Accurate and Vivid Colors
Featuring self-lighting pixels, the display maintains vivid colors and high contrast ratio even when the display becomes transparent. It brings content to life from wide viewing angles, and the content blends into its surroundings seamlessly and naturally.

Intuitive P-Cap Touch
By adding P-Cap touch sensor film to the display, the utilization possibilities expand to various industries where customer interaction services are demanding. Users could enjoy its fascinating content using their fingertips.

High Transparency
LG’s OLED technology makes the Transparent OLED Touch Signage have slimmer structure without backlight unit nor a liquid crystal layer, achieving high transparency even with P-Cap touch film. While clearly showing objects behind the screen, it overlays the relevant information right before them.

Protective Tempered Glass
Touching a display directly can cause damage or scratches. The tempered front glass protects product from such external impacts and its anti-shatter glass is designed to minimize customers’ injuries.

Enhanced Spatial Versatility
Experience the extraordinary with the state-of-the-art LG Transparent OLED Signage, which breaks down the barriers between the screen and surrounding environment, seamlessly connecting different spaces and people.

Display
LED backlight	Yes
Display diagonal	30"
Display resolution	1366 x 768 pixels
Display brightness	600 cd/m²
HD type	HD
Response time	8 ms
Contrast ratio (typical)	200000:1
Viewing angle, horizontal	178°
Viewing angle, vertical	178°
Display number of colours	1.073 billion colors
Panel life	30000 h
Touchscreen	Yes
Panel type	OLED
Native aspect ratio	16:9
Display technology	OLED
Transparency	37%
Touchscreen technology	Projected capacitive system
Haze rate	3%
Glass thickness	0.118" (3 mm)
Ports & interfaces
Ethernet LAN	Yes
HDMI ports quantity	1
DVI port	No
Remote (IR) output	1
Remote (IR) input	1
USB port	Yes
Audio (L/R) out	1
Ethernet LAN (RJ-45) ports	2
RS-232C	Yes
DisplayPorts quantity	2
DisplayPorts out	1
DisplayPorts in	1
HDMI input ports quantity	1
USB 2.0 Type-B ports quantity	3
Design
Product design	Digital signage flat panel
Product colour	Silver
Placement supported	Indoor
Orientation	Horizontal/Vertical
Bezel width (top)	0.311" (7.9 mm)
Bezel width (side)	0.311" (7.9 mm)
Bezel width (bottom)	4.53" (11.5 cm)
Screen shape	Flat
Performance
Purpose	Commercial
Operating hours (hours/days)	18/7
On Screen Display (OSD) languages	Arabic, Simplified Chinese, Traditional Chinese, Czech, Danish, German, Dutch, English, Spanish, Finnish, French, Greek, Italian, Japanese, Korean, Norwegian, Polish, Portuguese, Russian, Swedish, Turkish
On Screen Display (OSD)	Yes
HDCP	Yes
HDCP version	1.4/2.2
Panel life	30000 h
Windows operating systems supported	Windows 10, Windows 11
Power
Power consumption (typical)	45 W
Power consumption (standby)	0.5 W
Heat dissipation	154 BTU/h
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	86 W
Computer system
Internal memory	16 GB
Windows operating systems supported	Windows 10, Windows 11
Weight & dimensions
Width (with stand)	17.7" (449.2 mm)
Display width	26.8" (680.2 mm)
Display depth	0.602" (15.3 mm)
Display height	19.5" (496.2 mm)
Display weight	9.26 lbs (4.2 kg)
Base width	17.7" (44.9 cm)
Base depth	1.69" (4.28 cm)
Base height	11.4" (28.9 cm)
Base weight	5.29 lbs (2.4 kg)
Packaging data
Package width	32.5" (826 mm)
Package depth	7.68" (195 mm)
Package height	23.3" (593 mm)
Package weight	22.3 lbs (10.1 kg)
Remote control included	Yes
Cables included	HDMI, Power, USB
Packaging content
Remote control included	Yes
Cables included	HDMI, Power, USB
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80%
Thin Client
Internal memory	16 GB
Features
Heat dissipation (max)	294 BTU/h
Technical details
Panel type	OLED
DisplayPorts out	1
DisplayPorts in	1
Other features
Width (with stand)	17.7" (449.2 mm)
Power consumption (max)	86 W
Panel type	OLED
DisplayPorts out	1
DisplayPorts in	1
Display technology	OLED
Bezel width (top)	0.311" (7.9 mm)
Bezel width (side)	0.311" (7.9 mm)
Bezel width (bottom)	4.53" (11.5 cm)
Windows operating systems supported	Windows 10, Windows 11
