StarTech.com PEX867WAC22 network card Internal Ethernet / WLAN 867 Mbit/s

StarTech.com PEX867WAC22 network card Internal Ethernet / WLAN 867 Mbit/s

123.92 CAD

Skip to product information
StarTech.com PEX867WAC22 network card Internal Ethernet / WLAN 867 Mbit/s
1/4

StarTech.com PEX867WAC22 network card Internal Ethernet / WLAN 867 Mbit/s

Part number PEX867WAC22
123.92 CAD
Taxes and shipping calculated at checkout.
In stock

Enjoy Free Shipping on orders over 2000 CAD

Shipping time varies based your on location.

Specifications
Weight
0.388 kg
Shipping + Returns

Shipping Policy

Ships to: Canada & USA via UPS, DHL, & Canada Post.

Fast Dispatch: Orders before 2 PM EST process same-day.

Options: Standard (Ground) and Express (Air) shipping available.

Heavy Items: Heavy freight usually requires1-2 extra days for Processing

Returns & Refunds

Return Period: Request a return within 14 days of delivery.

Restocking Fee: 20% fee applies to non-defective/change-of-mind returns.

Condition: Items must be returned in original packaging (New or Like New).

Final Sale: Software, licenses, and special orders cannot be returned.

Add high speed 802.11ac WiFi connectivity to a desktop PC through a PCI Express slot with dual band 2.4/5 GHz frequencies and up to 867Mbps

The PEX867WAC22 PCI Express AC1200 Wireless Network Adapter lets you add dual-band Wireless-AC connectivity to a desktop computer through a PCIe slot.

With increased demand on network resources, this Wireless-AC adapter gives you exceptional speed and range for your office or home wireless network when paired with an 802.11ac router. This dual-band WiFi adapter supports maximum data rates of up to 867 Mbps on the 5GHz band (3x the speed of Wireless-N), plus up to 300 Mbps on the 2.4GHz band, making it the perfect solution for applications like HD video streaming, online conferencing, file transfers and gaming.

This versatile PCIe wireless card features a 2T2R (2 transmitter, 2 receiver) detachable antenna design, with an included magnetic antenna stand that can easily be mounted to the top or side of your PC case. Plus, the controller card is equipped with a standard profile bracket and includes a low-profile/half-height bracket for installation in small form-factor computers. To integrate with all of your networking devices, the adapter is also backward compatible with 802.11a/b/g/n networks.

Backed by a StarTech.com 2-year warranty, with free lifetime technical support.

The StarTech.com Advantage

- Experience faster wireless speed and better coverage with 802.11ac compatibility
- Ensure fast and dependable wireless networking, with less interference through dual band 2.4 GHz / 5 GHz operation
- Connect to existing wireless networks with 802.11a/b/g/n backward compatibility
Ports & interfaces
Internal Yes
Connectivity technology Wireless
Host interface PCI Express
Interface Ethernet / WLAN
Bandwidth
Maximum data transfer rate 867 Mbit/s
Full duplex Yes
Wireless LAN features
Wi-Fi Yes
Wi-Fi band Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard Wi-Fi 5 (802.11ac)
Wi-Fi standards 802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
WLAN data transfer rates supported 300,867 Mbit/s
Network
Chipset RTL8812AE
Maximum data transfer rate 867 Mbit/s
Wi-Fi Yes
Wi-Fi band Dual-band (2.4 GHz / 5 GHz)
Networking standards IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Top Wi-Fi standard Wi-Fi 5 (802.11ac)
Wi-Fi standards 802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
WLAN data transfer rates supported 300,867 Mbit/s
Security algorithms 128-bit WEP, 64-bit WEP, TKIP, WEP, WPA, WPA2
Full duplex Yes
Frequency range 2.4 - 5 GHz
Gain 5 dBi
Antenna
Antenna Yes
Gain 5 dBi
Frequency range 2.4 - 5 GHz
Detachable antenna(s) Yes
Antenna connector type RP-SMA
Design
Internal Yes
Product colour Green
Chipset RTL8812AE
Antenna Yes
LED indicators Activity, Link
Antenna connector type RP-SMA
Detachable antenna(s) Yes
System requirements
Windows operating systems supported Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Server operating systems supported Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Weight & dimensions
Width 3.27" (83 mm)
Depth 4.72" (120 mm)
Height 0.709" (18 mm)
Weight 13.1 oz (370 g)
Package width 6.14" (156 mm)
Package depth 8.27" (210 mm)
Package height 2.32" (59 mm)
Package weight 13.7 oz (388 g)
Packaging data
Package width 6.14" (156 mm)
Package depth 8.27" (210 mm)
Package height 2.32" (59 mm)
Package weight 13.7 oz (388 g)
Manual Yes
Packaging content
Manual Yes
Performance
Security algorithms 128-bit WEP, 64-bit WEP, TKIP, WEP, WPA, WPA2
Windows operating systems supported Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Server operating systems supported Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Technical details
Harmonized System (HS) code 85176990
Compliance certificates RoHS
Other features
Chipset RTL8812AE
Manual Yes
Gain 5 dBi
Detachable antenna(s) Yes
Harmonized System (HS) code 85176990
Logistics data
Harmonized System (HS) code 85176990
