WiFi 7 AiMesh Extendable Router, 4K-QAM, MLO, 2.5G WAN port, Four 1G ports, Commercial-Grade Network Security, Parental Control, IoT network, Kid’s network, VPN network
Key Features
- Ultrafast WiFi 7 – WiFi 7 (802.11be) dual-band extendable router boosts speeds up to 3600 Mbps, with 4096-QAM increasing a single frequency band’s transmission speed by 1.2 times
- Unleashing Multi-link operation (MLO) for Ultra-Smooth Connectivity – Link to multiple bands at the same time to ensure stable internet connections and efficient data transfers
- Hassle-free AiMesh Extendable Network – AiMesh extendable routers enable whole home seamless roaming with rich, advanced features
- Commercial-Grade Network Security – Network security with commercial-grade AiProtection, plus a one-tap security scan and Safe Browsing
Description
ASUS RT-BE55
Worry-Free Smart Home WiFi 7Elevate your smart home with blazing-fast dual-band Wi-Fi 7 speeds of up to 3600 Mbps and boosted coverage with AI-boosted Smart AiMesh technology. With next-gen ASUS Network Security and a suite of advanced network technologies such as IoT Network, the RT-BE55 safeguard your network end-to-end, 24/7.
Specifications
| Ethernet LAN features |
|---|
| Ethernet WAN |
Yes |
| Ethernet LAN interface type |
2.5 Gigabit Ethernet |
| Ethernet LAN |
Yes |
| Ethernet LAN data rates |
1000,2500 Mbit/s |
| Mobile network |
|---|
| SIM card slot |
No |
| 3G/4G USB modem compatibility |
No |
| Network |
|---|
| Wake-on-LAN ready |
Yes |
| Network address translation (NAT) |
Yes |
| Ethernet LAN interface type |
2.5 Gigabit Ethernet |
| Ethernet LAN |
Yes |
| VPN support |
Instant Guard
VPN Client L2TP
VPN Client Open VPN
VPN Client PPTP
VPN Client WireGuard
VPN Server IPSec
VPN Server Open VPN
VPN Server PPTP
VPN Server WireGuard |
| Port forwarding |
Yes |
| Ethernet LAN data rates |
1000,2500 Mbit/s |
| Port triggering |
Yes |
| Dynamic DNS (DDNS) |
Yes |
| Protocols |
|---|
| DMZ support |
Yes |
| DHCP server |
Yes |
| Security |
|---|
| VPN support |
Instant Guard
VPN Client L2TP
VPN Client Open VPN
VPN Client PPTP
VPN Client WireGuard
VPN Server IPSec
VPN Server Open VPN
VPN Server PPTP
VPN Server WireGuard |
| System event log |
Yes |
| Security algorithms |
SSH, WPA2-Enterprise, WPA2-Personal, WPA3-Enterprise, WPA, WPA3-Personal, WPS, WPA-Enterprise, WPA-Personal |
| Network address translation (NAT) |
Yes |
| NAT functionality |
PPTP Pass-Through, L2TP Pass-Through, IPSec Pass-Through, RTSP Pass-Through, H.323 Pass-Through, SIP Pass-Through, PPPoE relay |
| MAC address filtering |
Yes |
| Firewall security |
Maximum Firewall Keyword Filter : 64 • Maximum Firewall Network Service Filter : 32 • Maximum Firewall URL Filter : 64 |
| Firewall |
Yes |
| DMZ support |
Yes |
| Parental control |
Yes |
| Performance |
|---|
| Processor frequency |
2000 MHz |
| Processor cores |
4 |
| Built-in processor |
Yes |
| Internal memory |
512 MB |
| Flash memory |
128 MB |
| Weight & dimensions |
|---|
| Package width |
11.2" (285 mm) |
| Package weight |
2.27 lbs (1.03 kg) |
| Package height |
4.09" (104 mm) |
| Package depth |
7.6" (193 mm) |
| Width |
9.37" (238 mm) |
| Weight |
15.7 oz (446 g) |
| Height |
2.32" (59 mm) |
| Depth |
7.6" (193 mm) |
| Packaging content |
|---|
| Package type |
Box |
| Number of products included |
1 pc(s) |
| Quick start guide |
Yes |
| Cables included |
LAN (RJ-45) |
| AC adapter included |
Yes |
| Warranty card |
Yes |
| WAN connection |
|---|
| Ethernet WAN |
Yes |
| SIM card slot |
No |
| 3G/4G USB modem compatibility |
No |
| WAN connection type |
RJ-45 |
| Wireless LAN features |
|---|
| Top Wi-Fi standard |
Wi-Fi 7 (802.11be) |
| WLAN data transfer rate (max) |
3600 Mbit/s |
| Wi-Fi band |
Dual-band (2.4 GHz / 5 GHz) |
| Modulation |
4096-QAM, OFDMA |
| WLAN data transfer rate (first band) |
688 Mbit/s |
| WLAN data transfer rate (second band) |
2882 Mbit/s |
| Wi-Fi standards |
802.11a, Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be), 802.11b, Wi-Fi 6 (802.11ax), 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 6E (802.11ax) |
| Ports & interfaces |
|---|
| USB port |
No |
| Ethernet LAN (RJ-45) ports |
5 |
| Management features |
|---|
| WPS push button |
Yes |
| Wake-on-LAN ready |
Yes |
| Reset button |
Yes |
| Quality of Service (QoS) support |
Yes |
| Bandwidth control |
Yes |
| MU-MIMO technology |
Yes |
| Design |
|---|
| Product type |
Tabletop router |
| On/off switch |
Yes |
| LED indicators |
Power, LAN, WAN |
| Product colour |
Black |
| Other features |
|---|
| Internal memory |
512 MB |
| Flash memory |
128 MB |
| Antenna |
|---|
| Antenna design |
External |
| Antennas quantity |
4 |
| Features |
|---|
| Processor frequency |
2000 MHz |
| Processor cores |
4 |
| Built-in processor |
Yes |
| Internal memory |
512 MB |
| Flash memory |
128 MB |
| Power |
|---|
| Power source type |
AC |
| Output voltage |
12 V |
| Output current |
1.5 A |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50/60 Hz |
| Packaging data |
|---|
| Quick start guide |
Yes |
| Package width |
11.2" (285 mm) |
| Package weight |
2.27 lbs (1.03 kg) |
| Package type |
Box |
| Package height |
4.09" (104 mm) |
| Package depth |
7.6" (193 mm) |
| Cables included |
LAN (RJ-45) |
| AC adapter included |
Yes |
| Warranty card |
Yes |
| Number of products included |
1 pc(s) |
