HPE Networking Comware Switch 48XGT 6QSFP28 5940
36,769.76 CAD
Skip to product information
Out of stock
HPE Networking Comware Switch 48XGT 6QSFP28 5940
Part number
JH391A
36,769.76 CAD
Taxes and shipping calculated at checkout.
Enjoy Free Shipping on orders over 2000 CAD
Shipping time varies based your on location.
Specifications
Weight
13.0 kg
Shipping + Returns
Shipping Policy
Ships to: Canada & USA via UPS, DHL, & Canada Post.
Fast Dispatch: Orders before 2 PM EST process same-day.
Options: Standard (Ground) and Express (Air) shipping available.
Heavy Items: Heavy freight usually requires1-2 extra days for Processing
Returns & Refunds
Return Period: Request a return within 14 days of delivery.
Restocking Fee: 20% fee applies to non-defective/change-of-mind returns.
Condition: Items must be returned in original packaging (New or Like New).
Final Sale: Software, licenses, and special orders cannot be returned.
High-Density, Advanced, Data Center Switches with HPE FlexFabric Network Analytics
The HPE FlexFabric 5940 Switch Series enables customers to scale their server-edge 10/40/100GbE ToR deployments with high-density 48 x 10GbE (SFP or BASE-T) with 6 x 40GbE ports, 48 x 10GbE (SFP or BASE-T) with 6 x 100GbE ports, and 32 x 40GbE ports, delivered in a 1RU design.The HPE FlexFabric 5940 Switch Series is also available with a 2-slot modular version delivering 2 40GbE ports and a 4-slot modular version with 4 40GbE ports.
The HPE 5940 Switch Series includes HPE FlexFabric Network Analytics which in conjunction with the HPE IMC Virtual Application Networking Fabric Manager delivers real time visibility of microburst network congestion which negatively impacts overall network operations and performance.
High-Performance Data Center Switching
The HPE FlexFabric 5940 Switch Series delivers up to 2.56 Tbps switching capacity for the most demanding data center applications.It supports up to 1904 MPPS throughput for data-intensive environments.
Low latency, under 1µs for 40GbE, gives your network increased throughput.
VXLAN support for network virtualization and overlay solutions for improved flexibility. Includes Open vSwitch Database (OVSDB) for dynamic VXLAN tunnel management.
Business Agility and Resilience with Comware 7
The HPE FlexFabric 5940 Switch Series delivers Hewlett Packard Enterprise Intelligent Resilient Fabric (IRF) <50 msec convergence time enabling faster application response time.The In Service Software Update (ISSU) enables high availability with modular updates accomplished without a reboot or power cycle, in the background.
Simplicity and Lower TCO
HPE FlexFabric 5940 Switch Series simplifies switch management by up to 88% with 9-unit Intelligent Resilient Fabric (IRF).No hidden costs with simple one license per switch for all OS features.
All switch ports are active and ready to use without need for activation licenses.
HPE Networking Comware Switch 48XGT 6QSFP28 5940. Switch type: Managed, Switch layer: L2/L3. Basic switching RJ-45 Ethernet ports type: 10G Ethernet (100/1000/10000), Basic switching RJ-45 Ethernet ports quantity: 48, USB 2.0 ports quantity: 1, Console port: RJ-45/Mini-USB. MAC address table: 288000 entries, Switching capacity: 2160 Gbit/s. Networking standards: IEEE 802.1s, IEEE 802.1w, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3ah, IEEE 802.3x. DC input voltage: 40 - 60 V. Rack mounting, Form factor: 1U
| Management features | |
|---|---|
| Switch layer | L2/L3 |
| Switch type | Managed |
| Traffic shaping | Yes |
| Traffic classification | Yes |
| ARP inspection | Yes |
| Web-based management | Yes |
| System event log | Yes |
| Quality of Service (QoS) support | Yes |
| Multicast support | Yes |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 48 |
| Basic switching RJ-45 Ethernet ports type | 10G Ethernet (100/1000/10000) |
| Installed SFP modules quantity | 0 |
| Installed SFP+ modules quantity | 0 |
| SFP+ module slots quantity | 0 |
| QSFP+ module slots quantity | 6 |
| Console port | RJ-45/Mini-USB |
| Gigabit Ethernet (copper) ports quantity | 1 |
| USB 2.0 ports quantity | 1 |
| Fiber optic connector | QSFP28 |
| Network | |
| Networking standards | IEEE 802.1s, IEEE 802.1w, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3ah, IEEE 802.3x |
| 10G support | Yes |
| Optical fiber | |
| Fiber ethernet cabling technology | 1000BASE-X |
| Fiber optic connector | QSFP28 |
| Data transmission | |
| MAC address table | 288000 entries |
| Switching capacity | 2160 Gbit/s |
| Throughput | 1607 Mpps |
| Latency (10 Gbps) | 1 µs |
| Packet buffer memory | 16 MB |
| Multicast features | |
| Multicast support | Yes |
| Protocols | |
| Management protocols | SNMP, Telnet, FTP |
| Design | |
| Rack mounting | Yes |
| Stackable | Yes |
| Product colour | Black |
| Form factor | 1U |
| LED indicators | Yes |
| Performance | |
| Physical stacking (units) | 9 |
| Internal memory | 4096 MB |
| Flash memory | 1024 MB |
| Stackable | Yes |
| Packet buffer memory | 16 MB |
| Harmonized System (HS) code | 85176990 |
| Power | |
| Power supply included | No |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power consumption (typical) | 320 W |
| Power consumption (max) | 320 W |
| Input voltage | -40 - -75 V |
| DC input voltage | 40 - 60 V |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | No |
| Other features | |
| Warranty period | 1 year(s) |
| Input voltage | -40 - -75 V |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 45 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Heat dissipation | 887 BTU/h |
| Weight & dimensions | |
| Width | 17.3" (440 mm) |
| Depth | 26" (660 mm) |
| Height | 1.72" (43.6 mm) |
| Weight | 28.7 lbs (13 kg) |
| Packaging content | |
| User guide | Yes |
| Quick start guide | Yes |
| Manual | Yes |
| Technical details | |
| Warranty period | 1 year(s) |
| Packaging data | |
| User guide | Yes |
| Quick start guide | Yes |
| Manual | Yes |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
