel Ethernet Power Management |
Yes |
| Technical details |
|---|
| Harmonized System (HS) code |
85176990 |
| Export Control Classification Number (ECCN) |
5A991 |
| Commodity Classification Automated Tracking System (CCATS) |
NA |
| Thermal Design Power (TDP) |
5 W |
| Product type |
Network Interface Card |
| Processor family |
Gigabit Ethernet Adapters (up to 2.5GbE)-Gigabit Ethernet Adapters (up to 2.5GbE) |
| Status |
Launched |
| Product brief URL |
http://www.intel.com/content/www/us/en/ethernet-controllers/ethernet-i350-server-adapter-brief.html?wapkw=i350 |
| Network interface card type |
Server |
| Network interface card cable medium |
Copper |
| Market segment |
Server |
| Launch date |
Q3'14 |
| Last change |
63903513 |
| Other features |
|---|
| Chipset |
Intel® I350 |
| Compatible operating systems |
https://www.intel.com/content/www/us/en/support/articles/000025890/network-and-i-o/ethernet-products.html |
| Thermal Design Power (TDP) |
5 W |
| Product type |
Network Interface Card |
| Processor family |
Gigabit Ethernet Adapters (up to 2.5GbE)-Gigabit Ethernet Adapters (up to 2.5GbE) |
| Cable type |
Cat 5 up to 100m |
| Ethernet adapter ARK ID |
84805 |
| Storage-over-ethernet |
Yes |
| Speed & slot width |
5.0 GT/s, x4 Lane |
| PCI-SIG* SR-IOV Capable |
Yes |
| On-chip QoS and Traffic Management |
Yes |
| Low halogen options available |
No |
| iWARP/RDMA |
No |
| Interface type |
PCIe v2.1 (5.0 GT/s) |
| Intelligent Offloads |
Yes |
| Intel Virtualization Technology for Connectivity (VT-c) |
Yes |
| Intel Virtual Machine Device Queues (VMDq) |
Yes |
| Intel Flexible Port Partitioning |
Yes |
| Intel Ethernet Power Management |
Yes |
| Embedded options available |
No |
| Storage Over Ethernet |
iSCSI, NFS |
| Status |
Launched |
| Product brief URL |
http://www.intel.com/content/www/us/en/ethernet-controllers/ethernet-i350-server-adapter-brief.html?wapkw=i350 |
| Network interface card type |
Server |
| Network interface card cable medium |
Copper |
| Market segment |
Server |
| Launch date |
Q3'14 |
| Last change |
63903513 |
| Product family |
Intel Gigabit server adapter |
| Product series |
Intel® I350 |
| Product codename |
Powerville |
| Harmonized System (HS) code |
85176990 |
| Export Control Classification Number (ECCN) |
5A991 |
| Commodity Classification Automated Tracking System (CCATS) |
NA |
| Controller type |
Intel I350 |
| Cabling type |
Cat 5 up to 100m |
| Bracket height |
Low-Profile (LP) / Full-Height (FH) |
| Logistics data |
|---|
| Harmonized System (HS) code |
85176990 |
