1350 VA / 815 W, Line Interactive, Sine Wave, 120 VAC, NEMA 5-15P, x12
Key Features
- Battery Backup
- Surge Protection
- Automatic Voltage Regulation (AVR)
- Multifunction, Color LCD
- Data Line Protection
Description
A mini-tower UPS with line interactive topology, the CyberPower Intelligent LCD CP1350AVRLCD3 provides battery backup (using simulated sine wave output) and surge protection for desktop computers, workstations, networking devices, and home entertainment systems. The CP1350AVRLCD3 uses Automatic Voltage Regulation (AVR) to correct minor power fluctuations without switching to battery power, which extends battery life. AVR is essential in areas where power fluctuations occur frequently. The CP1350AVRLCD3 comes with a three-year warranty (including coverage of batteries) and a $500,000 Connected Equipment Guarantee.
Specifications
| Power |
|---|
| Output power capacity |
1.35 kVA |
| Output power |
815 W |
| Input operation voltage (max) |
120 V |
| Surge energy rating |
1500 J |
| Maximum current |
15 A |
| Power factor |
0.6 |
| Input frequency |
57/63 Hz |
| Ports & interfaces |
|---|
| Cable length |
70.9" (1.8 m) |
| AC outlets quantity |
12 AC outlet(s) |
| AC outlet types |
NEMA 5-15P |
| Power plug |
NEMA 5-15P |
| USB port |
Yes |
| USB port type |
USB Type A/USB Type-C |
| Performance |
|---|
| UPS topology |
Line-Interactive |
| Audible alarm modes |
Low battery alarm, Overload alarm, Fault, Alarm when on battery |
| Response time |
4 ms |
| EMI/RFI noise filtering |
Yes |
| Surge protection |
Yes |
| Surge protection features |
Coax |
| Waveform |
Sine |
| Power protection features |
Short circuit |
| LED indicators |
Power, Fault |
| Audible alarm(s) |
Yes |
| Features |
|---|
| UPS topology |
Line-Interactive |
| Output power capacity |
1.35 kVA |
| Audible alarm modes |
Low battery alarm, Overload alarm, Fault, Alarm when on battery |
| Response time |
4 ms |
| Output power |
815 W |
| Input operation voltage (max) |
120 V |
| Surge energy rating |
1500 J |
| Maximum current |
15 A |
| EMI/RFI noise filtering |
Yes |
| Surge protection |
Yes |
| Surge protection features |
Coax |
| Waveform |
Sine |
| Power protection features |
Short circuit |
| Power factor |
0.6 |
| Audible alarm(s) |
Yes |
| Input frequency |
57/63 Hz |
| Battery |
|---|
| Battery technology |
Sealed Lead Acid (VRLA) |
| Number of batteries supported |
2 |
| Battery recharge time |
8 h |
| Typical backup time at half load |
14 min |
| Typical backup time at full load |
4 min |
| Battery voltage |
12 V |
| Battery capacity |
9 Ah |
| Battery replacement accessibility |
End-user |
| Design |
|---|
| Form factor |
Mini Tower |
| Product colour |
Black |
| Cable length |
70.9" (1.8 m) |
| LED indicators |
Power, Fault |
| Housing material |
Plastic |
| Display type |
LCD |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-15 - 45 °C |
| Operating relative humidity (H-H) |
0 - 95% |
| Storage relative humidity (H-H) |
0 - 95% |
| Technical details |
|---|
| Compliance certificates |
RoHS, UL, cUL, Federal Communications Commission (FCC) |
| Certificates |
|---|
| Compliance certificates |
RoHS, UL, cUL, Federal Communications Commission (FCC) |
| Weight & dimensions |
|---|
| Width |
3.94" (100 mm) |
| Depth |
10.2" (259 mm) |
| Height |
13.8" (350 mm) |
| Weight |
23.8 lbs (10.8 kg) |
| Package width |
72.5" (1841 mm) |
| Package depth |
142.5" (3619 mm) |
| Package height |
175" (4445 mm) |
| Package weight |
24.5 lbs (11.1 kg) |
| Packaging data |
|---|
| Package width |
72.5" (1841 mm) |
| Package depth |
142.5" (3619 mm) |
| Package height |
175" (4445 mm) |
| Package weight |
24.5 lbs (11.1 kg) |
