Out of stock
10Gigabit Layer2 Switches
Buffalo’s BS-MP series of 10 GbE switches offers an easy, cost-effective and energy-efficient way to extend your business network at blazing speeds. Plug and play installation requires no additional software or configuration; simply plug your network-ready devices into one of the available Ethernet ports. Each AUTO-MDIX port automatically detects and configures the correct connection while optional jumbo frame support and full duplex operation provide maximum performance. This switch is a perfect complement to the TeraStation 5010 line of NAS devices which has up to 2 native 10GbE ports and is compatible to 2.5, 5 and 10 GbE.
Buffalo BS-MP2012 network switch Managed L2 10G Ethernet (100/1000/10000) 19U Black
Part number
BS-MP2012
$1,248.60 CAD
12x 100M/1000M/2.5/5/10G Full-Duplex, 802.3az, 120Gbit/s, QoS, Auto-MDIX, 2.57kg
Description
Finally, a value switch scalable to 10 GbE10Gigabit Layer2 Switches
Buffalo’s BS-MP series of 10 GbE switches offers an easy, cost-effective and energy-efficient way to extend your business network at blazing speeds. Plug and play installation requires no additional software or configuration; simply plug your network-ready devices into one of the available Ethernet ports. Each AUTO-MDIX port automatically detects and configures the correct connection while optional jumbo frame support and full duplex operation provide maximum performance. This switch is a perfect complement to the TeraStation 5010 line of NAS devices which has up to 2 native 10GbE ports and is compatible to 2.5, 5 and 10 GbE.
Specifications
| Management features | |
|---|---|
| Reset button | Yes |
| Switch layer | L2 |
| Switch type | Managed |
| Web-based management | Yes |
| Quality of Service (QoS) support | Yes |
| Ports & interfaces | |
| Copper ethernet cabling technology | 10GBASE-T, 100BASE-TX, 1000BASE-T |
| Basic switching RJ-45 Ethernet ports quantity | 12 |
| Basic switching RJ-45 Ethernet ports type | 10G Ethernet (100/1000/10000) |
| Virtual LAN features | |
| VLAN support | Yes |
| Network | |
| Networking standards | IEEE 802.3ab, IEEE 802.3an, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3u |
| Full duplex | Yes |
| Cable types supported | Cat5, Cat5e, Cat6a |
| Copper ethernet cabling technology | 10GBASE-T, 100BASE-TX, 1000BASE-T |
| VLAN support | Yes |
| Link aggregation | Yes |
| Auto MDI/MDI-X | Yes |
| 10G support | Yes |
| Data transmission | |
| MAC address table | 1600 entries |
| Latency (10 Gbps) | 10 µs |
| Jumbo frames support | Yes |
| Security | |
| Loop protection | Yes |
| Design | |
| Rack mounting | Yes |
| Product colour | Black |
| Reset button | Yes |
| Form factor | 19U |
| LED indicators | Activity, Link, Power, Speed |
| Certification | VCCI A, FCC / IC A, UL, CE, CB |
| Performance | |
| Maximum data transfer rate | 120000 Mbit/s |
| Buffer size | 2000 KB |
| Power | |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power consumption (max) | 42 W |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | No |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 °C |
| Operating relative humidity (H-H) | 10 - 85% |
| Weight & dimensions | |
| Width | 13" (330 mm) |
| Depth | 9.06" (230 mm) |
| Height | 1.73" (44 mm) |
| Weight | 5.67 lbs (2.57 kg) |
| Packaging data | |
| Rack mount kit | Yes |
| Manual | Yes |
| Packaging content | |
| Rack mount kit | Yes |
| Manual | Yes |
