Serious gaming specs
As a member of the TUF Gaming family, the F16 boasts some seriously impressive specs, giving you access to the very best of gaming on Windows 11. Featuring up to an Intel® Core™ Ultra 9 processor 275HX and up to an NVIDIA® GeForce RTX™ 5070 Laptop GPU, the F16 can easily play the latest games or keep your workflow on schedule. Paired with up to 32GB of DDR5 5600MHz memory per slot and up to 4TB of expandable PCIe Gen 4 storage, this little machine is ready for anything, right out of the box.

Design
Colour name	Jaeger Gray
Product type	Laptop
Product colour	Gray
Form factor	Clamshell
Market positioning	Gaming
Introduction year	2025
Display
Display diagonal	16"
Display resolution	1920 x 1200 pixels
Touchscreen	No
HD type	WUXGA
Panel type	IPS-Level
Anti-glare screen	Yes
Maximum refresh rate	165 Hz
RGB colour space	sRGB
Colour gamut	100%
Native aspect ratio	16:10
Processor
Processor generation	Intel® Core™ i7 (14th gen)
Processor family	Intel® Core™ i7
Processor cache type	Smart Cache
Processor model	i7-14650HX
Processor boost frequency	5.2 GHz
Processor cores	16
Processor threads	24
Processor cache	30 MB
Motherboard chipset	Intel HM770 Express
Processor manufacturer	Intel
Processor base power	55 W
Maximum turbo power	157 W
Efficient-core base frequency	1.6 GHz
Performance-core base frequency	2.2 GHz
Efficient-core Max Turbo Frequency	3.7 GHz
Performance-core Max Turbo Frequency	5.2 GHz
Performance cores	8
Efficient cores	8
Memory
Internal memory	16 GB
Internal memory type	DDR5-SDRAM
Memory clock speed	5600 MHz
Memory layout (slots x size)	2 x 8 GB
Memory slots	2x SO-DIMM
Maximum internal memory	64 GB
Memory form factor	SO-DIMM
Memory channels	Dual-channel
Storage
Optical drive type	No
Total storage capacity	1 TB
Storage media	SSD
SSD form factor	M.2
Number of SSDs installed	1
SSD capacity	1 TB
SSD interface	PCI Express 4.0
Card reader integrated	No
Total SSDs capacity	1 TB
NVMe	Yes
Graphics
Discrete graphics card	Yes
NVIDIA G-SYNC	Yes
On-board graphics card family	Intel® UHD Graphics
On-board graphics card model	Intel® UHD Graphics
Discrete graphics card model	NVIDIA GeForce RTX 5050
Discrete graphics memory type	GDDR7
On-board graphics card	Yes
Discrete graphics card memory	8 GB
Discrete GPU manufacturer	NVIDIA
On-board GPU manufacturer	Intel
Audio
Audio system	Dolby Atmos
Number of built-in speakers	2
Built-in microphone	Yes
Camera
Front camera	Yes
Front camera resolution	1920 x 1080 pixels
Front camera HD type	Full HD
Infrared (IR) camera	Yes
Windows Hello	Yes
Optical drive
Optical drive type	No
Network
Mobile network connection	No
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
Bluetooth	Yes
Wi-Fi standards	Wi-Fi 6E (802.11ax)
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Bluetooth version	5.3
Antenna type	2x2
Ports & interfaces
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	3
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	1
HDMI ports quantity	1
HDMI version	2.1
Ethernet LAN (RJ-45) ports	1
USB Type-C DisplayPort Alternate Mode	Yes
Combo headphone/mic port	Yes
USB Power Delivery (USB PD)	Yes
Thunderbolt 4 ports quantity	1
Intel® Thunderbolt 4	Yes
Performance
Motherboard chipset	Intel HM770 Express
Keyboard
Pointing device	Touchpad
Numeric keypad	Yes
Keyboard backlit	Yes
Keyboard backlit colour	RGB
Keyboard backlit zone	1-zone RGB
Copilot key	Yes
Software
Operating system installed	Windows 11 Home
Operating system architecture	64-bit
Microsoft Copilot	Yes
Battery
Battery technology	Lithium-Ion (Li-Ion)
Number of battery cells	4
Battery capacity	90 Wh
Power
AC adapter power	280 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	14 A
AC adapter output voltage	20 V
USB Power Delivery (USB PD)	Yes
USB Type-C charging port	Yes
Security
Cable lock slot	Yes
Cable lock slot type	Kensington
Password protection	Yes
Password protection type	BIOS, User
Face recognition	Yes
Windows Hello	Yes
Weight & dimensions
Weight	4.85 lbs (2.2 kg)
Width	13.9" (354 mm)
Depth	10.6" (269 mm)
Height (front)	0.705" (1.79 cm)
Height (rear)	1.07" (2.73 cm)
Packaging data
AC adapter included	Yes
Packaging content
AC adapter included	Yes
Technical details
Discrete graphics card memory	8 GB
Other features
Audio system	Dolby Atmos
On-board graphics card	Yes
AC adapter included	Yes
Anti-glare screen	Yes
