Intelligent LCD, 12x NEMA 5-15R, USB-A, USB-C, 1500 VA, 900 W, Line Interactive, Simulated Sine Wave, AVR
Key Features
- Battery Backup - Supplies power long enough for equipment to properly shut down when utility power fails. Helps prevent loss of data and minimizes the component stress caused by a hard shutdown.
- Surge Protection - Diverts excess voltage away from sensitive electronic equipment during an AC power surge or power spike to prevent damage.
- Automatic Voltage Regulation (AVR) - AVR increases the AC power and maintains a safe voltage level without switching to battery mode and conserving battery life.
- Multifunction, Color LCD - Displays immediate, detailed information on the UPS battery and power conditions, alerting users to potential problems before they can affect critical equipment and cause downtime.
- Data Line Protection - Prevents power surges that travel through coaxial and ethernet lines from causing damage to electronics.
- Line Interactive Topology - Exists when a line interactive UPS has an autotransformer that regulates low voltages (e.g., brownouts) and over voltages (e.g., spikes) without having to switch to battery.
- Simulated Sine Wave Output - Provides a manufactured waveform output to supply cost-effective battery backup power for equipment that does not require sine wave output.
- ENERGY STAR - This model is an ENERGY STAR® certified Uninterruptible Power Supply (UPS) system. ENERGY STAR is the trusted, government-backed symbol for energy-efficient products and practices that help save money and protect the environment.
- GreenPower UPS™ Bypass Design - A patented design that allows utility power to bypass the UPS transformer, when AC power is stable, which reduces energy consumption, noise, and heat buildup.
- Ultra Quiet Design - Minimizes noise during operation for a quieter work environment.
- PowerPanel® Personal Software - Provides a user-friendly dashboard interface for controlling and monitoring the UPS. Free software download available.
- Three-Year Warranty - CyberPower will repair or replace a defective UPS system (including batteries) within three years of the purchase date. See warranty for details.
- Connected Equipment Guarantee - CyberPower will repair or replace properly connected equipment if it is damaged by a power surge.
Description
A mini-tower UPS with line interactive topology, the CyberPower Intelligent LCD CP1500AVRLCD3 provides battery backup (using simulated sine wave output) and surge protection for desktop computers, workstations, networking devices, and home entertainment systems. The CP1500AVRLCD3 uses Automatic Voltage Regulation (AVR) to correct minor power fluctuations without switching to battery power, which extends battery life. AVR is essential in areas where power fluctuations occur frequently. The CP1500AVRLCD3 comes with a three-year warranty (including coverage of batteries) and a $500,000 Connected Equipment Guarantee.
Specifications
| Power |
|---|
| Output power capacity |
1.5 kVA |
| Output power |
900 W |
| Input operation voltage (min) |
120 V |
| Input operation voltage (max) |
120 V |
| Surge energy rating |
1500 J |
| Output power factor |
0.6 |
| Input frequency |
57/63 Hz |
| Ports & interfaces |
|---|
| Cable length |
70.9" (1.8 m) |
| AC outlets quantity |
12 AC outlet(s) |
| AC outlet types |
NEMA 5-15R |
| Power plug |
NEMA 5-15P |
| USB port |
Yes |
| Ethernet LAN (RJ-45) ports |
2 |
| USB port type |
USB Type A/USB Type-C |
| Performance |
|---|
| UPS topology |
Line-Interactive |
| Audible alarm modes |
Overload alarm, Low battery alarm, Alarm when on battery, Fault |
| EMI/RFI noise filtering |
Yes |
| Surge protection |
Yes |
| Waveform |
Simulated sine |
| Automatic Voltage Regulation (AVR) |
Yes |
| LED indicators |
Power, Fault |
| Audible alarm(s) |
Yes |
| Features |
|---|
| UPS topology |
Line-Interactive |
| Output power capacity |
1.5 kVA |
| Audible alarm modes |
Overload alarm, Low battery alarm, Alarm when on battery, Fault |
| Output power |
900 W |
| Input operation voltage (min) |
120 V |
| Input operation voltage (max) |
120 V |
| Surge energy rating |
1500 J |
| EMI/RFI noise filtering |
Yes |
| Surge protection |
Yes |
| Waveform |
Simulated sine |
| Output power factor |
0.6 |
| Automatic Voltage Regulation (AVR) |
Yes |
| Audible alarm(s) |
Yes |
| Input frequency |
57/63 Hz |
| Battery |
|---|
| Battery technology |
Lead-Acid |
| Number of battery cells |
2 |
| Battery recharge time |
8 h |
| Typical backup time at half load |
12 min |
| Typical backup time at full load |
3 min |
| Battery voltage |
12 V |
| Battery capacity |
9 Ah |
| Replacement battery cartridge |
RB1290X2E |
| Design |
|---|
| Form factor |
Mini Tower |
| Product colour |
Black |
| Certification |
RoHS
UL1778
cUL 107 5th
FCC DOC Class B |
| Cable length |
70.9" (1.8 m) |
| LED indicators |
Power, Fault |
| Housing material |
Plastic |
| Display type |
LCD |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-15 - 45 °C |
| Operating relative humidity (H-H) |
0 - 95% |
| Storage relative humidity (H-H) |
0 - 95% |
| Operating altitude |
0 - 120000" (0 - 3048 m) |
| Non-operating altitude |
0 - 599960.6" (0 - 15239 m) |
| Certificates |
|---|
| Certification |
RoHS
UL1778
cUL 107 5th
FCC DOC Class B |
| Weight & dimensions |
|---|
| Width |
3.94" (100 mm) |
| Depth |
13.8" (350 mm) |
| Height |
10.2" (259 mm) |
| Weight |
23.8 lbs (10.8 kg) |
