EnGenius EPA5090GBT PoE adapter Gigabit Ethernet 54 V
104.47 CAD
Skip to product information
1 left
EnGenius EPA5090GBT PoE adapter Gigabit Ethernet 54 V
Part number
EPA5090GBT
104.47 CAD
Taxes and shipping calculated at checkout.
Enjoy Free Shipping on orders over 2000 CAD
Shipping time varies based your on location.
Specifications
Weight
0.47 kg
Shipping + Returns
Shipping Policy
Ships to: Canada & USA via UPS, DHL, & Canada Post.
Fast Dispatch: Orders before 2 PM EST process same-day.
Options: Standard (Ground) and Express (Air) shipping available.
Heavy Items: Heavy freight usually requires1-2 extra days for Processing
Returns & Refunds
Return Period: Request a return within 14 days of delivery.
Restocking Fee: 20% fee applies to non-defective/change-of-mind returns.
Condition: Items must be returned in original packaging (New or Like New).
Final Sale: Software, licenses, and special orders cannot be returned.
- Gigabit Ethernet In & Out Ports for High-Speed Devices
- Delivers both data and power to PoE-compatible devices
- Optimal port design for easy mounting/positioning
- Extends power to unwired areas up to 328-ft./100m
- Disconnect, short-circuit & surge protection assure secure, reliable connections
- Sends up to 90W of output power for connecting APs, IP cameras, VoIP phones & more
- Mounts to walls or ceilings with included hardware
The EPA5090GBT IEEE 802.3bt standard Power-over-Ethernet adapter supports high-speed data and up to 90 Watts/54V of power to compliant devices such asnetwork devices that need a higher power to work normally to 100 meters away over a single cable. It is designed specifically to meet the demand for growing higher power required network equipment as big power AP, media server, thin client, POS system, health care, Lighting, PTZ speed dome camera, all-in-one touch PC, remote digital signage display. A compact, optimal port design provides easy, precise installation, while built-in power surge protection preserves valuable equipment.
| Network | |
|---|---|
| Networking standards | IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Ethernet interface type | Gigabit Ethernet |
| Features | |
| Wall mountable | Yes |
| Product colour | Black |
| Pin assignment & polarity | Pin4(Vdc+)&Pin5(Vdc+); Pin7(Vdc-)&Pin8(Vdc-); Pin1(Rx+)&Pin2(Rx-); Pin3(Tx+)&Pin6(Tx-) |
| Power protection features | Over current, Over voltage, Short circuit |
| LED indicators | Power |
| Networking standards | IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt |
| Power | |
| Output power | 90 W |
| Power over Ethernet (PoE) voltage | 54 V |
| Input voltage | 100 - 240 V |
| Input frequency | 50 - 60 Hz |
| Input current | 0.95A @ 120V, AC 0.5A @ 240V AC |
| Surge protection voltage | 4 kV |
| Certificates | |
| Compliance certificates | CB, CE, Federal Communications Commission (FCC), UL |
| Operational conditions | |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating temperature (T-T) | 0 - 40 °C |
| Weight & dimensions | |
| Weight | 7.41 oz (210 g) |
| Width | 5.91" (150 mm) |
| Depth | 2.56" (65 mm) |
| Height | 1.34" (34 mm) |
| Package weight | 16.6 oz (470 g) |
| Package depth | 3.54" (90 mm) |
| Package width | 7.01" (178 mm) |
| Package height | 2.83" (72 mm) |
| Packaging data | |
| Package weight | 16.6 oz (470 g) |
| Package depth | 3.54" (90 mm) |
| Package width | 7.01" (178 mm) |
| Package height | 2.83" (72 mm) |
| Technical details | |
| Warranty period | 1 year(s) |
| Compliance certificates | CB, CE, Federal Communications Commission (FCC), UL |
| Logistics data | |
| Master (outer) case width | 7.87" (200 mm) |
| Master (outer) case length | 15" (380 mm) |
| Master (outer) case height | 15.7" (400 mm) |
| Master (outer) case gross weight | 22 lbs (10 kg) |
| Products per master (outer) case | 20 pc(s) |
| Warranty period | 1 year(s) |
