Wireless IoT Gateway Device for medical devices Enterprise Wi-Fi 5G (802.11ac) Wi-Fi for Business Critical IoT Connectivity Delivering reliable and always on Wi-Fi® 5 (802.11ac) connectivity, the Lantronix® SGX 5150 Wi-Fi IoT gateway offers a module solution designed specifically for business critical industrial and commercial applications. With a production ready software stack, enterprise-class device security framework, modular RF certification and pre-integrated device management capabilities, SGX 5150 simplifies deployments and accelerates availability of robust WLAN connected IoT products. Production Ready Connectivity and Networking Enable quick deployment within challenging industrial environments, with integrated support for communication with multiple host interfaces and configuration based automatic Wi-Fi and network connection management for multiple network interfaces. Leverage customer proven embedded data communication applications, device management capabilities and integrated security frameworks to build customized gateway functionality with a faster time to market for various end-to-end IoT solution deployments. The SGX5150 XL which meets the customer needs looking for increased storage of valuable data, without the need to buy flash storage. It provides the ease of inserting and maintaining an external USB flash drive for purposes of data collection locally to the SGX 5150 XL InfiniShield – Comprehensive Device Security Framework Secure Wi-Fi connectivity requires supporting scalable enterprise class Wi-Fi via Extensible Authentication Protocol (EAP) methods and secure AES (CCMP) ciphers. SGX 5150 includes a comprehensive suite of built-in device security applications that offer robust and secure connections (SSL/TLS/PKI), FIPS 140-2 compliant operating mode, data-at-rest protection for keys and configuration, secure boot, secure firmware-over-the-air (FOTA) updates, user role-based access control, fine-grained policy-based network service control, firewall features. Remotely Manage your Connected Machines with the ConsoleFlow™ Platform Add scalable remote device management and data access from your machines via pre-integrated ConsoleFlow™. Provision the SGX5150 with mobile apps for iOS and Android.

Ethernet LAN features
Ethernet WAN	Yes
Ethernet LAN interface type	Ethernet
Ethernet LAN	Yes
Full duplex	Yes
Ethernet LAN data rates	10,100 Mbit/s
Auto MDI/MDI-X	Yes
Cabling technology	10/100Base-T(X)
Performance
Internal memory	8000 MB
Flash memory	256 MB
WAN connection
Ethernet WAN	Yes
WAN connection type	RJ-45
Wireless LAN features
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Network
Ethernet LAN interface type	Ethernet
Ethernet LAN	Yes
Networking standards	IEEE 802.11ac
Full duplex	Yes
Flow control support	Yes
Ethernet LAN data rates	10,100 Mbit/s
Auto MDI/MDI-X	Yes
Cabling technology	10/100Base-T(X)
Ports & interfaces
USB port	Yes
Ethernet LAN (RJ-45) ports	2
DC-in jack	Yes
Management features
WPS push button	Yes
Reset button	Yes
Security
Security algorithms	EAP-PEAP, EAP-TLS, EAP-TTLS, HTTPS
Protocols
DHCP server	Yes
DHCP client	Yes
Design
Product type	Tabletop router
LED indicators	Link, Status, System, WLAN
Product colour	White
Packaging content
Antenna included	Yes
Other features
Internal memory	8000 MB
Flash memory	256 MB
Antenna
Antennas quantity	2
Features
Internal memory	8000 MB
Flash memory	256 MB
Power
Power source type	DC
Power consumption (typical)	1.9 W
Operational conditions
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	5 - 95%
Weight & dimensions
Width	4.25" (108 mm)
Weight	12.3 oz (350 g)
Height	1.3" (33 mm)
Depth	2.83" (72 mm)
Packaging data
Antenna included	Yes
