iogear GCS92HU KVM switch Black
Part number
GCS92HU
$109.47 CAD
4096 x 2160, 60Hz, HDMI, HDCP 2.2
Key Features
- Control and switch between two DisplayPort computers from a USB keyboard, mouse and DisplayPort monitor
- Superior video quality – up to 4K DCI (4096 x 2160 @60Hz)
- Multi-platform support – Windows, Mac and Linux
- DisplayPort 1.1, HDMI and HDCP 2.2 compliant
- Port switching via remote switch button
- Supports USB hot-plugging (add or remove the device without shutting down the operating system)
- The console USB ports can be used for USB peripheral sharing (keyboard and mouse)1
- Easy installation, just plug and play
- Built-in cables
- Hook design for a space-saving and organized workstation
- Bus-powered – no external power adapter required
- 2.1 audio support
- 3-year warranty
- Free lifetime US-based technical support
Description
2-Port 4K KVM Switch with HDMI Connection, USB and Audio One of the most compact KVMs IOGEAR has to offer, the 2-Port 4K KVM Switch with HDMI Connection, USB and Audio is a must-have for users with two computers using one monitor, keyboard and mouse. It is perfect for a home office or small to medium-sized business that need to conserve workspace and streamline desktop setups. 4K Video This 4K KVM supports up to 4096 x 2160 @60Hz resolution on large widescreen HDMI displays giving the user high-quality images on screen every time. It is perfect for users in the finance, medical, computer programming and graphics fields. Digital/Analog Audio 2-Port 4K KVM Switch with HDMI Connection supports both digital and analog 2.1 audio. Digital is supported through HDMI while analog is supported with 3.5 mm audio ports. Both connections ensure clear audio to meet all your audio needs. Easy Installation The 2-Port 4K KVM Switch is plug-and-play. And all the cables you need are included. Easily switch between two computers with a touch of the remote button on your desktop. The KVM shows which computer you are using with a light on the unit (either PC1 or PC2). Additionally, the KVM was designed with a hook design for a space-saving and organized workstation.Specifications
| Ports & interfaces | |
|---|---|
| Cable length | 47.6" (1.21 m) |
| Number of computers controlled | 2 |
| Keyboard port type | USB |
| Number of microphone inputs | 2 |
| Mouse port type | USB |
| Video port type | HDMI |
| Audio connections | Yes |
| DisplayPort version | 1.1 |
| Headphone outputs | 2 |
| HDMI ports quantity | 2 |
| HDCP | Yes |
| Console USB ports quantity | 2 |
| Console ports | 3.5mm headphone, 3.5mm mic, HDMI, USB A |
| USB 2.0 Type-B ports quantity | 2 |
| Performance | |
| HDCP | Yes |
| HD type | 4K DCI |
| Video bandwidth | 60 Hz |
| Hot-Plug support | Yes |
| Plug and Play | Yes |
| Maximum resolution | 4096 x 2160 pixels |
| Audio channels | 2.1 |
| Video | |
| HD type | 4K DCI |
| Video bandwidth | 60 Hz |
| Maximum resolution | 4096 x 2160 pixels |
| Design | |
| Product colour | Black |
| Cable length | 47.6" (1.21 m) |
| Housing material | Plastic |
| Display | |
| Built-in display | No |
| System requirements | |
| Windows operating systems supported | Yes |
| Linux operating systems supported | Yes |
| Mac operating systems supported | Yes |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
| Weight & dimensions | |
| Depth | 3.23" (82 mm) |
| Height | 1.02" (26 mm) |
| Weight | 12.7 oz (360 g) |
| Package depth | 2.17" (55 mm) |
| Package height | 8.86" (225 mm) |
| Package weight | 16.9 oz (480 g) |
| Packaging data | |
| Package depth | 2.17" (55 mm) |
| Package height | 8.86" (225 mm) |
| Package weight | 16.9 oz (480 g) |
| Packaging content | |
| Cables included | KVM |
| Logistics data | |
| Master (outer) case length | 15.2" (387 mm) |
| Master (outer) case height | 6.73" (171 mm) |
| Master (outer) case gross weight | 7.01 lbs (3.18 kg) |
| Products per master (outer) case | 6 pc(s) |
