2.4 GHz & 5 GHz, 600 Mbps, 2400 Mbps, 21 dBm, 160 x 160 x 30 mm, 380g
Key Features
- Wi-Fi 6 Technology: Dual concurrent 802.11ax architecture with backward compatibility for legacy Wi-Fi devices.
- High-Performance Speeds:Delivers 2,400 Mbps (5GHz) and 574 Mbps (2.4GHz) throughput.
- Advanced Security: Integrated WPA3 and WPA2-AES authentication protection.
- Professional-Grade Antenna: 5 dBi integrated 2x2 antenna system.
- Extended Coverage: Supports 5GHz DFS channels for broader wireless coverage.
- Flexible Installation: GE PoE port enables placement up to 328 feet from power source.
- Cloud Management: Free local and remote management via EnGenius Cloud.
- Flexible Deployment: Multiple operating modes with AP, STA, and Mesh support.
Description
EnGenius Cloud Managed Wi-Fi 6 2X2 Access Point ECW210L is a cost-effective model designed for small businesses. It support dual-concurrent 802.11ax architecture, delivering speeds up to 574 Mbps on the 2.4GHz and 2,400 Mbps on the 5 GHz band, providing high-performance connectivity. With seamless integration into the EnGenius Cloud platform, it offers easy management and robust security through WPA3, making it an ideal solution for businesses seeking enterprise-grade performance at an affordable price.
Specifications
| Performance |
|---|
| Maximum data transfer rate |
2400 Mbit/s |
| Ethernet LAN data rates |
10,100,1000,2500 Mbit/s |
| Spread spectrum method |
DSSS, OFDM, OFDMA |
| 2.4 GHz |
Yes |
| 5 GHz |
Yes |
| Frequency band |
2.4 - 5.85 GHz |
| Wi-Fi Multimedia (WMM)/(WME) |
Yes |
| Number of users |
128 user(s) |
| VLAN support |
Yes |
| Quality of Service (QoS) support |
Yes |
| Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| MIMO type |
Multi User MIMO |
| MIMO |
Yes |
| Wi-Fi roaming |
Yes |
| Built-in processor |
Yes |
| Processor model |
ARM Cortex-A53 |
| Processor frequency |
1000 MHz |
| Features |
|---|
| 6 GHz |
No |
| Maximum data transfer rate |
2400 Mbit/s |
| Ethernet LAN data rates |
10,100,1000,2500 Mbit/s |
| Spread spectrum method |
DSSS, OFDM, OFDMA |
| 2.4 GHz |
Yes |
| 5 GHz |
Yes |
| Frequency band |
2.4 - 5.85 GHz |
| Wi-Fi Multimedia (WMM)/(WME) |
Yes |
| Number of users |
128 user(s) |
| VLAN support |
Yes |
| Quality of Service (QoS) support |
Yes |
| Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Bluetooth |
No |
| Fast roaming |
Yes |
| MIMO type |
Multi User MIMO |
| MIMO |
Yes |
| Wi-Fi roaming |
Yes |
| Maximum data transfer rate (2.4 GHz) |
600 Mbit/s |
| Maximum data transfer rate (5 GHz) |
2400 Mbit/s |
| Virtual LAN features |
Tagged VLAN |
| Spatial streams |
2 x 2 |
| Maximum Tx power (2.4 GHz) |
21 dBmW |
| Maximum Tx power (5 GHz) |
21 dBmW |
| Built-in processor |
Yes |
| Processor model |
ARM Cortex-A53 |
| Processor frequency |
1000 MHz |
| Security |
|---|
| Security algorithms |
WPA2-PSK, WPA3-PSK |
| MAC address filtering |
Yes |
| Service Set Identifier (SSID) features |
Hidden SSID |
| Ports & interfaces |
|---|
| USB 2.0 ports quantity |
0 |
| Ethernet LAN (RJ-45) ports |
1 |
| DC-in jack |
Yes |
| Power |
|---|
| Power consumption (max) |
10.7 W |
| Input current |
1.5 A |
| Power over Ethernet (PoE) |
Yes |
| DC voltage range |
12 V |
| Design |
|---|
| Placement |
Ceiling, Wall |
| Product colour |
White |
| Antenna |
|---|
| Antenna type |
Internal |
| Antennas quantity |
4 |
| Antenna gain level (max) |
7 dBi |
| Antenna direction type |
Omni-directional |
| Antenna features |
Integrated antenna |
| Technical details |
|---|
| Harmonized System (HS) code |
85176990 |
| Compliance certificates |
CE, Federal Communications Commission (FCC), Industry Canada (IC), UKCA |
| Certificates |
|---|
| Compliance certificates |
CE, Federal Communications Commission (FCC), Industry Canada (IC), UKCA |
| Software |
|---|
| Fast roaming |
Yes |
| Weight & dimensions |
|---|
| Width |
6.3" (160 mm) |
| Depth |
6.3" (160 mm) |
| Height |
1.18" (30 mm) |
| Weight |
13.4 oz (380 g) |
| Package width |
10.5" (266 mm) |
| Package depth |
6.5" (165 mm) |
| Package height |
1.54" (39 mm) |
| Package weight |
17.6 oz (500 g) |
| Packaging data |
|---|
| Mounting kit |
Yes |
| Package width |
10.5" (266 mm) |
| Package depth |
6.5" (165 mm) |
| Package height |
1.54" (39 mm) |
| Package weight |
17.6 oz (500 g) |
| Packaging content |
|---|
| Mounting kit |
Yes |
| Operational conditions |
|---|
| Operating relative humidity (H-H) |
0 - 90% |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-40 - 80 °C |
| Storage relative humidity (H-H) |
0 - 90% |
| Logistics data |
|---|
| Master (outer) case width |
13.9" (353 mm) |
| Master (outer) case length |
16.9" (428 mm) |
| Master (outer) case height |
12.2" (311 mm) |
| Master (outer) case gross weight |
26.9 lbs (12.2 kg) |
| Products per master (outer) case |
20 pc(s) |
| Harmonized System (HS) code |
85176990 |
