HPE Aruba Networking AP-503R-RW 1490 Mbit/s White
617.55 CAD
Skip to product information
Out of stock
HPE Aruba Networking AP-503R-RW 1490 Mbit/s White
Part number
R8N04A#ABA
617.55 CAD
Taxes and shipping calculated at checkout.
Enjoy Free Shipping on orders over 2000 CAD
Shipping time varies based your on location.
Specifications
Weight
0.59 kg
Shipping + Returns
Shipping Policy
Ships to: Canada & USA via UPS, DHL, & Canada Post.
Fast Dispatch: Orders before 2 PM EST process same-day.
Options: Standard (Ground) and Express (Air) shipping available.
Heavy Items: Heavy freight usually requires1-2 extra days for Processing
Returns & Refunds
Return Period: Request a return within 14 days of delivery.
Restocking Fee: 20% fee applies to non-defective/change-of-mind returns.
Condition: Items must be returned in original packaging (New or Like New).
Final Sale: Software, licenses, and special orders cannot be returned.
HPE Aruba Networking 500R Series Remote Access Points enable IT teams to deliver cost-effective Wi-Fi 6 coverage in a compact desktop form factor to hundreds or even thousands of remote workers. With 1.49 Gbps maximum combined speed, these APs are well-suited for small branches and remote work. Two wired ports provide additional device support for work from home and an add-on LTE USB module delivers cellular backhaul capabilities.
| Performance | |
|---|---|
| Maximum data transfer rate | 1490 Mbit/s |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Spread spectrum method | DSSS, OFDM, OFDMA |
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| Auto MDI/MDI-X | Yes |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3az |
| MIMO | Yes |
| Features | |
| 6 GHz | No |
| Maximum data transfer rate | 1490 Mbit/s |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Spread spectrum method | DSSS, OFDM, OFDMA |
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| Auto MDI/MDI-X | Yes |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3az |
| MIMO | Yes |
| Maximum data transfer rate (2.4 GHz) | 574 Mbit/s |
| Maximum data transfer rate (5 GHz) | 1200 Mbit/s |
| Trusted Platform Module (TPM) | Yes |
| Security | |
| Security algorithms | WMM, WPA, WPA2, WPA3 |
| Ports & interfaces | |
| USB connector type | Micro-USB B, USB Type-A |
| USB 2.0 ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
| Power | |
| Power consumption (max) | 15.4 W |
| Power supply | 18 W |
| Power over Ethernet (PoE) | No |
| DC voltage range | 12 V |
| Design | |
| Placement | Desk, Wall |
| LED indicators | Reset, Status, System |
| Product colour | White |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Antenna | |
| Antenna type | Internal |
| Antennas quantity | 2 |
| Antenna gain level (max) | 5.1 dBi |
| Antenna direction type | Omni-directional |
| Antenna features | Integrated antenna |
| Weight & dimensions | |
| Width | 5.91" (150 mm) |
| Depth | 5.91" (150 mm) |
| Height | 1.54" (39 mm) |
| Weight | 11.3 oz (320 g) |
| Package width | 9.45" (240 mm) |
| Package depth | 6.69" (170 mm) |
| Package height | 1.97" (50 mm) |
| Package weight | 21.2 oz (600 g) |
| Packaging data | |
| Package width | 9.45" (240 mm) |
| Package depth | 6.69" (170 mm) |
| Package height | 1.97" (50 mm) |
| Package weight | 21.2 oz (600 g) |
| Operational conditions | |
| Operating relative humidity (H-H) | 5 - 95% |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -25 - 55 °C |
| Storage relative humidity (H-H) | 10 - 100% |
