0.7L, Intel Core Ultra 5, 2 x SO-DIMM DDR5, Intel Arc 140T, WiFi 7, Bluetooth 5.4, no OS
Key Features
- Powered by Intel Core Ultra Processors (Series 2) with up to 99 TOPS and 18% faster gen-on-gen performance for seamless operations
- Advanced thermal design ensures ultra-quiet cooling with 1.2x reduced noise for a refined experience
- Intel Wi-Fi 7 and Bluetooth 5.4 deliver up to 2.4x faster speeds and reliable, seamless connectivity
- Sleek 0.7L chassis with tool-free upgrades combines elegance with effortless customization
- Supports up to four 4K displays via HDMI 2.1 and Thunderbolt 4, with smart power-off for energy efficiency
- Built from sustainable materials, offering enduring quality with eco-conscious design
Description
Elegant Mini PC with up to Intel® Core™ Ultra 9 Processors (Series 2) and Intel Arc™ Graphics, Unleashing Unmatched Performance.Unleash Ultra Power, Embrace IntelligenceASUS NUC 15 Pro+ offers a perfect blend of cutting-edge performance and sophisticated design. Powered by the latest-generation Intel® Core™ Ultra 9 processor (Series 2) and Intel Arc™ graphics, NUC 15 Pro+ delivers unparalleled speed and stunning visuals, all in a sleek and compact metal chassis.
Specifications
| Processor |
|---|
| Built-in processor |
Yes |
| Processor family |
Intel Core Ultra 5 |
| Processor model |
225H |
| Processor threads |
14 |
| Processor cores |
14 |
| Processor boost frequency |
4.9 GHz |
| Processor manufacturer |
Intel |
| Processor cache |
18 MB |
| Performance cores |
4 |
| Efficient cores |
8 |
| Performance-core Max Turbo Frequency |
4.9 GHz |
| Efficient-core Max Turbo Frequency |
4.3 GHz |
| Performance-core base frequency |
1.7 GHz |
| Efficient-core base frequency |
1.3 GHz |
| Low Power Efficient-cores |
2 |
| Low Power Efficient-core Max Turbo Frequency |
2.5 GHz |
| Low Power Efficient-core Base Frequency |
700 MHz |
| Processor generation |
Intel Core Ultra (Series 2) |
| Memory |
|---|
| Memory slots type |
SO-DIMM |
| Number of memory slots |
2 |
| Supported memory types |
DDR5-SDRAM |
| Supported memory clock speeds |
6400 MHz |
| Maximum internal memory |
96 GB |
| Internal memory installed |
Yes |
| Storage |
|---|
| Supported storage drive types |
SSD |
| Storage drive sizes supported |
M.2 |
| Storage drive interface |
M.2 |
| SSD form factor |
M.2 |
| NVMe |
Yes |
| Storage drives installed |
No |
| Graphics |
|---|
| On-board graphics card |
Yes |
| Graphics card family |
Intel |
| On-board graphics card model |
Intel Arc 130T |
| Audio |
|---|
| Built-in speaker(s) |
No |
| Network |
|---|
| Ethernet LAN |
Yes |
| Wi-Fi |
Yes |
| Wi-Fi standards |
Wi-Fi 7 (802.11be) |
| LAN controller |
Intel I226-V |
| Bluetooth version |
5.4 |
| Bluetooth |
Yes |
| Top Wi-Fi standard |
Wi-Fi 7 (802.11be) |
| WLAN controller model |
Intel Wi-Fi 7 BE201 |
| Ports & interfaces |
|---|
| USB 2.0 ports quantity |
1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
3 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
1 |
| HDMI ports quantity |
2 |
| HDMI version |
2.1 |
| VGA (D-Sub) ports quantity |
0 |
| Ethernet LAN (RJ-45) ports |
1 |
| DC-in jack |
Yes |
| Thunderbolt 4 ports quantity |
2 |
| Design |
|---|
| Product type |
Mini PC barebone |
| On/off switch |
Yes |
| Product colour |
Silver |
| Cable lock slot type |
Kensington |
| Cable lock slot |
Yes |
| Performance |
|---|
| Windows operating systems supported |
Windows 11 x64 |
| Operating system installed |
No |
| Linux operating systems supported |
Ubuntu 24.04 LTS |
| Processor special features |
|---|
| Low Power Efficient-cores |
2 |
| Low Power Efficient-core Max Turbo Frequency |
2.5 GHz |
| Low Power Efficient-core Base Frequency |
700 MHz |
| Software |
|---|
| Windows operating systems supported |
Windows 11 x64 |
| Operating system installed |
No |
| Linux operating systems supported |
Ubuntu 24.04 LTS |
| Power |
|---|
| Power supply type |
External AC adapter |
| Power supply |
120 W |
| AC adapter output voltage |
19 V |
| AC adapter output current |
6.32 A |
| Weight & dimensions |
|---|
| Width |
5.67" (144 mm) |
| Depth |
4.41" (112 mm) |
| Height |
1.65" (42 mm) |
| Weight |
21.2 oz (600 g) |
