A Future-Proof, Versatile, and Compact Router with PoE+ Ports and Controller Capability
Omada 3-in-1 Gigabit VPN Router

3-in-1 Router, More Than A Router
The 3-in-1 ER7212PC presents a one-stop solution for home and small business networking.

With a single compact box, users can replace their router, hardware controller, and PoE+ switch setup. There is no need to manually configure various network devices one by one, you can perform unified deployment through ER7212PC. All you need is one device.

Up to Four WAN Gigabit Ports to Optimize Bandwidth Usage
Equipped with multiple ports, ER7212PC satisfies various internet access requirements through one device. The multi-WAN Load Balancing function distributes data streams according to the bandwidth proportion of every WAN port to raise the utilization rate of multi-line broadband.

Easy Installation, Quiet Heat Dissipation
A clean, well-organized, and quiet network environment is at your fingertips.

- The compact and minimalist design makes it suitable for your configuration in various spaces, whether it's the corner of office desks or the ceiling of a store.
- Fanless design offers noiseless heat dissipation to your shops or offices.

Easy Centralized Management
With built-in centralized management capability, the ER7212PC enables you to manage and update devices in bulk, with no need for individual and complex setups. Additionally, check the Omada app or web browser, ER7212PC allows you to remotely control connected devices, monitor the network, and view the network maintenance in real-time.

High-Security and High-Performance VPN
ER7212PC supports pass-through traffic and multiple VPN protocols, including OpenVPN, IPSec, PPTP, and L2TP in Client/Server mode. One-click auto IPSec VPN simplifies VPN configuration and facilitates network management and deployment.

Robust Security Features

- Powerful Firewall
Advanced firewall policies
protect your network and data.

- Convenient VLAN Support
Create virtual network segments for
enhanced security and simplified
network management.

- DoS Defense
Automatically detects and blocks
Denial of Service (DoS) attacks such
as TCP/UDP/ICMP Flooding, Ping of
Death, and other related threats.

- IP/MAC/URL/Keyword Filtering
Forcefully prevent viruses and attacks from intruders.

- IP-MAC Binding
Reserves static IP assignment for
clients to defend against ARP
attacks and spoofing.

- One-Click ALG Activation
One-Click ALG Activation for
applications such as FTP, H323, SIP,
IPSec, and PPTP.

Ethernet LAN features
Ethernet LAN data rates	10,100,1000 Mbit/s
Cabling technology	10/100/1000Base-T(X)
Performance
Flash memory	4096 MB
Internal memory	1024 MB
Internal memory type	DDR3
Built-in processor	Yes
Processor frequency	1200 MHz
WAN connection
SFP WAN	Yes
Ethernet WAN	Yes
DSL WAN	No
SIM card slot	No
3G/4G USB modem compatibility	No
Network
Networking standards	IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Ethernet LAN data rates	10,100,1000 Mbit/s
Cabling technology	10/100/1000Base-T(X)
Port forwarding	Yes
Static route	Yes
VLAN support	Yes
Ethernet interface type	Gigabit Ethernet
Management features
Universal Plug and Play (UPnP)	Yes
Reset button	Yes
Ports & interfaces
Power over Ethernet (PoE) ports quantity	8
Ethernet LAN (RJ-45) ports	10
DC-in jack	Yes
Combo SFP ports quantity	2
Protocols
DHCP server	Yes
DHCP client	Yes
Supported protocols	TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, SNMP
Security
URL filtering	Yes
NAT functionality	Multi-Net NAT; Virtual Server; NAT-DMZ; FTP/H.323/SIP/IPSec/PPTP ALG; UPnP;
Access Control List (ACL)	Yes
Packaging content
AC adapter included	Yes
Manual	Yes
Features
Flash memory	4096 MB
Internal memory	1024 MB
Internal memory type	DDR3
Built-in processor	Yes
Processor frequency	1200 MHz
Certification	CE, FCC, RoHS
Design
LED indicators	Yes
Housing material	Metal
Product colour	Black
Power
Output voltage	53.5 V
Output current	2.43 A
Power over Ethernet (PoE)	Yes
Operational conditions
Operating temperature (T-T)	0 - 45 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 90%
Storage relative humidity (H-H)	5 - 90%
Weight & dimensions
Width	8.9" (226 mm)
Depth	5.16" (131 mm)
Height	1.38" (35 mm)
Package width	8.94" (227 mm)
Package depth	14.7" (374 mm)
Package height	2.87" (73 mm)
Package weight	4.23 lbs (1.92 kg)
Packaging data
AC adapter included	Yes
Manual	Yes
Package width	8.94" (227 mm)
Package depth	14.7" (374 mm)
Package height	2.87" (73 mm)
Package weight	4.23 lbs (1.92 kg)
Certificates
Certification	CE, FCC, RoHS
