- Proprietary Ubiquiti LTU core processor
- Long-range, 29 dBi antenna with InnerFeed® technology
- High data and performance rate (1024 QAM)
- Link range up to 35 km
- Channel width flexibility (10/20/30/40/50 MHz bandwidth)
- Central configuration management from the AP side
- Frequency splitting
- Router mode support
- Integrated GPS
- Link planning support via ISP Design Center
The LTU XR is a high-performance, cost-effective PtMP CPE for wireless ISPs that can reach up to a 550 Mbps throughput rate. The LTU XR also facilitates independent transmission and receives channel frequency configurations anywhere within its radio band to avoid local interference and ensure superior client performance. Additionally, the LTU XR is equipped with a Bluetooth management radio so it's easy to set up and configure with the UISP® Mobile app.
| Performance | |
|---|---|
| 5 GHz | Yes |
| Web-based management | Yes |
| Reset button | Yes |
| Modulation | 1024-QAM |
| Certification | FCC, IC, CE |
| Operating system installed | AirOS |
| Built-in processor | Yes |
| Features | |
| 5 GHz | Yes |
| Modulation | 1024-QAM |
| Cabling technology | 10/100/1000Base-T(X) |
| Bluetooth | Yes |
| Throughput data rate | 550 Mbit/s |
| Operating system installed | AirOS |
| Built-in processor | Yes |
| Security | |
| Security algorithms | WPA2-PSK |
| Management features | |
| Web-based management | Yes |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 1 |
| DC-in jack | Yes |
| Cabling technology | 10/100/1000Base-T(X) |
| Power | |
| Power consumption (max) | 8.5 W |
| Power over Ethernet (PoE) | Yes |
| Design | |
| Reset button | Yes |
| Placement | Pole |
| LED indicators | LAN, Power |
| International Protection (IP) code | IPX6 |
| Housing material | Aluminum, Polycarbonate (PC) |
| Product colour | White |
| Certification | FCC, IC, CE |
| Antenna | |
| Antenna gain level (max) | 29 dBi |
| Weight & dimensions | |
| Width | 29.4" (747 mm) |
| Depth | 13.7" (347 mm) |
| Height | 20.7" (525 mm) |
| Weight | 7.05 lbs (3.2 kg) |
| Packaging data | |
| Mounting kit | Yes |
| Packaging content | |
| Mounting kit | Yes |
| Operational conditions | |
| Operating relative humidity (H-H) | 5 - 95% |
| Operating temperature (T-T) | -40 - 55 °C |
| Logistics data | |
| Quantity per pack | 1 pc(s) |
