ThinkPad P14s Gen 5 Intel

This notebook combines advanced technology with unparalleled durability, setting the standard for high-performance computing. Equipped with up to Intel® H Series Core™ Ultra 9 Processor and optional NVIDIA® RTX 500 GPU, it allows creative professionals to bring their visions to life with unparalleled speed and precision. Whether rendering complex 3D models, editing highresolution videos, or designing immersive digital experiences, it delivers uncompromising performance to enhance the creative output. With support for up to 96GB DDR5 memory, users can tackle multiple tasks simultaneously without any
slowdown.

Design
Colour name	Black
Product type	Laptop
Product colour	Black
Form factor	Clamshell
Housing material	Aluminum
Display
Display diagonal	14.5"
Display resolution	3072 x 1920 pixels
Touchscreen	No
HD type	3K
Display brightness	430 cd/m²
Panel type	IPS
Anti-glare screen	Yes
Maximum refresh rate	120 Hz
RGB colour space	DCI-P3
Colour gamut	100%
Native aspect ratio	16:10
Low Blue Light technology	Yes
Processor
Processor generation	Intel® Core™ Ultra (Series 1)
Processor family	Intel Core Ultra 9
Processor cache type	Smart Cache
Processor model	185H
Processor boost frequency	5.1 GHz
Processor cores	16
Processor threads	22
Processor cache	24 MB
Motherboard chipset	Intel SoC
Processor manufacturer	Intel
Processor base power	45 W
Maximum turbo power	115 W
Efficient-core base frequency	1.8 GHz
Performance-core base frequency	2.3 GHz
Efficient-core Max Turbo Frequency	3.8 GHz
Performance-core Max Turbo Frequency	5.1 GHz
Performance cores	6
Efficient cores	8
Low Power Efficient-core Base Frequency	1000 MHz
Low Power Efficient-core Max Turbo Frequency	2.5 GHz
Low Power Efficient-cores	2
Neural processor unit (NPU)
Neural processor unit (NPU)	Intel AI Boost
Sparsity support	Yes
Windows Studio effects support	Yes
AI software frameworks supported by NPU	DirectML, ONNX RT, OpenVINO, Windows ML
Memory
Internal memory	64 GB
Internal memory type	DDR5-SDRAM
ECC	No
Memory clock speed	5600 MHz
Memory layout (slots x size)	2 x 32 GB
Memory slots	2x SO-DIMM
Maximum internal memory	96 GB
Memory form factor	SO-DIMM
Memory channels	Dual-channel
Non-ECC	Yes
Storage
Optical drive type	No
Total storage capacity	1 TB
Storage media	SSD
SSD form factor	M.2
Number of SSDs installed	1
SSD capacity	1 TB
SSD interface	PCI Express 4.0
Card reader integrated	No
Total SSDs capacity	1 TB
NVMe	Yes
M.2 SSD size	2280 (22 x 80 mm)
Graphics
Discrete graphics card	No
On-board graphics card family	Intel Arc Graphics
On-board graphics card model	Intel Arc Graphics
Discrete graphics card model	Not available
On-board graphics card	Yes
On-board GPU manufacturer	Intel
Audio
Audio chip	Realtek ALC3287
Number of microphones	2
Audio system	High Definition Audio
Number of built-in speakers	2
Speaker power	2 W
Built-in microphone	Yes
Camera
Front camera	Yes
Front camera resolution (numeric)	5 MP
Privacy camera	Yes
Privacy type	Privacy shutter
Infrared (IR) camera	Yes
Windows Hello	Yes
Optical drive
Optical drive type	No
Network
Mobile network connection	No
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
Bluetooth	Yes
WLAN controller model	Intel Wi-Fi 6E AX211
Wi-Fi standards	Wi-Fi 6E (802.11ax)
Ethernet LAN	Yes
Ethernet LAN data rates	100,1000 Mbit/s
Bluetooth version	5.3
WWAN	Not installed
Near Field Communication (NFC)	No
Antenna type	2x2
WLAN controller manufacturer	Intel
Ports & interfaces
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
HDMI ports quantity	1
HDMI version	2.1
Ethernet LAN (RJ-45) ports	1
USB Type-C DisplayPort Alternate Mode	Yes
Combo headphone/mic port	Yes
USB Sleep-and-Charge	Yes
USB4 Gen 2x2 ports quantity	2
Intel® Thunderbolt 4	Yes
Performance
Motherboard chipset	Intel SoC
Keyboard
Pointing device	ThinkPad UltraNav
Numeric keypad	No
Spill-resistant keyboard	Yes
Keyboard backlit	Yes
Keyboard language	English
Software
Operating system installed	Windows 11 Pro
Operating system architecture	64-bit
Operating system language	English
Battery
Battery technology	Lithium Polymer (LiPo)
Battery capacity	75 Wh
Power
AC adapter power	100 W
AC adapter frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
USB Type-C charging port	Yes
Security
Cable lock slot	Yes
Cable lock slot type	Kensington
Fingerprint reader	Yes
Trusted Platform Module (TPM)	Yes
Password protection	Yes
Password protection type	BIOS, SSD, Supervisor, User
Windows Hello	Yes
Smart card reader	Yes
Trusted Platform Module (TPM) version	2.0
Operational conditions
Operating temperature (T-T)	5 - 35 °C
Storage temperature (T-T)	5 - 43 °C
Operating relative humidity (H-H)	8 - 95%
Storage relative humidity (H-H)	5 - 95%
Certificates
Compliance certificates	RoHS
Sustainability
Sustainability certificates	ENERGY STAR, EPEAT Gold, TCO
Weight & dimensions
Weight	3.55 lbs (1.61 kg)
Width	12.8" (325.5 mm)
Depth	8.96" (227.6 mm)
Height	0.728" (18.5 mm)
Packaging data
AC adapter included	Yes
Packaging content
AC adapter included	Yes
Technical details
Sustainability certificates	ENERGY STAR, EPEAT Gold, TCO
Compliance certificates	RoHS
Other features
WLAN controller model	Intel Wi-Fi 6E AX211
Audio system	High Definition Audio
On-board graphics card	Yes
AC adapter included	Yes
Anti-glare screen	Yes
