The ViewSonic® CDE7512 is a 75” 4K Ultra HD large format wireless presentation display. With features including a razor-sharp resolution of 3840 x 2160, 330-nit high brightness, 178-degree ultra-wide viewing angles, 2 x 10W speakers, and wireless screen sharing, the CDE7512 transforms meeting rooms into a dynamic communications hub. The built-in ViewBoard® Cast screen sharing software* (along with the optional ViewSonic vCastSender app), and myViewBoard Display software, enables both on-site and online users to participate in conferences and simultaneously share content. Equipped with a 1.5GHz Quad-core embedded SoC processor, 2GB RAM, and 16GB of internal memory, the CDE7512 can play multimedia from internal storage or a USB flash drive 16 hours a day, seven days a week. And with remote configuration and content management system support, the ViewSonic® CDE7512 is also suitable for a wide array of diverse signage applications.

ULTRA HD RESOLUTION
With four-times the resolution of Full HD, this Ultra HD 3840x2160 display delivers a breathtaking viewing experience with immersive images that are vibrant, clear, and as large as life.

POWERFUL EMBEDDED SOC PLATFORM
The ViewSonic® EMBEDDED Signage Platform (VESP) is a Linux-based Kernel OS, all-in-one solution that simplifies installation and maintenance. With VESP, there is no need for any external devices to communicate with the server or play digital media. Enjoy simplified development, reinforced capability with multiple web formats, and secured protection.

EMBEDDED LAN AND USB WIRELESS CONNECTIVITY
An integrated RJ45 connection, as well as a removable, integrated USB, provide Wi-Fi capabilities for content streaming.

FREE VIEWBOARD ® CAST CONTENT SHARING SOFTWARE
ViewBoard® Cast enables content to be streamed from mobile devices onto the display via wireless or cable networks. Multiple users can simultaneously annotate content (such as documents, cloud files, multimedia, etc.) on their devices in real time, and then stream and share that content onto the ViewSonic large format display. One-to-one, one-to-many, and 4-in-1 multi-screen options are also available.

REMOTE CONTENT SHARING FROM ANYWHERE
myViewBoard Display is a cloud-based and client-free app that allows you to share your screen from anywhere in the world from virtually any device, without having to worry about group policies or installing additional software.

ALL-IN-ONE SOLUTION
Perfect for conference rooms, huddle spaces and other collaborative environments, this bundle delivers the most useful items businesses need to get up and running with their wireless presentation display. You can quickly install the display with the included wall mount, while the included USB Wi-Fi plug-in module provides a robust and reliable wireless presentation experience.

STREAMLINED DEVICE MANAGEMENT
myViewBoard Manager™ is an easy-to-use, web-based application that allows you to securely set up, manage and maintain all of your display devices from a centralized dashboard. Cloud-based access allows IT managers to remotely access, monitor and manage devices from anywhere.

USB-C WITH POWER DELIVERY
USB-C connectivity provides up to 15W power delivery for convenient charging of your peripherals and accessories. It can also support DisplayPort 1.2 and USB 2.0 with optional adapters.

AV CONTROL SYSTEM CERTIFIED
The AV control system is at the heart of all integrated AV systems and impacts the overall effectiveness of the entire system. Proper programming is essential for completing profitable projects, gaining user confidence and client satisfaction, and promoting relationships. These wireless presentation displays are Extron certified, AMX certified and Crestron compatible.

RELIABLE 16/7 CONTINUOUS OPERATION
Featuring a long lifespan, this professional-grade commercial display is designed for reliable use 16 hours a day, 7 days a week. Ideal in virtually any commercial application and environment, this commercial display delivers peace of mind with its robust and durable design.

INTEGRATED CONTENT MANAGEMENT SYSTEM
Enjoy a cloud-based 30-day trial service subscription from ViewSonic's content management software, powered by Revel Digital platform. This allows you to instantly transfer multimedia from any HTML5 browser-based device to the display no matter where you are. Works with optional ViewSonic Signage Manager CMS (SW-216) for local content push with perpetual license.

Display
Display diagonal	75"
Display resolution	3840 x 2160 pixels
Display brightness	330 cd/m²
HD type	4K Ultra HD
Response time	8 ms
Contrast ratio (typical)	1200:1
Contrast ratio (dynamic)	5000:1
Viewing angle, horizontal	178°
Viewing angle, vertical	178°
Display number of colours	1.07 billion colors
Panel life	30000 h
Touchscreen	No
LED backlighting type	Direct-LED
Ports & interfaces
Ethernet LAN	Yes
HDMI ports quantity	2
HDMI version	2.0
VGA (D-Sub) input ports	1
USB port	Yes
Audio (L/R) in	1
Audio (L/R) out	1
Ethernet LAN (RJ-45) ports	1
RS-232 interface	Yes
Wi-Fi	Yes
USB version	2.0
USB ports quantity	2
Number of speaker outputs	1
HDMI input ports quantity	2
Audio
Number of built-in speakers	2
RMS rated power	10 W
Built-in speaker(s)	Yes
Design
Product design	Digital signage flat panel
Product colour	Black
VESA mounting	Yes
Panel mounting interface	600 x 400 mm
Placement supported	Indoor
Orientation	Landscape
Certification	cULus, FCC, Energy Star, RoHS
Mounting type	Wall
Performance
Operating hours (hours/days)	16/7
Panel life	30000 h
Wi-Fi	Yes
Power
Power consumption (typical)	240 W
Power consumption (standby)	0.5 W
AC input voltage	100-240 V
AC input frequency	50-60 Hz
Power consumption (max)	300 W
Computer system
Processor family	ARM Cortex
Processor model	Cortex-A53
Processor frequency	1.5 GHz
Operating system installed	Android 9.0
Computer system	Yes
Computer system type	System on Chip (SoC)
Internal memory	2 GB
Processor cores	4
Internal storage capacity	16 GB
Processor manufacturer	ARM
Built-in processor	Yes
On-board graphics card model	ARM Mali-G52
Weight & dimensions
Width	66.3" (1683.8 mm)
Depth	2.81" (71.3 mm)
Height	38" (965.3 mm)
Weight	60.2 lbs (27.3 kg)
Packaging data
Package width	71.2" (1808 mm)
Package depth	7.09" (180 mm)
Package height	42.1" (1069 mm)
Package weight	79.6 lbs (36.1 kg)
Remote control included	Yes
Cables included	HDMI, RS-232
Packaging content
Remote control included	Yes
Cables included	HDMI, RS-232
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 80%
Certificates
Certification	cULus, FCC, Energy Star, RoHS
Thin Client
Processor family	ARM Cortex
Processor model	Cortex-A53
Processor frequency	1.5 GHz
Operating system installed	Android 9.0
Internal memory	2 GB
Internal storage capacity	16 GB
Features
Wall mountable	Yes
Technical details
Response time	8 s
LED backlighting type	Direct-LED
Other features
Response time	8 s
Wi-Fi	Yes
Power consumption (max)	300 W
Aspect ratio	16:9
