Fit 2×2 Indoor Wireless Wi-Fi 6 Access Point
Key Features
- Dual concurrent 802.11ax architecture & backward-compatible with 11ac/a/b/g/n client devices
- WPA3 & WPA2-AES authentication support
- 5 dBi integrated 2x2 antenna
- Supports up to 2,400 Mbps in the 5GHz frequency band & 574 Mbps in the 2.4GHz frequency band
- Support 5GHz DFS channels
- Local and remote management over FitController controller without fees
- 1 GB 802.3af PoE port for easy placement up to 328 feet from a power source
- Choice of AP and WDS modes to meet your management & deployment requirements
Description
EnGenius Fit 802.11ax 2×2 Managed Dual Band Wireless Indoor Access PointEnGenius Fit6 2x2 Lite Managed Indoor Wireless Access Point offers advanced 802.11ax technology, granting users incredibly speedy and efficient performance with a maximum theoretical speed of 574 Mbps on the 2.4GHz frequency and an incredible 2,400Mbps on 5GHz frequency! Furthermore it's safeguarded by top-tier WPA3/WPA2PSK AES encryption protocols for unparalleled security. security.
Specifications
| Performance |
|---|
| Maximum data transfer rate |
2400 Mbit/s |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| 2.4 GHz |
Yes |
| 5 GHz |
Yes |
| IGMP snooping |
Yes |
| Web-based management |
Yes |
| VLAN support |
Yes |
| Switch type |
Managed |
| Reset button |
Yes |
| Quality of Service (QoS) support |
Yes |
| Networking standards |
IEEE 802.11n, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g |
| MIMO type |
Multi User MIMO |
| MIMO |
Yes |
| Built-in processor |
Yes |
| Processor frequency |
1000 MHz |
| Features |
|---|
| Maximum data transfer rate |
2400 Mbit/s |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| 2.4 GHz |
Yes |
| 5 GHz |
Yes |
| VLAN support |
Yes |
| Quality of Service (QoS) support |
Yes |
| Networking standards |
IEEE 802.11n, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g |
| MIMO type |
Multi User MIMO |
| MIMO |
Yes |
| Maximum data transfer rate (2.4 GHz) |
574 Mbit/s |
| Maximum data transfer rate (5 GHz) |
2400 Mbit/s |
| Switch type |
Managed |
| Built-in processor |
Yes |
| Processor frequency |
1000 MHz |
| Security |
|---|
| Security algorithms |
WPA2-Enterprise, WPA3 |
| IGMP snooping |
Yes |
| MAC address filtering |
Yes |
| Protocols |
|---|
| Management protocols |
SNTP |
| Management features |
|---|
| Web-based management |
Yes |
| Switch type |
Managed |
| Ports & interfaces |
|---|
| USB 2.0 ports quantity |
0 |
| Ethernet LAN (RJ-45) ports |
1 |
| Power |
|---|
| Power consumption (max) |
12.8 W |
| Input current |
2 A |
| Power over Ethernet (PoE) |
Yes |
| DC voltage range |
12 V |
| Design |
|---|
| Reset button |
Yes |
| LED indicators |
Yes |
| Product colour |
White |
| Antenna |
|---|
| Antenna type |
Internal |
| Antenna direction type |
Omni-directional |
| Technical details |
|---|
| Harmonized System (HS) code |
85176990 |
| Weight & dimensions |
|---|
| Width |
6.3" (160 mm) |
| Depth |
6.3" (160 mm) |
| Height |
1.31" (33.2 mm) |
| Weight |
13.4 oz (380 g) |
| Package width |
10.5" (266 mm) |
| Package depth |
6.5" (165 mm) |
| Package height |
1.54" (39 mm) |
| Package weight |
20.1 oz (570 g) |
| Packaging data |
|---|
| Package width |
10.5" (266 mm) |
| Package depth |
6.5" (165 mm) |
| Package height |
1.54" (39 mm) |
| Package weight |
20.1 oz (570 g) |
| Packaging content |
|---|
| Quantity per pack |
1 pc(s) |
| Operational conditions |
|---|
| Operating relative humidity (H-H) |
5 - 95% |
| Operating temperature (T-T) |
0 - 50 °C |
| Storage temperature (T-T) |
-40 - 70 °C |
| Storage relative humidity (H-H) |
5 - 95% |
| Logistics data |
|---|
| Master (outer) case width |
13.9" (353 mm) |
| Master (outer) case length |
16.9" (428 mm) |
| Master (outer) case height |
12.2" (311 mm) |
| Master (outer) case gross weight |
26.9 lbs (12.2 kg) |
| Products per master (outer) case |
20 pc(s) |
| Quantity per pack |
1 pc(s) |
| Harmonized System (HS) code |
85176990 |
