New In-Cell Touch Open Frame for Optimal Customization

Slim & Light
The In-Cell Touch Open Frame has a touch function built into the display, allowing for the implementation of a slim design and a narrow bezel compared to general touch products that require additional touch parts (Film).

Clear Picture Quality
Compared to general touch products, 27TNF3K implements clear picture quality without milk effects caused by additional touch sensor film parts.

Design Flexibility
By providing integrated parts such as touchscreen, display, and webOS, users can realize free design for their own needs.

Wide Viewing Angle
IPS panel technology provides better control of the liquid crystals, which in turn allows the screen to be viewed at virtually any angle.

45-degree Tilt (Face up) Installation Possible
When a display is installed at low places, it is usually tilted for the user’s viewing comfort. Considering this, the installation with a max tilt of 45 degrees is supported.

10 Points of Multi-Touch
The 27TNF3K provides a more realistic touch sensation since it can recognize up to 10 points of multi-touch at once, and various touchbased user services can be provided through the screen.

High-Performance with webOS 6.0
webOS 6.0, upgraded in SoC* and web engine, is available on 27TNF3K for a smooth execution of several tasks. LG webOS smart signage platform enhances user convenience with intuitive GUI** and provides to SI or/and developers simple app development tools such as SDK (Software Development Kit), SCAP, sample applications.

Display
Display diagonal	27"
Display resolution	1920 x 1080 pixels
Display brightness	300 cd/m²
HD type	Full HD
Response time	9 ms
Contrast ratio (typical)	1000:1
Viewing angle, horizontal	178°
Viewing angle, vertical	178°
Display number of colours	16.7 million colors
Touchscreen	Yes
Panel type	IPS
Number of simultaneous touchpoints	10
Native aspect ratio	16:9
LED backlighting type	Edge-LED
Display technology	LED
Anti-glare screen	Yes
Hardness	3H
Touchscreen technology	Capacitive
Colour saturation	72%
Rated lifetime	31000 h
Native refresh rate	60 Hz
Multi-touch	Yes
Ports & interfaces
Ethernet LAN	Yes
HDMI ports quantity	2
DVI port	No
USB connector type	USB Type-A, USB Type-B
Remote (IR) input	1
USB port	Yes
Ethernet LAN (RJ-45) ports	1
Wi-Fi	No
USB ports quantity	2
Number of speaker outputs	1
DisplayPorts quantity	0
Audio
Built-in speaker(s)	No
Design
Product design	Digital signage flat panel
Product colour	Silver
VESA mounting	Yes
Panel mounting interface	200 x 100 mm
Placement supported	Indoor
Bezel width (top)	0.303" (7.7 mm)
Bezel width (side)	0.303" (7.7 mm)
Bezel width (bottom)	0.382" (9.7 mm)
Anti-glare screen	Yes
Screen shape	Flat
Performance
Purpose	Universal
Operating hours (hours/days)	16/7
On Screen Display (OSD)	Yes
HDCP	Yes
HDCP version	1.4
Wi-Fi	No
Power
Power consumption (standby)	0.5 W
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Computer system
Operating system installed	WebOS
Computer system	Yes
Computer system type	System on Chip (SoC)
Internal storage capacity	8 GB
Weight & dimensions
Display width	24.2" (614.9 mm)
Display depth	0.594" (15.1 mm)
Display height	14" (355.3 mm)
Display weight	9.26 lbs (4.2 kg)
Packaging data
Package width	27.8" (707 mm)
Package depth	6.73" (171 mm)
Package height	17.8" (451 mm)
Package volume	6200 cm³
Remote control included	Yes
Cables included	AC, USB Type-A to USB Type-B
Packaging content
Remote control included	Yes
Cables included	AC, USB Type-A to USB Type-B
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80%
Thin Client
Operating system installed	WebOS
Internal storage capacity	8 GB
Technical details
USB connector type	USB Type-A, USB Type-B
Panel type	IPS
Number of simultaneous touchpoints	10
LED backlighting type	Edge-LED
Other features
USB connector type	USB Type-A, USB Type-B
Wi-Fi	No
Panel type	IPS
Number of simultaneous touchpoints	10
Display technology	LED
Bezel width (top)	0.303" (7.7 mm)
Bezel width (side)	0.303" (7.7 mm)
Bezel width (bottom)	0.382" (9.7 mm)
