HPE Aruba Networking Aruba Instant On 1430 8G Class4 PoE 64W Unmanaged L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) White
Part number
R8R46A#ABA
$212.05 CAD
HPE Aruba Networking Aruba Instant On 1430 8G Class4 PoE 64W, Unmanaged, L2, Gigabit Ethernet (10/100/1000), Full duplex, Power over Ethernet (PoE)
Description
HPE Aruba Networking Aruba Instant On 1430 8G Class4 PoE 64W. Switch type: Unmanaged, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 8. Full duplex. MAC address table: 8192 entries, Switching capacity: 16 Gbit/s. Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE.... Power over Ethernet (PoE)Specifications
| Ports & interfaces | |
|---|---|
| Copper ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-T |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Performance | |
| Packet buffer memory | 2 MB |
| Management features | |
| Switch layer | L2 |
| Switch type | Unmanaged |
| Quality of Service (QoS) support | Yes |
| Network | |
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Full duplex | Yes |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-T |
| Flow control support | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Auto-sensing | Yes |
| 10G support | No |
| Half duplex | Yes |
| Data transmission | |
| MAC address table | 8192 entries |
| Switching capacity | 16 Gbit/s |
| Throughput | 11.9 Mpps |
| Latency (10-100 Mbps) | 2.7 µs |
| Latency (1 Gbps) | 1.8 µs |
| Jumbo frames support | Yes |
| Packet buffer memory | 2 MB |
| Design | |
| Product colour | White |
| Power | |
| Power supply included | Yes |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power consumption (max) | 90 W |
| Number of power supply units | 1 |
| Power source | AC |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | Yes |
| Total Power over Ethernet (PoE) budget | 64 W |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 15 - 95% |
| Storage relative humidity (H-H) | 15 - 90% |
| Weight & dimensions | |
| Width | 6.97" (177 mm) |
| Depth | 5.91" (150 mm) |
| Height | 1.46" (37 mm) |
| Weight | 27.2 oz (770 g) |
| Other features | |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
