AI-powered Performance

Revolutionize every task using Lenovo's cutting-edge AI-accelerated functions to elevate efficiency. Designed for demanding multitasking and data-intensive tasks, the Lenovo ThinkCentre 90t Gen 5 (Intel) emphasizes power management, delivering the necessary performance enhancements precisely when and where they are needed.

Focused on Security

Lenovo ThinkShield provides comprehensive security by integrating hardware and software to safeguard your data. Through the discrete Trusted Platform Module (dTPM) chip, passwords and data are encrypted, while BIOS-based Smart USB Protection thwarts unauthorized access via peripherals. By leveraging the Intel vPro® platform, it elevates asset security standards.

Optimal Processing Power

No task is too complex to keep the Lenovo ThinkCentre M90t Gen 5 (Intel) from keeping pace with the speed of business. Equipped with advanced Intel vPro® Enterprise technology and Intel® Core™ processors, this desktop ensures exceptional performance. Elevate every digital assignment with Lenovo’s cutting-edge AI-accelerated functionalities, enhancing overall performance.

Enhanced Versatility

With its user-friendly features, the ThinkCentre M90t Gen 5 (Intel) allows you to effortlessly share device control, data, and screen projection across multiple devices. The Smart Cable revolutionizes the way devices collaborate by seamlessly integrating USB-A and USB-C® connections. Experience the convenience of swift data transfers and smooth productivity.

Environmental Sustainability

This workstation is meticulously designed with a strong focus on recycling. Our dedication to sustainability shines through the incorporation of recycled post-consumer content (PCC) in different parts such as the chassis, keyboard, and mouse. The packaging is thoughtfully crafted using a blend of recycled and sustainably sourced materials.

Processor
Processor generation	Intel® Core™ i7 (14th gen)
Processor family	Intel® Core™ i7
Processor manufacturer	Intel
Processor model	i7-14700
Processor cores	20
Processor cache type	Smart Cache
Processor boost frequency	5.4 GHz
Processor cache	33 MB
Processor threads	28
Number of processors installed	1
Performance cores	8
Efficient cores	12
Performance-core base frequency	2.1 GHz
Efficient-core base frequency	1.5 GHz
Processor base power	65 W
Maximum turbo power	219 W
Efficient-core Max Turbo Frequency	4.2 GHz
Performance-core Max Turbo Frequency	5.3 GHz
Memory
Internal memory	32 GB
Internal memory type	DDR5-SDRAM
Maximum internal memory	128 GB
Memory layout (slots x size)	2 x 16 GB
Memory slots	4x DIMM
Memory clock speed	4400 MHz
Memory channels	Dual-channel
Storage
Total storage capacity	1 TB
Optical drive type	DVD±RW
Card reader integrated	No
Storage media	SSD
Number of storage drives installed	1
Number of SSDs installed	1
SSD capacity	1 TB
SSD interface	PCI Express 4.0
SSD form factor	M.2
Total SSDs capacity	1 TB
NVMe	Yes
Graphics
Discrete graphics card	No
Discrete graphics card model	Not available
On-board graphics card model	Intel UHD Graphics 770
On-board graphics card family	Intel® UHD Graphics
On-board graphics card	Yes
On-board GPU manufacturer	Intel
Optical drive
Optical drive type	DVD±RW
Network
Ethernet LAN	Yes
Ethernet LAN data rates	100,1000 Mbit/s
Cabling technology	10/100/1000Base-T(X)
Wi-Fi	Yes
Wi-Fi standards	Wi-Fi 6E (802.11ax)
Bluetooth	Yes
Bluetooth version	5.3
WLAN controller model	Intel Wi-Fi 6E AX211
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
Antenna type	2x2
WLAN controller manufacturer	Intel
Ports & interfaces
USB 2.0 ports quantity	0
HDMI ports quantity	1
HDMI version	2.1
DisplayPorts quantity	3
Ethernet LAN (RJ-45) ports	1
Line-out	Yes
Microphone in	Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	6
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	1
Thunderbolt 3 ports quantity	0
Combo headphone/mic port	Yes
Design
Product colour	Black
Chassis type	Tower
Placement supported	Vertical
Cable lock slot	Yes
Cable lock slot type	Kensington
Volume	17 L
Colour name	Black
Performance
Product type	PC
Motherboard chipset	Intel Q670
Audio system	High Definition Audio
Password protection	Yes
Password protection type	BIOS, HDD, Power on
Audio chip	Realtek ALC897Q-CG
Number of speakers	1
Trusted Platform Module (TPM)	Yes
Built-in speaker(s)	Yes
Trusted Platform Module (TPM) version	2.0
Software
Operating system installed	Windows 11 Pro
Operating system architecture	64-bit
Operating system language	English
Power
Power supply	300 W
Power supply input frequency	50/60 Hz
Power supply input voltage	100 - 240 V
Operational conditions
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80%
Operating altitude	0 - 120000" (0 - 3048 m)
Non-operating altitude	0 - 480000" (0 - 12192 m)
Storage temperature (T-T)	-40 - 60 °C
Storage relative humidity (H-H)	10 - 90%
Certificates
Certification	ErP Lot 3 TCO Certified 9.0 MIL-STD-810H
Compliance certificates	RoHS
Sustainability
Sustainability certificates	ENERGY STAR, EPEAT Gold, ErP, GREENGUARD, TCO
Weight & dimensions
Volume	17 L
Width	6.69" (170 mm)
Depth	11.7" (298 mm)
Height	14.8" (376 mm)
Weight	14.3 lbs (6.5 kg)
Package width	10.8" (275 mm)
Package depth	15.6" (395 mm)
Package height	21.3" (540 mm)
Package weight	21.6 lbs (9.8 kg)
Packaging data
Package width	10.8" (275 mm)
Package depth	15.6" (395 mm)
Package height	21.3" (540 mm)
Package weight	21.6 lbs (9.8 kg)
Packaging content
Display included	No
Mouse included	Yes
Keyboard included	Yes
Mouse connectivity	Wired
Keyboard connectivity	Wired
Technical details
Sustainability certificates	ENERGY STAR, EPEAT Gold, ErP, GREENGUARD, TCO
Compliance certificates	RoHS
Other features
Processor manufacturer	Intel
Number of speakers	1
Trusted Platform Module (TPM)	Yes
On-board graphics card	Yes
Built-in speaker(s)	Yes
